  1. Computation in Intelligent Transportation Computation in Intelligent Transportation Ouri Wolfson Ouri Wolfson University University of Illinois, Chicago of Illinois, Chicago 1

  2. IGERT Ph.D. program in Computational Transportation Science Information Technology Transportation Focus on Intelligent Transportation Systems (ITS) 2

  3. ITS: safety applications Make a driver aware of unseen hazards Examples: Vehicle in front has a malfunctioning brake light Vehicle on crossroad is about to run a red light Patch of ice at milepost 305 A vehicle 100 meters ahead has emergency braked 3 3

  4. ITS: Efficiency/convenience/mobility applications On-route traffic and weather conditions, What is the average speed a mile ahead of me? Is the upcoming pavement wet there? Are wipers/fog-lights on there? Are there any accidents ahead? Resource search 4 4

  5. ITS: Environmental/Energy applications Ride/car sharing Multimodal routing/navigation for optimal Pollution generation/exposure Energy consumption Persuasive/green technologies 5

  6. Spatio-temporal Resource Search Mobile agents (vehicles) Static, serially reusable, resources in geo-space or time Parking slots, Electric-car charging stations Taxi-cab customers Bikes at stations Bike-Station-slots Package for pick-up/delivery Airport landing time-slots Agents compete for resources First agent reaching resource (or closest) captures it

  7. Parking Statistics (Shoup 2005) In major cities cruising for parking generates 30% of congestion 1,825 vehicle miles traveled/year/slot Chicago has over 35,000 curbside parking slots 63M Vehicle-Miles-Traveled/year for parking waste of over 3.1 million gallons of gasoline > 48,000 tons of CO2 emissions

  8. Parking Applications SFPark: Smartphone app that displays location of available parking slots Enabled by sensors in pavement 8

  9. SFPark Problems Safety concern Driver distraction Solution: Automatic selection and guidance to slot Which parking slot? Cost Install: $300/sensor Maintain: $170/year Solution: smart-phones crowdsourcing 9

  10. Outline of Talk Finding spatio-temporal resources Models of the problem Noncompetitive (Optimality) Competitive (Equilibrium) Agents availability-information Zero Incomplete Probabilistic Deterministic, complete Extensions: pricing, negotiation, truthfulness Detecting spatio-temporal resources A crowdsourcing approach using smartphones Preliminary work on: Transportation Neuroscience 10

  11. Noncompetitive (Centralized) Model Minimum Total Cost c(v1,s1) v1 s1 Possible cost components: Travel time Walk-time to destination Wait time $-cost Safety Customer destination for taxi Combination of above c(v1,s2) s2 v2 c(v1,sm) . . . . . . . . . vn sm 11

  12. Noncompetitive (Centralized) Model Minimum Total Time Traveled c(v1,s1) v1 s1 0 0 c(v1,s2) 0 0 s2 v2 t s c(v1,sm) . . . . . . 0 0 . . . Theorem: Assignment with minimum total cost can be computed efficiently vn sm Proof: reduction to minimum cost network flow problem. 12

  13. Enter Selfishness 1 s1 5 v1 v2 2 s2 8 System Optimal: V1->S2 and V2->S1 at total-time 7; but V1 can improve time Nash Equilibrium: V1->S1 and V2->S2 at total-time 9; V1 and V2 cannot unilaterally improve time 13

  14. Equilibrium In real world cars compete for parking In selfish parking, i.e. no central authority, Nash equilibrium is settle-on strategy v1 s1 c,t(v1,s2) Nash Equilibrium (NE): No agent can reduce its cost, if all others are rational (attempt to minimize theirs) c,t(v1,s1) s2 v2 c,t(v1,sm) . . . . . . . . . vn sm Theorem 1: NE assignment can be computed efficiently Generally not unique Unique if Costs = TravelTimes 14

  15. How compute NE? Using Stable Marriage Problem A matching (paring) such that: There doesn t exist a man-woman pair from different marriages that prefer each other over their assigned spouse . Can be solved efficiently (Gale-Shapley 1962) Men Preference Order Women Preference Order w1 > w3 > w2 m3 > m2 > m1 m1 w1 w1 > w2 > w3 m1 > m2 > m3 m2 w2 w2 > w3 > w1 m2 > m1 > m3 m3 w3 15

  16. Resource-Search Stable-Marriage Theorem 2: If Each agent ranks the resources increasingly by their costs, and Each resource ranks the agents increasingly by their travel-time, then: Solution to the stable marriage problem => Nash Equilibrium matching 16

  17. Price of anarchy: Ratio Between Optimum and Equilibrium 1 s1 5 v1 v2 2 s2 8 9/7

  18. Price of Anarchy (SigSpatial11) Proposition 3: Worst case Price of Anarchy is unbounded Proof: 1 s1 5 v1 v2 2 s2 1000 18

  19. Resource-Availability information of agents Map only Incomplete availability-knowledge Probabilistic-availability knowledge Complete availability-knowledge

  20. Parking Example: Map only s1 v1 v2 s2

  21. Parking Example: Map only Result? Vehicles wander around until coming upon some available slot. No one is happy. s1 v2 v1 s2 City_Hall

  22. Incomplete Knowledge: SFPark Vehicles: Are aware of locations of the slots. Are not aware of locations of other vehicles. 1 5 s1 v2 v1 8 2 s2 City_Hall

