1. PNF Pre Onboarding and Onboarding Use Cases in ONAP Dublin Release Ericsson, Michela Bevilacqua 2018/11/15

2. Background: PNF Plug and Play in Casablanca Release This use case covers in Casablanca: - PNF definition at design time - PNF instantiation in ONAP at run time (including initial configuration). This use case today does not cover the PNF onboarding - The onboarding process of a vendor PNF archive including a PNF descriptor and a set of artifacts.

3. UCs for Dublin Release PNF Pre-Onboarding Use Case: - PNF package/archive shall be pre-onboarded and verified by VNF SDK tools - This UC shall be aligned as much as possible to the ONAP VNF package pre-onboarding UC - PNF archive is provided by a vendor and it will include PNFD (based on ETSI SOL004) and all the artifacts required by ONAP (non ETSI NFV artifact provided managed as Non-MANO artifact (i.e. FM and PM dictionary) PNF Onboarding Use Case: - PNF archive can be onboarded through ONAP - ONAP SDC shall also continue to support PNF definition by UI as in Casablanca Release

4. Impacted components per UC PNF pre-onboarding UC: - VNF SDK: Agree the list of artifacts provided by a vendor in Dublin timeframe, approve the format of Non-MANO artifacts Evaluate any impact in order to support Non-MANO artifacts in a Package PNF Onboarding UC : - Onboarding Data Model definition - SDC: Enable PNF package and TOSCA descriptor onboarding to be used also for vCPE UC Additional Non-MANO artifact onboarding and distribution

5. VNF and PNF onboarding and internal dependencies in Casablanca Onboarding Design Time Pre-onboarding SDNC/APPC/ multiVIM VNF SDK SDC SO VFC VNF SOL001 VOLTE workflow VNFD ETSI SOL001 based vendor VNF CSAR vCPE CreateVcpeWorkflow Heat template VNF heat template VNF AID AI vCPE Create&ActivateWorkflow PNF defined by UI PNF AID AID

6. Montreal F2F proposal Quick and Dirty Path for Dublin There is a request for support of these selected typed from SOL001 v2.5.1 Type Comment tosca.nfv.nodes.PNF New; To be discussed tosca.nfv.nodes.NS, tosca.nodes.NS.VirtualLink.SAP New; To be discussed; ETSI community wants to better understand the ONAP Service node type VNF, VnfExtCp, Vdu.Compute, VirtualBlockStorage, VirtualObjectStorage, VirtualFileStorage, Cp, VduCp, VnfVirtualink Already supported; Need an update to align with the latest version of SOL001 Communicate to the PTLs: SDC, SO, AI&I, VID(?), etc. Policy: InstantiationLevels, VduInstantiationLevels, VirtualLinkInstantiationLevels New; To be discussed Policy: scaling New; To be discussed Policy: affirnityRule, antiAffirntyRule New; To be discussed Data types to support all of the above Some new, some to be updated 6

7. VNF onboarding and internal dependencies in Dublin Pre-onboarding Onboarding Design Time SDNC/APPC/ multiVIM VNF SDK SDC SO VFC SDC VNF CSAR VOLTE workflow VNFD, PNFD, NSD ETSI SOL001 vendor VNF CSAR vCPE workflow Heat template VNF heat template SDC VNF CSAR

8. VNF and PNF onboarding and internal dependencies in Dublin Pre-onboarding Onboarding Design Time VNF SDK SDC SO SDNC/APPC VFC PNF SOL001 VOLTE workflow VNFD, PNFD, NSD ETSI SOL001 VNF SOL001 vendor PNF CSAR vendor VNF CSAR vCPE workflow Heat template VNF heat template TOSCA AID VNF vCPE Creat&ActWorkflow PNF defined by UI TOSCA AID PNF AID
