Human Evolution: Evidence of Common Ancestors

KNOWLEDGE AREA:

Diversity, Change and

Continuity

TOPIC 4.2:Human Evolution

Evidence of Common Ancestors

for Living Hominids including

Humans



Before we look at the

phylogenetic tree

we must

first study the

classification of humans

.



Humans are found in the

class mammalia

.



They belong to the

order Primates

and then



They are found in the

sub-order Anthropoidea



This

sub-order

 is made up of

2 families

.



These are

family Hylobatidae

, and

family

Hominidae

.



Humans fall into the

family Hominidae

.



Then

genus Homo



Finally

species Homo

sapiens



This is all shown in the

picture alongside.



Here we often come

across the terms

hominid and hominin

.



Lets look at these 2

terms.

Classification of Humans



Hominid

 refers to the

group

 which

contains

modern humans, chimpanzees, gorillas and

orangutans

.



It also

includes all their immediate ancestors

.



In other words

all the organisms

found in the

family Hominidae

.



Hominin

 refers to

modern humans

and

all

the extinct human species

.



It also

includes all our immediate ancestors

.



Now will look at how the

humans are similar

and

different to the African apes

.



The

African

apes

include the

gorillas, chimpanzee

and bonobos

.

Now lets look at the

phylogenetic tree

.

Chimpanzee

Bonobos



The phylogenetic trees on the next 2 slides gives

some information on human evolution.



We will use both these trees to trace human

evolution from about 6 million years ago.



Between

6 to 7 mya the first bipedal primates

appeared.

These organisms had the following features:

a.

Small brain size

b.

Foramen magnum had a forward position.

c.

Small canine teeth



Then about

4mya

Australopithecus

appeared.



They had

features of both primitive apes

and

modern humans

.



They had the

head of primitive apes

and from the

neck down they looked like the modern humans

.



Therefore they are

often called ape-men

.

The features  shared

with primitive

apes were

…

1.

Protruding jaws

2.

Heavy brow ridges

3.

Slopping faces

4.

Small brain.

Australopithecus



A

new genus

appeared between

4.32 and 4.51 million

years ago

.



This was the

Ardipithecus

.



This

genus

 was made

up of

2 species

.



They were

A. ramidus

and

A. kadabba



A. kadabba

lived

about

5.6 mya

.

A. ramidus

A. ramidus

had the following features…

1.

A small brain

2.

A pointed face and poorly developed chin

3.

A grasping big toe for swinging from branch to

branch of trees.

4.

It was also adapted for bipedalism.



Then about

2 mya the australopithecines

gave rise

to

Homo habilis

(the handy man)



H. habilis

was referred to as the

handy man

because

fossil evidence showed that they used tools

.



H. habilis

was

first of the early humans

.

H. habilis

was different from the australopithecines in

the following way…

1.

Less pronounced

brow ridges

2.

More human like

teeth

3.

A flatter face

4.

A more rounded

head

5.

A brain capacity of

600 to 750ml.

homo habilis



It is thought that

about

1.5 mya

H.

habilis

gave rise to

Homo erectus

.



H. erectus

had the

head of an ape

but

from the neck down it

looked like modern

man

.



It  was

as tall as

modern man

and had

a

larger brain size of

700 ml to 1300ml

.

Homo erectus



Then about

150 000 to 200 000

years ago

h.

erectus

 gave rise to

Homo sapiens

.



We will look at these in a little more detail later

on.



Two groups

of the

African apes

share a

common

ancestor with humans

.



These

2 groups of apes

are the

chimpanzee and

bonobos

.

We want to look at evidence that support the idea of a

common ancestor.



We look at 3 lines of evidence.

These are …



Fossil evidence



Genetic evidence



Cultural evidence

Lets look at each of these in some detail.

1.

Fossil Evidence:



From our earlier discussion we can see that

many hominin fossils

have been discovered over

the years.



Hominin fossils

belong to

at least 20 species

.



These

fossil provide evidence

for a

close

evolutionary relationship

between humans and

the great apes

.



The

fossils use anatomy

to show this

relationship.



The

fossils provide 2 lines of evidence

.

These are…

a)

Transitional fossils:



This refers to the

immediate  fossils between a

group and their ancestor

.



In this case the

transitional fossils

have

characteristics of both the apes and humans

.



The

great –ape characteristics

are also found in

the common ancestor

, but



The

human characteristics occur only

in the

hominins

.

b)

The Oldest fossils:



These fossils have

more characteristics of the

great apes

than the

younger fossils

.



