Lecture-3
Types of lasers
He-Ne Laser
Laser Types
•
According to the
active material
:
solid-state, liquid, gas, excimer or semiconductor
lasers.
Gas:
HeNe laser, excimer lasers, CO
2
lasers
Liquid:
dye lasers
Solid:
Nd:YAG laser, Ti:sapphire laser
Diode (semiconductor) lasers
.
According to the
wavelength
:
infra-red, visible, ultra-violet (UV) or x-ray lasers.
Types of Laser
Based on the mode of operation
(i) Pulsed Laser systems
(ii) Q-switched systems
(iii) Continuous wave Laser systems
Based on the mechanism in which Population Inversion is achieved
(i) Three level lasers
(ii) Four level lasers
Based on state of active medium used
(i) Gas Laser
(ii) Solid state Laser
(iii) Semiconductor Laser
(iv) Tunable dye Laser
Types of Laser
•
Gas Laser: He-Ne, Argon ion and CO
2
•
Solid state Laser : Ruby, Nd:YAG, Nd:glass
•
Semiconductor Laser
•
Tunable dye Laser
Helium-neon Laser
It was
invented by Javan et. al. in 1961 and his
coworkers at Bell Telephone Laboratories
Introduction
•
A helium-neon laser (He-Ne laser) is a type of small gas laser.
HeNe lasers have many industrial and scientific uses, and are
often used in laboratory demonstrations of optics.
•
He-Ne laser is a four-level laser.
•
Its usual operation wavelength is
6328Å
in the red portion of
the visible spectrum.
•
This was the first gas laser to be operated successfully.
Construction of He-Ne laser
•
This consists of a mixture of helium and neon gases in a ratio of
about 10:1
•
The setup consists of a discharge tube of length 80 cm and bore
diameter of 1.5cm.
•
The pressure inside the tube is about 1mm of Hg.
•
The energy or pump source of the laser is provided by an electrical
discharge of around 1000 volts through an anode and cathode at
each end of the glass tube. A current of 5 to 100 mA is typical for
CW operation.
•
The optical cavity of the laser typically consists of a plane, high-
reflecting mirror at one end of the laser tube, and a partially
transparent mirror of approximately 1% transmission at the other
end.
Schematic of a Helium-Neon Laser
Working of He-Ne Laser
•
Electric discharge is passed through the gas. As electrons have a smaller
Electric discharge is passed through the gas. As electrons have a smaller
mass than ions, they acquire a higher velocity.
mass than ions, they acquire a higher velocity.
•
The He atoms are more readily excitable than Neon as they are lighter.
The He atoms are more readily excitable than Neon as they are lighter.
•
Electrons collides with the He atoms, excite them to the metastable states
Electrons collides with the He atoms, excite them to the metastable states
and stay for a sufficiently long time.
and stay for a sufficiently long time.
•
The excited He atoms losses energy through collision with unexcited Ne
The excited He atoms losses energy through collision with unexcited Ne
atoms, Ne atoms are excited to the metastable states
atoms, Ne atoms are excited to the metastable states
which have nearly the same energy as the levels of of He.
which have nearly the same energy as the levels of of He.
•
The probability of energy transfer from He atoms to Neon atoms is more
The probability of energy transfer from He atoms to Neon atoms is more
as there are 10 He atoms to 1Neon atoms in the medium
as there are 10 He atoms to 1Neon atoms in the medium
•
Population inversion is achieved between
Population inversion is achieved between
•
transition generates a laser beam of red colour of wavelength
transition generates a laser beam of red colour of wavelength
6328Å
•
transition produces laser beam of wavelength
transition produces laser beam of wavelength
1.15µm
1.15µm
(not in visible
(not in visible
region)
region)
•
transition results in a laser beam of
transition results in a laser beam of
3.39µm
3.39µm
(not in visible region)
(not in visible region)
•
transition generates incoherent light due to spontaneous emission
transition generates incoherent light due to spontaneous emission
(~6000Å)
(~6000Å)
•
From the level , the Ne atoms are brought back to the ground state through
From the level , the Ne atoms are brought back to the ground state through
collisions with the walls
collisions with the walls
•
Also since level is a metastable state , can decrease the population inversion by
Also since level is a metastable state , can decrease the population inversion by
exciting atoms f rom . Hence the tube is made narrow so that Ne atoms in
exciting atoms f rom . Hence the tube is made narrow so that Ne atoms in
level de-excite by collision with the walls of the tube.
level de-excite by collision with the walls of the tube.
•
By a proper design of resonator , laser action in Ne is obtained in the visible region
By a proper design of resonator , laser action in Ne is obtained in the visible region
(
(
6328Å)
Applications of He-Ne laser
•
The Narrow red beam of He-Ne laser is used in supermarkets
The Narrow red beam of He-Ne laser is used in supermarkets
to read bar codes.
to read bar codes.
