402x Series Precision RF Power Sensors 4421A Power Meter 4421B540-2 Interface Adapter and VPM3 Software Mike Gathergood Bird Technologies, EMEA +44 7557 368490 mgathergood@birdrf.com July 2020
Precision Power Sensors The 402x Series are a range of precision RF power sensors which include: 4020 Series 3% sensors. 4027A Series 1% sensors for commonly used ISM frequencies. 4027F Series 1% sensors with integral rejection of harmonics and modulation artefacts. 4028 Series 2% high power sensors, 500W to 50kW. The 402x Series work with: 4421A power meter 4421B540-2 interface adapter and VPM3 software
Precision Power Sensors 4020 Series 3% accuracy over stated range. Works with 4421A Power Meter or 4421B540-2 Interface Adapter. Supplied with N female connectors by default. Other connectors from the QC range may be ordered as factory-fit options.
Precision Power Sensors 4027A Series 1% accuracy on calibrated frequency and power level. 2% accuracy over stated range. Supplied with N female connectors by default. Other connectors from the QC range may be ordered as factory-fit options.
Precision Power Sensors 4027F Series 1% accuracy on calibrated frequency and power level. 2% accuracy over stated range. Works with 4421A Power Meter or 4421B540-2 Interface Adapter. Integral filtering minimises effects of harmonics and modulation. Supplied with N female connectors by default. Other connectors from the QC range may be ordered as factory-fit options.
Precision Power Sensors 4028 Series 2% accuracy on calibrated frequency and power level. 3% accuracy over stated range. Works with 4421A Power Meter or 4421B540-2 Interface Adapter.
Precision Power Sensors 4421A Power Meter One or two sensor inputs (factory option). Optional RS-232 interface (factory option). Displays forward power in W or dBm. Displays reflected power in W or dBm. Displays VSWR, Return Loss or Reflection Coefficient. Graphical display of power versus time. Serial command protocol available on request.
Precision Power Sensors 4421B540-2 Interface Converter Converts interface of 402x Series sensor to USB or RS-232. Allows 402x Series to be used with VPM3 virtual power meter software for Windows . Allows remote control of 402x Series sensor over RS-232 serial interface. Serial command protocol available on request. Includes universal AC power supply.
