1. New Single Phase Profile Divider Design Cristobal Garces UTA HEP Dec. 10, 2019 1

2. Profile Divider Purpose of the divider is to separate the aluminum profiles during assembly. Keeps profiles in their respective positions Helps speed up the assembly process Divider must not damage the profiles during assembly. Previous/Current Design is made of two main parts. Rods and the divider Both made of Delrin 2

3. Vics Short Divider Design 3

4. Vics Long Divider Design 4

5. New Design Maintains the same the design concept. One row has one short and two long dividers Consists of two short profile dividers and four long dividers. Made of a hard foam rather than Delrin Uses integrated teeth instead of independent rods/pins Less components required Easy to machine 5

6. New Profile Dividers 6

7. Short Divider Drawing 7

8. Long Profile Drawing 8

9. Close-Up 9
