Network Management Processes in Computer Networks

ITEC 275

ITEC 275

 Computer Networks – Switching, Routing, and

 Computer Networks – Switching, Routing, and

WANs

WANs

Week 9

Week 9

Robert D’Andrea

Robert D’Andrea

Winter 2018

Winter 2018

Agenda

Agenda

•

Learning Activities

–

Network Management Processes

•

Syslog

–

Network Management Architectures

–

Network Management Tools and Protocols

–

Campus Cabling

–

Ethernet

–

Campus Network Design Example

Network Management Processes

Network Management Processes

•

International Organization for Standardization

(ISO) defines five types of network processes

–

Fault management

–

Configuration management

–

Accounting management

–

Performance management

–

Security management

Network Management Processes

Network Management Processes

•

Fault management refers to detecting, isolating,

diagnosing, and correcting problems.

- Develop a workaround(s)

- Test the workaround(s)

- Document the workaround(s) in a problem-

 tracking database

- Utilize monitoring tools to alert managers,

protocol analyzers and Wire Shark for fault

resolution

- Syslog network contains timestamp, level,

and facility. Syslog severity levels are

provided

Syslog is a standard for computer message logging.

Syslog can be used for computer system

management and security auditing as well as

generalized informational, analysis, and debugging

messages. It is supported by a wide variety of

devices (like printers and routers) and receivers

across multiple platforms. Because of this, syslog

can be used to integrate log data from many

different types of systems into a central repository.

Network Management Processes

Network Management Processes

Network Management Processes

Network Management Processes

Syslog is a standard for computer message logging.

/var/log>ls

anaconda.log                        messages-20151004

anaconda.program.log         messages-20151011

anaconda.storage.log           messages-20151018

anaconda.syslog                  messages-20151025

anaconda.xlog                     mysqld.log

anaconda.yum.log               ntpstats

audit                                    ppp

boot.log                               prelink

boot.log-20151004             RPM-GPG-KEY-EPEL

boot.log-20151011             RPM-GPG-KEY-EPEL-6.pub

boot.log-20151018             sa

boot.log-20151025             salt

btmp                                   secure

btmp-20151001                 secure-20150809.gz

Network Management Processes

Network Management Processes

•

Syslog is a standard for computer message logging.

/var/log>ls

client-config-overrides.txt   secure-20150816.gz

client_config_update.py      secure-20150823.gz

ConsoleKit                           secure-20150830.gz

cron                                      secure-20151004

cron-20140921.gz                secure-20151011

cron-20140928.gz                secure-20151018

cron-20141005.gz                secure-20151025

cron-20141012.gz                spooler

cron-20151004                    spooler-20151004

cron-20151011                    spooler-20151011

cron-20151018                    spooler-20151018

cron-20151025                    spooler-20151025

cups                                     sssd

dmesg                                  tallylog

dmesg.old                            up2date

Network Management Processes

Network Management Processes

•

Syslog is a standard for computer message logging.

/var/log>ls

httpd

up2date-20151004

lastlog

up2date-20151011

mail

up2date-20151018

maillog

up2date-20151025

maillog-20150809.gz      VMWARE-PACKAGING-GPG-DSA-KEY.pub

maillog-20150816.gz       vmware-tools-guestd

maillog-20150823.gz       wtmp

maillog-20150830.gz        wtmp-20150901

maillog-20151004             yum.log

maillog-20151011             yum.log-20120101

maillog-20151018             yum.log-20130101

maillog-20151025             yum.log-20140101

messages

 yum.log-20150101

Network Management Processes

Network Management Processes

Most syslog messages are found on Unix-

like operating systems under the /var/log

directory.

anaconda.log

sssd

boot.log

dmesg

RPM-GPG-KEY-EPEL

httpd

ppp

spooler-20150208

mysqld.log

cron-20140921.gz

yum.log

maillog

cups

audit

Network Management Processes

Network Management Processes

Anaconda is the installation program used by

Fedora, Red Hat Enterprise Linux.

