  1. PROFLO Pumps

  2. TYPES OF PROFLO PUMPS Utility Sump Effluent Sewage Battery Backup Pumps

  3. LINCOLN STOCKING CROSS Description Description LP# Model LP# Model 236005 236035 1/5HP THERMOPLAS SUB UTIL PUMP 1/2HP CI SUMP PUMP SIDE DISCHRG PF91025 PF92511 236010 236040 1/3HP THERMOPLAS SUB UTIL PUMP 1/3HP THERMOPLAS PED SUMP PUMP PF91335 PF92333 236015 SO 1/4HP THERMOPLAS AUTO SUMP PUMP 1/3HP CI EFFLUENT PUMP TETHERED PF92260 PF92305 1/2HP CI SEWAGE PUMP W/ FLOAT SWCH 236017 236045 1/3HP THERMOPLAS AUTO SUMP PUMP PF92342 PF93501 1/2HP CI SEWAGE PUMP W/ VERT SWCH SO 236046 1/3HP THERMOPLAS AUTO SUMP PUMP PF92330 PF93511 SMPLX SEW PUMP KIT W/ PF93501 PUMP SO SO 1/3HP PLAS SUMP PUMP W/ BSE PF92330PB PF93015 1/3HP TPLAS SUMP PUMP TETHERED SWCH SMPLX SEW PUMP KIT W/ PF93511 PUMP SO SO PF92370 PF93020 SO 236013 1/3HP CI SUB SUMP PUMP W/ SWCH REMOTE LDRY DRN PUMP SYS PF92331 PF92017 3/10HP CI SUB SUMP PUMP W/ VERT SWC 236020 SO 12V BATRY BU PUMP SYS W/ PF92341 PF92341 PF92941 236025 SO 1/3HP CI SUB SUMP PUMP SIDE DISCHRG 12V BATRY BU PUMP SYS W/ PF92352 PF92352 PF92952 236030 236060 1/3HP CI SUB SUMP PUMP W/ABS DISC 12V BATRY BU PUMP ONLY KIT PFTG92352 PF92910 SO 1/3HP CI SUMP PUMP W/ BSE PIPE PVC PFTG92352P

  4. PROFLO PUMP COMPARISON

  5. PUMP TERMINOLOGY Pump Head - refers to how high a pump will vertically lift water. Split Capacitor Motors - Used in all PROFLO Pumps feature dual ball bearings and require less amp draw therefore run cooler and last longer. GPMs- Gallons per Minute. How many gallons are pumped out of a basin per minute. Solids Handling - The size of solids a pump can pass. Discharge size - Determines the pipe size required for the pump to discharge the water or sewage Impeller- Is a rotor blade positioned near the bottom of the pump which creates the process of water movement and subsequent water removal. Housing/Base - The housing is the material of the top half of the pump. The base is the lower portion. All PROFLO Cast Iron pumps have cast iron housings and bases.

  6. UNIQUE FEATURES OF PROFLO PUMPS Underwriters Laboratories (UL) Listed Split Capacitor Motors Double O-Ring Seals SS Jacketed Double Lip Shaft Seals Solid Copper Windings

  7. PROFLO UTILITY PUMPS 236005/PF91025 - 1/5HP THERMOPLAS SUB UTILITY PUMP 236010/PF91335 -1/3HP THERMOPLAS SUB UTILITY PUMP Continuous duty, thermally protected split capacitor motors Pump will lift water over 25' Low suction clearance - pumps to 1/8" of the floor Pre fitted with garden hose adapter Sleek design allows pump to fit in a 6" opening For basic ground water removal

  8. PROFLO SUMP PUMPS Split Capacitor Motors for low amp draw and cooler operation Side and bottom intake for clog resistant suction Vertical or tethered float switches available with piggy back plug included Cast Iron and Thermoplastic designs available Pump will lift water over 25 vertical height For basic ground water removal

  9. PROFLO SUMP PUMPS 236020/PF92341 3/10 HP Cast Iron submersible sump pump with side discharge, vertical float and 10 cord. Pumps up to 46 GPM. 236025/PF92352 1/3 HP Cast Iron submersible sump pump with side discharge, vertical float and 10 cord. Pumps up to 60 GPM. 236035/PF92511 1/2 HP Cast Iron submersible sump pump with side discharge, vertical switch and 10 cord. Pumps up to 70 GPM.

  10. PROFLO SUMP PUMPS - THERMOPLASTIC 236015/PF92260 1/4 HP Thermoplastic submersible sump pump with tethered switch. Pumps up to 30 GPM. 236017/PF92342 1/3 HP Thermoplastic submersible sump pump with vertical switch. Pumps up to 40 GPM.