•
The He- Ne Laser is used in Holography in producing the 3D
The He- Ne Laser is used in Holography in producing the 3D
images of objects.
images of objects.
•
He-Ne lasers have many industrial and scientific uses, and are
He-Ne lasers have many industrial and scientific uses, and are
often used in laboratory demonstrations of optics.
often used in laboratory demonstrations of optics.
Helium-neon lasers are widely used in various industries and scientific settings. They are classified based on active materials, wavelengths, and operational modes. The He-Ne laser, invented in 1961, operates at a red wavelength of 6328nm. Its construction involves a mixture of helium and neon gases with specific pressure and discharge mechanisms. The laser cavity includes mirrors for optimal light reflection.
Download Presentation
Please find below an Image/Link to download the presentation.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.
E N D
Presentation Transcript
Lecture-3 Types of lasers He-Ne Laser
Laser Types According to the active material: solid-state, liquid, gas, excimer or semiconductor lasers. Gas: HeNe laser, excimer lasers, CO2lasers Liquid:dye lasers Solid: Nd:YAG laser, Ti:sapphire laser Diode (semiconductor) lasers . According to the wavelength: infra-red, visible, ultra-violet (UV) or x-ray lasers.
Types of Laser Based on the mode of operation (i) Pulsed Laser systems (ii) Q-switched systems (iii) Continuous wave Laser systems Based on the mechanism in which Population Inversion is achieved (i) Three level lasers (ii) Four level lasers Based on state of active medium used (i) Gas Laser (ii) Solid state Laser (iii) Semiconductor Laser (iv) Tunable dye Laser
Types of Laser Gas Laser: He-Ne, Argon ion and CO2 Solid state Laser : Ruby, Nd:YAG, Nd:glass Semiconductor Laser Tunable dye Laser
Helium-neon Laser It was invented by Javan et. al. in 1961 and his coworkers at Bell Telephone Laboratories
Introduction A helium-neon laser (He-Ne laser) is a type of small gas laser. HeNe lasers have many industrial and scientific uses, and are often used in laboratory demonstrations of optics. He-Ne laser is a four-level laser. Its usual operation wavelength is 6328 in the red portion of the visible spectrum. This was the first gas laser to be operated successfully.
Construction of He-Ne laser This consists of a mixture of helium and neon gases in a ratio of about 10:1 The setup consists of a discharge tube of length 80 cm and bore diameter of 1.5cm. The pressure inside the tube is about 1mm of Hg. The energy or pump source of the laser is provided by an electrical discharge of around 1000 volts through an anode and cathode at each end of the glass tube. A current of 5 to 100 mA is typical for CW operation. The optical cavity of the laser typically consists of a plane, high- reflecting mirror at one end of the laser tube, and a partially transparent mirror of approximately 1% transmission at the other end.
Working of He-Ne Laser Electric discharge is passed through the gas. As electrons have a smaller mass than ions, they acquire a higher velocity. The He atoms are more readily excitable than Neon as they are lighter. Electrons collides with the He atoms, excite them to the metastable states and stay for a sufficiently long time. The excited He atoms losses energy through collision with unexcited Ne atoms, Ne atoms are excited to the metastable states which have nearly the same energy as the levels of of He. The probability of energy transfer from He atoms to Neon atoms is more as there are 10 He atoms to 1Neon atoms in the medium Population inversion is achieved between transition generates a laser beam of red colour of wavelength 6328 transition produces laser beam of wavelength 1.15 m (not in visible region) transition results in a laser beam of 3.39 m (not in visible region) 19 ( 81 . ) ( 20 61 . ) F eV and F eV 2 3 18 ( 7 . F ) ( 20 66 . ) E and eV and E eV 4 6 F 2 3 , , E and E E andE E and E 6 5 6 3 4 3 E E 6 3 E E 4 3 E E 6 5
E E transition generates incoherent light due to spontaneous emission (~6000 ) 3 2 From the level , the Ne atoms are brought back to the ground state through collisions with the walls E 2 2 E Also since level is a metastable state , can decrease the population inversion by exciting atoms f rom . Hence the tube is made narrow so that Ne atoms in level de-excite by collision with the walls of the tube. 2 E E to E 2 3 By a proper design of resonator , laser action in Ne is obtained in the visible region (6328 )
Applications of He-Ne laser The Narrow red beam of He-Ne laser is used in supermarkets to read bar codes. The He- Ne Laser is used in Holography in producing the 3D images of objects. He-Ne lasers have many industrial and scientific uses, and are often used in laboratory demonstrations of optics.