During an installation, a target computer's hardware

is identified and configured and the appropriate file systems

for the system's architecture are created. Finally, Anaconda

allows the user to install the operating system software on

the target computer.

Anaconda can also upgrade existing installations of

earlier versions of the same distribution. After the

installation is complete, you can reboot into your installed

system and continue doing customization using the initial

setup program.

Network Management Processes

Network Management Processes

Syslog

Messaging

Levels

- Emergency (level 0)

- Alert (level 1)

- Critical (level 2)

- Error (level 3)

- Warning (level 4)

- Notice (level 5)

- Information (level 6)

- Debugging (level 7)

Network Management Processes

Network Management Processes

Syslog Messages

- Sent to Cisco router or switch consoles

- Sent to Network Management Station

- Sent to a remote network host where a

syslog analyzer is installed.  A syslog

analyzer distributes these messages

appropriately to the network node

manager, and management.

Network Management Processes

Network Management Processes

•

Configuration Management helps the network

manager maintain a list of devices and

information installed on those devices.

- Version-logging refers to keeping track of

the version of operating systems or

applications running on network

devices.

- Change management includes DHCP and

VLAN Trunk Protocol (VTP)

automatically updates switches with

VLAN information.

Network Management Processes

Network Management Processes

Network Management Processes

Network Management Processes

Dynamic Host Configuration Protocol

(DHCP) allows for manual and automatic

assignment of IP addresses (see IETF RFC 2131

& 2132). DHCP is enacted when a new machine

joins a network or an existing machine attempts to

renew its IP address. DHCP is an extension of an

older protocol known as the "bootstrap protocol"

(BOOTP) and is backwards compatible with

BOOTP. There are three methods of IP address

allocation:

Network Management Processes

Network Management Processes

Manual:

 An administrator manually assigns the

IP address; tedious but most secure

method.

Automatic:

DHCP server assigns permanent IP

address to requesting client.

Dynamic:

DHCP server "leases" IP address to

requesting client. The IP address is only

valid for a limited period of time; after

which the client must request a renewal or

ask for a new IP address.

Network Management Processes

Network Management Processes

•

Accounting management

- Facilitates usage-based billing. If

money is not exchanged, it identifies

consumption and possibly “abuse” of

network resources.

Network Management Processes

Network Management Processes

•

Performance management

- Facilitates measurement of network

behavior and effectiveness.

-Examine network applications

- Protocol behavior

- End-to-end performance across an

internetwork

- Component performance of individual

links or devices.

Network Management Processes

Network Management Processes

Security Management allows the network

management to maintain and distribute passwords

and other authentication information. Security

management should also include generating,

distributing, and storing encryption keys.

–

 Audit logs should document logins and logouts

–

Attempts by individuals to change their level of

authorization.

–

Compressing data rather than storing less data

Network Management Architectures

Network Management Architectures

Managed device:

Routers, servers, switches,

bridges, hubs, end systems, or printers.

Agent:

Network management software that

resides in a managed device.

Network management system (NMS):

Is a

terminal with software that displays

management data, monitor and controls

managed devices, and communicates with

agents. Typically located in a network

operations center (NOC).

Network Management Architectures

Network Management Architectures

•

In-band monitoring is network management

data that travels across an internetwork using

the same paths as user traffic.

- Impacts ability to trouble shoot problems

•

Out-of-band monitoring

- More complex and expensive

- Analog lines are used for backup

- Security risks with analog links need a

callback mechanisms

Network Management Architectures

Network Management Architectures

Centralized monitoring architecture all

NMSs reside in one place of the network

.

Distributed monitoring means the NMSs and

agents are spread out across the entire

internetwork. Distributed monitoring involves a

more complex network configuration and tends to

be harder to manage.

Manage-of-managers (MoM) is a distributed

arrangement with a central NMS. The central

NMS manages the distributed locations.

Network Management Tools and Protocols

Network Management Tools and Protocols

A network management solution should include

tools to isolate, diagnose, and report problems and to

expedite recovery and quick repair.