  11. PROFLO EFFLUENT PUMPS PF92305 - 1/3HP CI EFFLUENT PUMP TETHERED Split Capacitor Motors for low amp draw and cooler operation Specifically constructed for operating in caustic environments Side and bottom intake for clog resistant suction Cast Iron housing and base Features trouble free metal vortex impellers Pump will lift water over 25' vertical height

  12. PROFLO SEWAGE PUMPS 236046/PF93511 - 1/2HP CI SEWAGE PUMP W/ VERT SWCH 236045/PF93501 - 1/2HP CI SEWAGE PUMP W/ FLOAT SWCH 1/2 HP Split Capacitor Motor Cast Iron housing and base Trouble Free non-clogging metal vortex impeller 2" female iron pipe discharge thread Will easily handle up to 2" solids Lifts water to 25'

  13. SIMPLEX SEWAGE KITS SYSTEM INCLUDES Pre assembled kit 1/2 HP Cast Iron Sewage Pump (PF93501/PF93511) 18" x 30" basin with 12 bolt cover (12" or covers?) 2" Full Flow Check valve with rubber boot BASIN FEATURES Structural foam construction Sonic Welded Torque stops Corrosion resistant 18" x 30" Size Gasket Sealed, Air Tight Cover 4" Inlet hub 2" Discharge & Vent Sonic Welded Torque stops PF93501 / PF93511 PF93015 - Tethered PF93020 - Vertical Great for new homes or remodels!

  14. REMOTE SINK DRAIN KIT SYSTEM INCLUDES 1/3 HP Cast Iron sump pump (PF92341) 15" x 15" Poly basin with cover Universal check valve 236013/PF92017 BASIN FEATURES Polyethylene structural foam Corrosion resistant 6 Gallon Capacity, 15"x 15" Gasket Sealed, Air Tight Cover 1 1/2" Inlet 1 1/2" Outlet & Vent Preassembled 236020/PF92341

  15. BATTERY BACKUP PUMPS 236060/PF92910 Battery Backup System A Battery Back Up Pump allows your sump pump to operate even with loss of power or failure to the primary pump. Once the sump pump reaches a certain level the Battery Back Up pump will turn on to discharge the water. PF92941 Pre-assembled Primary and Battery Backup Sump Kit PF92952 Pre-assembled Primary and Battery Backup Sump Kit *Replacement Parts available upon request

  16. BATTERY BACKUP PUMPS Why the PROFLO Battery Back Up Pump? Low amp draw longer life Works when power is out Meets or exceeds industry standards Simplicity and ease of use Peace of mind Uses a sump rather than a bilge pump Simultaneous operation if needed Compact design Durable and efficient Alarm / control

  17. BATTERY SPECIFICATION COMPATIBILITY The PROFLO PF92910 (236060) battery back-up requires the following battery style: Group 27 marine grade battery Recommended 160 minute reserve capacity Acceptable batteries include: Interstate SRM-27, SRM-27B Excide NC-27 East Penn MDC-27 Delco M27D6 Everstart 27DC6 Diehard DP27 Duralast 27DP-DL Zoller P-N10-0761 Length of run time may be increased by using an AGM (Absorbed Glass Mat) battery. Acceptable AGM batteries examples include: Optima D27M Zoller 10-1450 AGM

  18. PROFLO PUMP QUALITY ASSURANCE STEPS In addition to adherence to shop drawings and quality of materials, all production goes through the following steps: Each motor is 100% tested for continuity, RPM, Amp draw & Hi Pot. Each assembled pump is air pressurized to 60 PSI under water to check for seal integrity and any weaknesses in construction. All production is 100% operationally tested underwater to check performance, amp draw under load & seal integrity. Samplingof each production run is sent to lab for endurance testing. Testing includes: 90,000 on/off switch cycles at 10 ft head. 5,000 hours running under load of 12 ft head.

  19. PROFLO PUMP WARRANTY AND RETURN INFORMATION PUMP TYPE WARRANTY PERIOD Cast Iron Sump Pumps & Sump Pump Kits 5 year warranty Thermoplastic Sump & Utility Pumps 3 year warranty Sewage Pumps & Sewage Pump kits 3 year warranty Effluent Pumps 3 year warranty Battery Backup Pumps & Pump Kits 3 year warranty

  20. TROUBLESHOOTING Pump doesn t start or run Make sure the pump is plugged in to an outlet Check for blown fuses or tripped circuit breakers or tripped GFCI outlets Check the pump by bypassing switch by plugging pump directly into outlet. If the pump works you have a switch malfunction Check for any obstructions in the impeller CALL 1-888-6PROFLO (1-888-6356)

  21. TROUBLESHOOTING Pump starts and stops too often Check for back flow of water from discharge pipe Check float switch for proper operation Pump will not shut off Make sure switch drops to full down position Check for obstruction in piping CALL 1-888-6PROFLO (1-888-6356)

  22. TROUBLESHOOTING Pump runs and moves little or no water Make sure check valve is installed in proper direction Check to ensure discharge pipe is not obstructed The unit may be air locked. This pump has an anti-air lock device built in. Clean out the air lock Check intake screen for obstructions. CALL 1-888-6PROFLO (1-888-677-6356)

  23. SUMP PUMP MAINTENANCE Always keep outside discharge outlet clean - Especially during winter. Fill sump pit with water every 6 months Check pit for trash, stones and debris monthly After power outage activate pump switch to confirm operation.

  24. For sales assistance please call: 1-800-735-4503 or or email: sales@lincolnproducts.com For operational or warranty assistance please call our pump experts: 1-888-6(PROFLO) 1-888-677-6356