These

younger fossils

are

more like the modern

human

.



Over a period of time

we see that the

fossils

become more human like than ape like

.



We shall look at the

similarities and differences

between the great apes and humans

a little

later.

2.

Genetic Evidence:



The

DNA base pairing

of

humans and the Great

apes

 are

almost identical

.



The

human DNA sequence

is

most similar

to the

chimpanzee

.



Humans and chimpanzee

have

98.76%

 of

the

base pair sequence in common

.



Since

DNA sequence is so similar

it

provides

evidence for a close relationship between

humans and chimpanzees

.

3.

Cultural Evidence

:



Fragments of sticks, burned bones, stone

weapons and tools

etc, were used as

cultural

evidence for human evolution

.



Chimpanzees also use tools

, for example using

stones to open nuts

.



Young chimpanzee learn behaviour

from

watching their mothers

.



Therefore it is believed that the

common

ancestor of humans and chimpanzee

also

used

similar tools in a similar way

.



Many of the

early mammals lived on trees

.



Many

 of the

African apes

are

still adapted

for an

arboreal life

.

Humans share the following characteristics with

the African apes and other primates…

1.

The upper limbs

2.

The brain

3.

Vision

4.

Number of Offspring

5.

Upright posture

1.

The Upper Limbs:



Primates

 have

very long arms

, which

they move

freely

.



They are able to

move their arms freely because

…

1.

The

socket

 is

very shallow

.

2.

The

scapula is not attached

to the

vertebral column

.



They

do not have claws

, instead

they have flat nails

.



Their

fingertips are bare

and

contain a large

amount of nerve endings

.



Finally all

primates have opposable thumbs

.



The

long arms

are

used to gather fruit

from the

tips of tree branches

.



Their

bare fingertips

are

very sensitive

, this

makes

precision work possible

.  Therefore they

are able

to make and use tools

.



The

opposable thumbs

makes the

power grip and

precision grip possible

.



Like primates humans have…



 opposable thumbs,



flat nails instead of claws and



freely moving upper limbs.

2.

Brain:



We find that when we

compare the brain to

body size

, the

primates have large brains

compared to their body size

.



This

enables them

to

process large amounts of

information

.



Parts of the brain responsible

for

interpretation

information coming from the hands

and

eyes

are enlarged

.



The

olfactory organ

is

much reduced

because

primates do not depend

on the

sense of smell

.

3.

Vision:



Their

eyes are found

in the

front

.



They display both

stereoscopic and binocular

vision

.



They have

rods and cones

to

enable a more

clear and colour vision

.

4.

Number of Offspring Produced:



Primates

produce far less offspring

.



Parental care

is

intensive

.

5.

Upright Posture

:



They have an

upright posture

, which

allows for

the primates to walk on two legs

.



This allows for

better view of the surroundings

.



Upper limbs are free for carrying things

such as

food, babies and tools.



List the characteristics that humans share with the

African apes.

1.

Large brains compared to their body mass.

Therefore a large skull.

2.

Reduced sense of smell due to a reduced olfactory

center in the brain

3.

Parts of the brain that process information from

hands and eyes are larger.

4.

Retina contains cones to make color vision possible.

5.

Stereoscopic vision

6.

Binocular vision

7.

Long upper arms

8.

Upper arms – full and free movement

9.

Forearm can rotate because of elbow joint

10.

No claws, nails are flat

11.

No hair on fingertips-bare fingertips

12.

Opposable thumbs

13.

Upright posture.

This is a good learning tool use it to learn the

similarities.



Anatomy

refers to

structural make up

of an organism.



In this section we will look at how the humans and

African apes are structurally different from each other.

The following anatomical differences occur between

the humans and the African Apes…

1.

Bipedalism

2.

Brain size

3.

Dentition

4.

Flat face/Prognathism

5.

Cranial ridges

6.

Brow ridges



There is

fossil evidence to support these anatomical

differences

.

Now lets look at each of these in some detail

1.

Bipedalism:



The

African apes sit upright

and are

able to walk on

2 feet

.



However

they do this

only sometimes

,

while

humans walk on 2 legs

all the time

.



Animals that show

bipedalism

 have

a different

arrangement of the vertebral column

to the

head



Therefore the

position

of the foramen magnum

had to

change

.



It moved from the

back

of the skull to a forward

position at the bottom

of the skull

as shown

alongside.