–

Interfaces can be CLI, GUI, and different browsers

–

SMNPv3 should gradually replace versions 1 and 2

because it offers better security, authentication to

protect against modification of information, and

secure set operations for the remote configuration

of SNMP managed devices.

Network Management Tools and Protocols

Network Management Tools and Protocols

•

Management Information Bases (MIB) stores

information from local management agent on a

managed device.

- Each object in a MIB has a unique

identifier.

- Network management applications use the

identifier to retrieve a specific object.

- A MIB is a structured tree and

hierarchical structure.

Network Management Tools and Protocols

Network Management Tools and Protocols

The MIB structure is logically represented

by a tree hierarchy. The root of the tree is

unnamed and splits into three main branches:

1. Consultative Committee for International

Telegraph and Telephone (CCITT),

2. International Organization for

Standardization (ISO),

3. Joint ISO/CCITT.

Network Management Tools and Protocols

Network Management Tools and Protocols

These branches and those that fall below

each category have short text strings and integers

to identify them. Text strings describe object

names, while integers allow computer software to

create compact, encoded representations of the

names. For example, the Cisco MIB variable

authAddr is an object name and is denoted by

number 5, which is listed at the end of its object

identifier number 1.3.6.1.4.1.9.2.1.5.

Network Management Tools and Protocols

Network Management Tools and Protocols

The object identifier in the Internet MIB

hierarchy is the sequence of numeric labels on the

nodes along a path from the root to the object. The

Internet standard MIB is represented by the object

identifier 1.3.6.1.2.1. It also can be expressed as

iso.org.dod.internet.mgmt.mib.

Internet MIB Hierarchy

Internet MIB Hierarchy

Network Management Tools and Protocols

Network Management Tools and Protocols

RMON Monitoring (RMON) developed to

close the gap in the standard MIBs which lacked

the capability to provide statistics on the data link

and physical layer parameters. The IETF

developed RMON MIB to provide Ethernet traffic

statistics and fault diagnosis.

- RMON collects CRC errors

- Packet-size distribution

- Number of packets in and out

Network Management Tools and Protocols

Network Management Tools and Protocols

What does RMON support?

-

A

llows the network manager set

thresholds for network parameters

-

C

onfigures agents to automatically

deliver

alerts to NMS.

-

C

apturing packets and sending the captured

packets to the MNS for

protocol analysis.

-

P

rovides information about the

health and performance of the network

segment.

Network Management Tools and Protocols

Network Management Tools and Protocols

•

Cisco Discovery Protocol (CDP)

- Specifies a method for Cisco routers and

switches to send configuration

information to each other on a regular basis.

- CDP runs on the data link layer

- Utilizes Sub Network Access Protocol (SNAP)

SNAP is the data-link address used in IS-IS protocol to

reach the neighbor on a broadcast media. This is

comparable to Ethernet links using the Mac Address of

the neighbor.

Network Management Tools and Protocols

Network Management Tools and Protocols

By default, CDP announcements are sent every

60 seconds on interfaces that support Sub Network

Access Protocol (SNAP) headers,

including Ethernet, Frame

Relay and Asynchronous

Transfer Mode (ATM). Each Cisco device that

supports CDP stores the information received from

other devices in a table that can be viewed using

the show CDP neighbors command. This table is also

accessible via SNMP. CDP frames are sent every 60

seconds. Switches and routers do not forward CDP

frames.

Network Management Tools and Protocols

Network Management Tools and Protocols

 View: Cisco CPD configuration video

http://www.youtube.com/watch?v=l9zfWyS0Bn8

Network Management Tools and Protocols

Network Management Tools and Protocols

•

Cisco NetFlow Accounting

–

Collects and measures data as it enters router or

switch interfaces. The information enables a

network manager to characterize utilization of

network and application resources.

–

Helps network manager visualize traffic patterns so

that proactive problems can be detection is

possible.

–

NetFlow allows a network manager to gain a

detailed, time-based view of application usage.

Selecting Technologies and Devices

Selecting Technologies and Devices

•

We now know what the network will look like.

