Latest Developments in S-124 Product Specification
S-124PT report
WWNWS14
Geneva, Switzerland
S-124 Product Specification development
•
In general terms, a product specification consists of;
•
Main document
which describes the data model, the product/datasets and its
distribution.
•
Data Capture and Encoding Guide
which describes how to make use of the data
model to describe items that should be captured in compliant datasets.
•
Feature Catalogue
which is a machine-readable representation of the data model.
•
Portrayal Catalogue
which is a machine-readable set of instructions for how to
portray data from compliant datasets.
•
GML Schema
which is a machine-readable set of rules for how to create and validate
structure of compliant datasets.
•
There are other optional components, but these are not targeted for
completion in Edition 1.0.0 (e.g. data content validation checks).
S-124 Product Specification development
•
December 2021; task group working on the NAVWARN types general and
detailed finished the work and submission to GI Registry started.
•
453 concepts have been made to GI Registry’s Concept Register.
•
39 items have been registered in the Data Dictionary Register.
•
took Elena 56 submissions to get all sub-attributes and enumerations due to the interface
problems.
•
Approval took several months due to a glitch in the system that doesn’t
allow Registry Manager to automatically accept submissions after 60 days.
•
On September 13, 2022 the last concept was approved and September 14, 2022 the
approval of the last supersession arrived.
•
The submissions to the data dictionary register are now finalized.
•
Soft list needs update to match the final submissions.
Soft list
•
List of proposed binding between
typeGeneral and typeDetails.
•
Acts as a recommendation for
production tools to simplify the
selection of warning details.
•
See draft version of the soft list for
more details.
S-124 Product Specification development
•
S-100 Edition 5.0.0 is in the process of being formally adopted by IHO.
•
See Circular Letter 35/2022.
•
Consequence of S-100 5.0.0 is that S-124 must comply and is
dependent on the infrastructure.
•
Latest estimate is that infrastructure can be ready in December 2022.
•
This slows down development of all components of the product specification,
but most impacted are the Feature Catalogue, GML Schema and Portrayal
Catalogue.
•
Best estimate is that in February 2023, S-124 can be submitted to HSSC for
approval.
•
WWNWS-Sc endorsement is needed before any submission.
SECOM
•
Defined by IEC 63173-2:2022
•
Discussed at NCSR9 and confirmed for further discussion at NCSR10.
•
Unclear if NCSR10 will approve inclusion of SECOM in ECDIS Performance
Standard.
•
Communication between SECOM information services for data
exchange relies on IP based web services.
•
SECOM provides the means to push S-124 datasets right to the ECDIS.
•
WWNWS14 is invited to endorse SECOM as the primary data link to
transmit S-124 NAVWARN to ECDIS.
Technical Service Description
•
IALA G1128 - The specification of e-navigation technical services.
•
MCP Consortium, SMA and University of Oldenburg in Germany
support the development of a S-124 Technical Service Description.
•
See WWNWS14-2-1-1-4
•
Describes how to set up a machine-readable S-124 service in the
context of e-Navigation.
•
Recommend
that WWNWS-Sc endorse S-124PT work on S-124PT,
recognizing that both chair and vice-chair of WWNWS-Sc are
members of the project team, and permit S-124PT to submit S-124 to
HSSC for approval to release as Edition 1.0.0
when S-124PT consider
the Product Specification documents are ready.
•
WWNWS
is invited to note the report and comment as required.
