Introducing YEEBO Bar Type TFT Displays for Various Applications

Slide Note

YEEBO Bar Type TFT displays offer a unique landscape-stretched design, making them ideal for industrial equipment, automotive applications, server systems, POS systems, dynamic information displays, and advertising displays. These displays come in sizes ranging from 3.9 inches to 6.5 inches, providing a different aspect ratio compared to mainstream TFT LCD panels. The roadmap outlines the mass production and development stages for different display sizes, including designing and developing processes. The introduction highlights the specifications of the standard product, featuring IPS display type, normative black display model, and operating temperature range.

mthie Follow

Uploaded on Oct 11, 2024 | 0 Views

Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

E N D

Presentation Transcript

Bar Type TFT Display YEEBO NEW LAUNCH PRODUCT

CONTENTS 1 2 3 4 5 What is Bar type TFT? Application Bar Type TFT Display Y E E B O N E W L A U N C H P R O D U C T Roadmap - TFT Roadmap TFT+CTP Introduction

1 What is Bar type TFT?

1 What is Bar type TFT? YB Bar Type TFT Bar type TFT is Landscape stretched Display. The mainstream aspect ratio of the TFT LCD panel in the market is 4:3 or 16:9. But for some applications, bar type shape of display panel would be much better than the current mainstream 4:3 or 16:9 to display the required information. YEEBO Bar Type TFT-LCD displays are perfect for industrial equipment, automotive application, server system, POS system, dynamic information displays and advertising display. We offer different sizes Bar Type TFT (Stretched Bar LCD Display) including sizes of 3.9 inch, 4.6 inch and 6.5 inch.

2 Application

2 Application for Bar Type TFT YB YB YB Bar Type TFT YEEBO Bar Type TFT-LCD displays are perfect for industrial equipment, automotive application, server system, POS system, dynamic information displays and advertising display.

3 Roadmap-TFT

3 Bar Type TFT Roadmap Mass Production 6.5 Designing 800RGB*320 4.6 800RGB*320 3.9 480RGB*128 6.86 480RGB*1280 Developing 2.0 320RGBx130 2.86 376RGB*960 2019 Q4 2020 Q1 2020 Q2 Coming soon

4 Roadmap-TFT+CTP

4 Bar Type TFT+CTP Roadmap Mass Production Designing 6.5 800RGB*320 4.6 800RGB*320 3.9 480RGB*128 Developing 2020 Q1 2020 Q2 2020 Q3

5 Introduction (Standard product)

5 Introduction-Standard product IPS Display Type Normally Black Display Model Transmissive 3.9 Bar Type TFT SPEC 3.9 Display Size/Format 480(RGB)*128 Operating Temperature -20~70 Storage Temperature -30~80 Typical Contrast 800 Top Bottom: 80 /80 Left Right: 80 / 80 Viewing Direction Backlight Color White Home App / Medical / Instruments Applications

5 Introduction-Standard product TN Display Type Normally White Display Model Transmissive 4.6 Bar Type TFT SPEC 4.6 Display Size/Format 800(RGB)*320 Operating Temperature -20~70 Storage Temperature -30~80 Typical Contrast 500 Top Bottom: 60 /65 Left Right: 70 / 70 Viewing Direction Backlight Color White Home App / Medical / Instruments Applications

5 Introduction-Standard product TN Display Type Normally White Display Model Transmissive 6.5 Bar Type TFT SPEC 6.5 Display Size/Format 800(RGB)*320 Operating Temperature -20~70 Storage Temperature -30~80 Typical Contrast 500 Top Bottom: 60 /70 Left Right: 70 / 70 Viewing Direction Backlight Color White Home App / Medical / Instruments Applications