•

We also know what capabilities the network

will need.

•

We are now ready to start picking out

technologies and devices.

•

Chapter 10 has guidelines for campus networks.

Campus Network Design Steps

Campus Network Design Steps

•

Develop a cabling plant

design

•

Select the types of cabling

•

Select the data-link-layer

technologies

•

Select internetworking devices

•

Meet with vendors

Cabling Plant Design Considerations

Cabling Plant Design Considerations

•

Campus and building cabling topologies

•

The types and lengths of cables between buildings

•

Within buildings

–

The location of telecommunications closets and cross-

connect rooms

–

The types and lengths of cables for vertical cabling

between floors

–

The types and lengths of cables for horizontal cabling

within floors

–

The types and lengths of cables for work-area cabling

going from telecommunications closets to workstations

Centralized Versus Distributed Cabling

Centralized Versus Distributed Cabling

Topologies

Topologies

•

A centralized cabling scheme terminates

most or all of the cable runs in one area of

the design environment. A star topology is an

example of a centralized system.

•

A distributed cabling scheme terminates

cable runs throughout the design

environment. Ring, bus, and tree topologies

are examples of distributed systems.

Centralized Campus Cabling

Centralized Campus Cabling

Cable Bundle

Building B

Building C

Building D

Centralized Campus Cabling

Centralized Campus Cabling

Distributed Campus Cabling

Distributed Campus Cabling

Types of Media Used in Campus Networks

Types of Media Used in Campus Networks

•

Copper media

•

Optical media

•

Wireless media

Copper Media Advantages

Copper Media Advantages

•

Conducts electric current well

•

Does not rust

•

Can be drawn into thin wires

•

Easy to shape

•

Hard to break

C

o

p

p

e

r

M

e

d

i

a

Coaxial

Twisted-Pair

Unshielded Twisted-Pair (UTP)

Coaxial Cable

Coaxial Cable

•

Solid copper conductor, surrounded by:

–

Flexible plastic insulation

–

Braided copper shielding

–

Outer jacket

•

Can be run without as many boosts from

repeaters, for longer distances between

network nodes, than either STP or UTP

cable

–

Nonetheless, it’s no longer widely used

Twisted-Pair Cabling

Twisted-Pair Cabling

•

A “twisted pair” consists of two copper

conductors twisted together

•

Each conductor has plastic insulation

•

Shielded Twisted Pair (STP)

–

Has metal foil or braided-mesh covering that

encases each pair

•

Unshielded Twisted Pair (UTP)

–

No metal foil or braided-mesh covering around

pairs, so it’s less expensive

UTP Categories

UTP Categories

•

Category 1.

Used for voice communication

•

Category 2.

 Used for voice and data, up to 4 Mbps

•

Category 3.

 Used for data, up to 10 Mbps

–

Required to have at least 3 twists per foot

–

Standard cable for most telephone systems

–

Also used in 10-Mbps Ethernet (10Base-T Ethernet)

•

Category 4.

 Used for data, up to 16 Mbps

–

Must also have at least 3 twists per foot as well as other

features

•

Category 5.

 Used for data, up to 100 Mbps

–

Must have 3 twists per

inch

!

•

Category 5e.

 Used in Gigabit Ethernet

•

Category 6.

 Used in Gigabit Ethernet and future technologies

Types of Cables

Types of Cables

•

Mode is an allowable path for light to travel

down a fiber.

•

Multimode fiber has multiple modes or paths

that light can follow. All paths are not equal.

some are longer, and the time it takes to travel

down each path more time consuming.

•

Single mode contains a small core diameter, has

one path, supports higher bandwi

d

th rate over

longer distances.

