1. P2P Systems: Gossip Protocols CS 6410 By Alane Suhr & Danny Adams 1

2. Outline Timeline CAP Theorem Epidemic algorithms for replicated database maintenance Managing update conflicts in Bayou, a weakly connected replicated storage system Conclusion 2 A

3. Timeline 1978 1982 1985 1987 1990 1995 1998 Lamport Lamport FLP Demers Schneider Terry Lamport Implementing fault-tolerant services using the state machine approach: A tutorial The part-time parliament Time, Clocks, and the Ordering of Events in a Distributed System The Byzantine Generals Problem Impossibility of Distributed Consensus with One Faulty Process Epidemic algorithms for replicated database maintenance Managing update conflicts in Bayou, a weakly connected replicated storage system 3 A

4. CAP Consistency -- all nodes contain the same state Availability -- requests are responded to promptly Partition part of a system completely independent from the rest of the system ideally should maintain itself autonomously Partition tolerance -- system can stay online and functional even when message passing fails 4 A

5. CAP Theorem Paxos: prioritize consistency given a network partition Gossip: prioritize availability given a network partition Paxos & Gossip 5 A

6. Gossip 6 6 D

7. Gossip Overview Authors Motivations Epidemic Models Direct Mail Anti-Entropy Rumor mongering Evaluation DC s Spatial Distribution 7 D

8. A u t h o r s Carl Hauser PhD Cornell Washington State University Alan Demers Cornell University Dan Greene PARC Research Scott Shenker EECS Berkeley Doug Terry Amazon Web Services 8 D

9. Motivations Unreliable network Unreliable nodes CAP: *AP* always be able to respond to a (read/write) request eventual consistency 9 D

10. Epidemic Models 10 A

11. Proposers and Acceptors Proposer In Paxos: clients propose an update to the database Epidemic model: a node infects its neighbors Acceptor In Paxos: acceptor accepts an update based on one or more proposals Epidemic model: a node is infected by a neighbor 11 A

12. Types of Epidemics Direct Mail Anti-Entropy Rumor Mongering A 12

13. Advantages Simple algorithms High Availability Fault Tolerant Tunable Scalable Works in Partition 13 A

14. Notify all neighbors of an update Timely and reasonably efficient n messages per update Direct Mail 14 D

15. Direct Mail 15 D

16. Direct Mail 16 D

17. Direct Mail Messages sent: O(n) where n is number of neighbors Not fault tolerant -- doesn t guarantee eventual consistency High volume of traffic with site at the epicenter 17 D

18. Anti-Entropy Site chooses random partner to share data Number of rounds til consistency: O(log n) Sites use custom protocols to resolve conflicts Fault tolerant 18 A

19. Anti-Entropy 19 A

20. Anti-Entropy 20 A

21. Anti-Entropy 21 A

22. Anti-Entropy 22 A

23. Anti-Entropy 23 A

24. Anti-Entropy 24 A

25. Anti-Entropy 25 A

26. Anti-Entropy 26 A

27. Anti-Entropy What happens next? 27 A

28. Mechanism: Push & Pull 28 D

29. Push vs. Pull Push Pull {A, B} {A, C} {A, B} {A, C} H(A), H(B) H(A), H(B) H(B C B {A, B} {A,B,C} {A, B, C} {A, C} 29 D

30. {A, B} {A, C} What is Push-Pull? H(A), H(B) C, H(B) B 30 {A, B, C} {A,B,C} D

31. Propagation times of Push vs. Pull Push: Pi+1 = Pie-1 Pull: Pi+1= Pi2 Pull is faster!! P= Probability node hasn t received update after the ithround 31 D

32. Rumor Mongering Sites choose a random neighbor to share information with Transmission rate is tuneable 1. How long new updates are interesting is also tuneable 2. Can use push or pull mechanisms 32 A

33. Rumor Mongering Complexity O(ln n) rounds leads to consistency with high probability Push requires O(n ln n) transmissions until consistency Further proved lower bound for all push- pull transmissions: 0(n ln ln n) 33 Karp et al 2000. Randomized rumor spreading. In FOCS. A

34. Analogy to epidemiology Susceptible: site does not know an update yet Infective: actively sharing an update Removed: updated and no longer sharing Rumor mongering: nodes go from susceptible to infective and eventually (probabilistically) to removed 34 A

35. Rumor mongering 35 A

36. Rumor mongering 36 A

37. Rumor mongering 37 A

38. Rumor mongering 38 A

39. Rumor mongering 39 A

40. Rumor mongering 40 A

41. Rumor mongering A 41 A

42. Rumor mongering Pros: Cons: Fast Low call on resources Fault-Tolerant Less traffic A site can potentially miss an update 42 A

43. Backups Anti-entropy can be used to update the network regularly after direct mail or rumor mongering If inconsistency found in anti- entropy, run the original algorithm again 43 D

44. Death Certificates How are items deleted using epidemic models? 44 D

45. I DONT like Bread! I like Bread System Update I like orange juice 45 D

46. Death Certificates How to remove items from epidemic model? Drawbacks Space Increases traffic DC Can be lost 46 Dormant death D

47. Evaluating Epidemic Models Residue: remaining susceptibles when epidemic finishes Traffic: Delay: Tavg: Average time between start of outbreak and arrival of update @ given site Tlast: Delay until last update 47 D

48. Spatial Distribution Helping Or Hurting 48 A

49. Convergence Times and Traffic Linear network: anti entropy Nearest-neighbors O(n) convergence O(1) traffic Random connections O(log(n)) convergence O(n) traffic 49 A

50. Optimizations for realistic network distributions Select connections from list of neighbors sorted by distance Treat network as linear Compute probabilities based on position in list 50 A