  23. 1 s1 v1 s view of the system v1 2 s2 City_Hall

  24. 5 s1 v2 s view of the system v2 8 s2 City_Hall

  25. Greedy strategy 1 5 s1 v2 v1 s2 Result: v1 is happy but no one else is happy. v2 and City_Hall are happier but still not happy. City_Hall

  26. Alternative to Greedy: Gravitational Slots have gravitational pull on the vehicles. F(v,s) = 1/cost(v,s)2 Compute force vector for each slot Add vectors s2 s1 Move in direction of resultant vector (magnitude irrelevant) s3 v s4 Repeat 26

  27. Force field generated by Gravitational strategy Vehicles will eventually converge to a slot. Motion vector changes depending on: location of vehicle available slots Motion not directed to a specific slot 27

  28. Greedy vs. Gravitational in Fishermens Wharf area using SFPark data

  29. Probabilistic information Node Intersection : vi Edge Block: eij Cost of eij: cij (simplified) Probability of finding a resource on eij: pij Cost of quitting on vi: qi

  30. Probabilistic formulation of search Find the path of time < T, which has either: highest probability of finding a resource meaningless if T is very large, All infinite paths have probability 1 lowest expected cost of finding a resource. Find the path (possibly infinite) which has minimum expected cost

  31. Results in Probabilistic model Proposition: Expected cost of infinite path is bounded. Representation of infinite path: next(i) at each node i; Efficient algorithm to find path (maybe infinite) of min expected cost Distinction in the algorithm between 2 types of resources. Suppose no resource on edge e with probability pe is found at time t: the probability of e at t+1 is still pe (taxi cab customer) the probability of e at t+1 is 0 and recovers to pe within a limited amount of time (parking slot)

  32. Complete Availability-Knowledge My position is My position is 1 5 s1 v2 v1 8 2 s2 City_Hall

  33. Complete Availability-Knowledge vehicles compute and pay equilibrium price. Vehicles are happy City_Hall is still not happy. 1 s1 v2 v1 8 s2 City_Hall

  34. Alternative view of Complete Availability-Knowledge Each agent a knows the future availability of resources; and a pursues the lowest-cost resource r that will stay available by the time a reaches r (not the same as greedy)

  35. How to make City Hall happy? 1 s1 5 v1 v2 2 s2 8 optimum allocation: travel time 7

  36. Pricing by central-authority 10 cents 1 s1 5 v1 v2 2 s2 8 Suppose parking at S1 has a price of 10 cents1 Driving 1 minute has a total $-cost of 5 cents Then it becomes beneficial for V1 to drive to S2 Pricing converts Equilibrium to Optimum

  37. Pricing Scheme (ACMGIS12) Pricing for slots, such that: Priced Equilibrium is (unpriced) Cost Optimum Assuming some conversion $ <-> time

  38. Auction Algorithm Start with prices of all slots at 0 and with an arbitrary assignment. A vehicle is said to be happy if he doesn t want to change to another slot given the current costs. An iterative process starts: For any vehicle vthat is not happy Give v his most preferred slot and swap with its current owner. Raise price of this slot to the point where its value to v is the same as its 2nd preferred slot. Repeat Process until everyone is happy.

  39. Auction Algorithm 0 5 s1 1 v1 v2 2 8 s2 0

  40. Auction Algorithm Start with an arbitrary assignment 0 5 s1 1 v1 v2 2 8 s2 0

  41. Auction Algorithm v2is not happy since 0.8 > 0.5 0 5 s1 1 v1 v2 2 8 s2 0

  42. Auction Algorithm v2is not happy since 0.8 > 0.5 0 5 s1 1 v1 v2 2 8 s2 Then swap slots with v1. 0

  43. Auction Algorithm 0.15 v2is not happy since 0.8 > 0.5 5 s1 1 v1 v2 2 8 s2 Then swap slots with v1. 0 Raise price of s1 to point where value is same as s2.

  44. Auction Algorithm Now both are happy so we are done. 0.15 5 s1 1 v1 v2 2 8 s2 0

  45. But V1 pays more than would have paid in equilibrium and The scheme constitutes an additional tax

  46. Complete Availability-Knowledge with Negotiation Situation in which the vehicles are aware of: locations of the slots. locations of other vehicles Vehicles can trade slots for $. Say $1 = 1min of travel time. 1 5 s1 8 2 s2 City_Hall

  47. Parking Example: Complete Knowledge with Negotiation I ll offer you $2, let me have s1. Ok, I ll take the $2!! 1 5 s1 v2 v1 8 2 s2 City_Hall

  48. Complete Knowledge with Negotiation v2 pays $2 to v1 for s1: v1 pays cost 0 v2 pays cost 7. Each vehicle pays < its price at equilibrium. City_Hall is happy . -$2 +$2 5 s1 2 s2 City_Hall

  49. Guaranteed-Improvement Theorem (GIT) (SigSpatial 12) for every configuration of slots and vehicles there is a payment scheme, and an optimal allocation (of vehicles to slots) scheme such that the cost of each vehicle v (including payment/refund) than v s cost in equilibrium (w/o payment)

  50. Truthfulness v1 and v2 have an incentive to spoof their location to be the location of s1. I m only 0.1 minutes away from s1. Ok, then I won t even go there. 1 5 s1 v2 v1 8 2 s2 City_Hall