O

p

t

i

c

a

l

M

e

d

i

a

Multimode Fiber (MMF)

Single-mode Fiber (SMF)

Copper Vs Fiber-Optic Cabling

Copper Vs Fiber-Optic Cabling

•

Twisted-pair and coax cable transmit network signals

in the form of current

•

Fiber-optic cable transmits network signals in the

form of light

•

Fiber-optic cable is made of glass

–

Not susceptible to electromagnetic force (EMF) or radio

frequency interference

–

Not as susceptible to attenuation, which means longer

cables are possible

–

Supports very high bandwidth (10 Gbps or greater)

–

For long distances, fiber costs less than copper

Multimode        Single-mode

Multimode        Single-mode

•

Larger core diameter

•

Beams of light bounce

off cladding in multiple

ways

•

Usually uses LED source

•

Shorter distances

•

Less expensive

•

Smaller core diameter

•

Less bouncing around;

single, focused beam of

light

•

Usually uses LASER

source

•

More expensive

•

Very long distances

LED

LED

Definition: A light-emitting diode

(LED) is a two-

lead semiconductor light source. It resembles a

basic pn-junction diode, which emits light when

activated

Single/Multi-Mode Fiber

Single/Multi-Mode Fiber

Multi-Mode Fiber

Multi-Mode Fiber

Ethernet

Ethernet

•

STP is shielded twisted pair cabling.

•

UTP is unshielded twisted pair cabling.

Typically found in buildings. Generally , least

expensive, lowest transmission capabilities

because it is subject to crosstalk, noise, and

EMI (Electromagnetic Interference).

•

Coax cabling was popular in the 1980s and

1990s. Not used or installed as it was in the

recent past.

Electromagnetic Interference (EMI)

Electromagnetic Interference (EMI)

Internet Cables

Internet Cables

Internet Cables

Internet Cables

Just when you thought it was safe to run

internet cables in the water, it appears sharks have

developed the taste for data.

Video of shark biting under water cable

https://youtu.be/1ex7uTQf4bQ

Ethernet

Ethernet

•

Ethernet is a physical and data link layer

standard for the transmission of frames on a

LAN.

- IEEE802.3 has evolved to support UTP and

fiber-optic cabling, and fast

transmission speeds.

- Gigabit Ethernet is targeted for the core

layer on enterprise systems.

Wireless Media

Wireless Media

•

IEEE 802.11a, b, g, n

•

Laser

•

Microwave

•

Cellular

•

Satellite

Cabling Guidelines

Cabling Guidelines

•

At the access layer use

–

Copper UTP rated for Category 5 or 5e, unless

there is a good reason not to

o

–

To future proof the network

•

Use 5e instead of 5

•

Install UTP Category 6 rated cable and terminate the

cable with Cat 5 or 5e connectors

•

Then only the connectors need to be changed to

move up in speed

–

In special cases

•

Use MMF (Multimode Fiber) for bandwidth

intensive applications

•

Or install fiber along with the copper

Cabling Guidelines

Cabling Guidelines

•

At the distribution layer use

–

MMF (Multi mode fiber) if distance allows

–

SMF (Single mode fiber) otherwise

–

Unless unusual circumstances occur and cable

cannot be run, then use a wireless method

–

To future proof the network

•

Run both MMF and SMF

LAN Technologies

LAN Technologies

•

Half-duplex Ethernet (becoming obsolete)

•

Full-duplex Ethernet

•

10-Mbps Ethernet (becoming obsolete)

•

100-Mbps Ethernet

•

1000-Mbps (1-Gbps or Gigabit) Ethernet

•

10-Gbps Ethernet

•

Metro Ethernet

•

Long Range Ethernet (LRE)

•

Cisco’s EtherChannel

10 Mbps Ethernet

10Base5

10Base2

10BaseF

Thick coax cable

500 meters

Thin coax cable

185 meters

10BaseT

2 pairs Category-

3 or better UTP

100 meters

 IEEE 802.3 10-Mbps Ethernet

2 multimode

optical fibers

10Broad36

3 channels of a private

CATV system 3600

meters

100BaseT

100BaseTX

100BaseFX

100BaseT2

2 pairs Category-5 or

better UTP            100

meters

2 multimode optical fibers

2000 meters (full duplex)

100BaseT4

4 pairs Category-

3 or better UTP

100 meters

 IEEE 802.3 100-Mbps Ethernet

2 pairs Category-

3 or better UTP

100 meters

1000BaseX

1000BaseSX

1000BaseLX

1000BaseT

2 multimode optical fibers

using shortwave laser optics

550 meters

2 multimode or single-mode

optical fibers using longwave

laser optics

550 meters multimode, 5000

meters single-mode

4 pairs Category-5 UTP

100 meters

1000BaseCX

2 pairs STP    25

meters

 IEEE 802.3 Gigabit Ethernet

10GBase with Fiber Cabling

10GBaseLX4

10GBaseSR

10GBaseER

Multimode or single-mode

optical fibers

 300 meters multimode,       10

km single-mode

Multimode optical

fibers                   300

meters

Single-mode

optical fibers 40

km

10GBaseLR

Single-mode

optical fibers

10 km

 IEEE 802.3 10-Gbps Ethernet

10GBase with Copper Cabling

10GBaseCX4

SFP+ Direct

Attach

XAUI 4-lane PCS

15 meters

Twinax

10 meters

10GBaseT

 IEEE 802.3 10-Gbps Ethernet

UTP or STP

100 meters

Metro Ethernet (MAN)

Metro Ethernet (MAN)

•

Service offered by providers and carriers that

traditionally had only classic WAN offerings.

•

The customer can use a standard Ethernet

interface to reach a MAN or WAN.

•

The customer can add bandwidth as needed

with a simple configuration change.

Long-Reach Ethernet

Long-Reach Ethernet

•

Enables the use of Ethernet over existing,

unconditioned, voice-grade copper twisted-pair

cabling

•

Used to connect buildings and rooms within

buildings

–

Rural areas

–

Old cities where upgrading cabling is impractical

–

Multi-unit structures such as hotels, apartment

complexes, business complexes, and government

agencies

Cisco’s EtherChannel

Cisco’s EtherChannel

D

a

t

a

C

e

n

t

e

r

S

w

i

t

c

h

W

i

r

i

n

g

C

l

o

s

e

t

S

w

i

t

c

h

E

a

s

t

F

i

b

e

r

R

u

n

4

0

0

M

b

p

s

W

e

s

t

F

i

b

e

r

R

u

n

4

0

0

M

b

p

s

8

0

0

M

b

p

s

E

t

h

e

r

C

h

a

n

n

e

l

Cisco’s EtherChannel

Cisco’s EtherChannel

EtherChannel provides incremental trunk

speeds between Fast Ethernet, Gigabit Ethernet,

and 10 Gigabit Ethernet. EtherChannel combines

multiple Fast Ethernet up to 800Mbps, Gigabit

Ethernet up to 8Gbps , and 10 Gigabit Ethernet up

to 80Gbps.

Internetworking Devices for Campus

Internetworking Devices for Campus

Networks

Networks

•

Switches

•

Routers

•

Wireless access points

•

Wireless bridges

Selection Criteria for Internetworking Devices

Selection Criteria for Internetworking Devices

•

The number of ports

•

Processing speed

•

The amount of memory

•

Latency when device relays data

•

Throughput when device relays data

•

LAN and WAN technologies supported

•

Media supported

More Selection Criteria for Internetworking

More Selection Criteria for Internetworking

Devices

Devices

•

Cost

•

Ease of configuration and management

•

MTBF and MTTR

•

Support for hot-swappable components

•

Support for redundant power supplies

•

Quality of technical support, documentation,

and training

Summary

Summary

•

Once the logical design is completed, the physical

design can start

•

A major task during physical design is selecting

technologies and devices for campus networks

–

Media

–

Data-link layer technology

–

Internetworking devices

•

Also, at this point, the logical topology design can

be developed further by specifying cabling

topologies

This Week’s Outcomes

This Week’s Outcomes

•

Network Management Processes

•

Syslog

•

Security

•

Campus Cabling

•

CDP

•

Technologies

•

Selection Criteria for Internetworking Devices

Q & A

Q & A

•

Questions, comments, concerns?