This means that in

animals that show

bipedalism

, the

foramen

magnum is in a forward

position at the bottom

of the skull,

 while

Position of Foramen Magnum



The animals that show

quadrupedalism

 have a

foramen magnum at the back of the skull

.



In addition

animals

with bipedalism

had a

much wider and

shorter pelvis

,

because the

pelvic

girdle had to support

the weight of the

body

.



While

quadrupeds

have long, narrow

pelvic girdles

.

Comparison of pelvic girdle of

human and chimpanzee



Finally the

spine of

an organism

with

bipedalism

 is

straighter

 than a

quadrupedal

.

Comparison of the Spine

2.

Brain Size:



Over the time the

brain size of the hominin

species has gradually increased

.



Homo sapiens

have a

brain size twice

that of

Homo habilis

.



The

brain size of the first bipedal apes

was

half

the size of the brain of

Homo habilis

.



The

brain of the modern man

is the

biggest

.



It

ranges in size

from

1200ml to 1800ml

.



The

advantage of the large brain size compared to

their body masses over those apes

 that had a

smaller

brain compared to their body mass size is greater

intelligence

.



But it must be noted that this

does not apply to

modern humans

.



Since humans have a

larger brain they also have a

larger skull

.

3.

Dentition:



Apes have

large canines that protrude

.



In

humans

 the

canines are much smaller

and is

shaped almost like an incisor

.



The

incisors in humans do not stick out

, while in

chimpanzees they stick out spatulas or spoons

.



The dental formula a of humans is

2.1.2.3

2.1.2.3



The dental formula of the oldest primates are

2.1.3.3

2.1.3.3



The

apes

 have a

u-shaped jaw

with

parallel sides and

the front is slightly rounded

.



The

incisors are found at the front and canines

,

premolars and molars are on the side

.



Humans

 have a

gently curved jaw

.

4.

A flat face / Prognathism:



Modern humans have a

flat face

.

The following features ensures that humans have a

flat face…

1.

The

foreheads

of

modern humans do not slope

backwards

while the

forehead of the ape men

slope backwards

.

2.

Humans have  a well developed chin

on their

lower jaws

.

Human chins

are

square shaped

,

this is thought to be an

adaptation for speech

.

Chimpanzees

 have

rounded chins

.

3.

The

bones of the nose and jaws stick out

in the

ape man

in other words ape men were

prognathous

.  Modern humans are

not

prognathous

, this means that the

bones of the

nose and jaws do not stick out

.



Humans have

shorter palates than apes

.



The chimpanzee have

a parallel-sided palates

.



While the

palates of the

Australopithecus

have a

U-shaped palate

.

5.

Cranial ridges:



Cranial ridges

are found

at the back

of the

skull

.



Cranial ridges of humans do not protrude

as

those of

ape men

.

6.

Brow ridges:



The

ape men have larger brow ridges

than

humans.



In most cases the

brow ridges in humans are

absent

.

3.2.1

A – Gorilla

B – Modern human

3.2.2

3.2.3

B

3.2.4

Allows total awareness of the environment in

sensing

danger/looking for food

- Enables hands to be free to use  implements

/carry

objects or offspring/throw/protect

- Exposes a large surface area for thermo-

regulation /lose body heat to surroundings in hot

conditions/reduce overheating therefore reduce

need for water

- Display of male/female sex organs as part of

courtship behaviour



You can use these answers to enhance or

even make your studying easier.



You can use the table to learn the

differences between the African Apes

and modern human.



The answer to question 3.2.4 can be used

to learn the advantages of bipedalism

3.1.1

(a)

Pan troglodytes/chimpanzee/C

(b)

Homo erectus/A

(c)

Homo sapiens /B

OR

(a)

Homo erectus/A

(b)

Pan troglodytes/chimpanzee/C

(c)

Homo sapiens /B (3)

Remember

:

that if scientific names are

not underlined you will lose the marks!!!!

3.1.2

Learn this table too

The following essay appeared in the Nov 2013 paper

1.

4.3 Describe the structural changes to the skull that

characterise the evolution of modern humans

from their ape-like ancestors, and explain the

significance of these changes .

4.3

Foramen magnum

- The foramen magnum was in a backward position in the ape-like

beings

- but in a forward/ central/ ventral position in modern humans

Significance

- This represents a change from quadrupedalism in ape-like beings

- To bipedalism/(walking upright) in modern humans, leading to the

following in modern humans:

o Increased awareness of the environment

in sensing danger/food

o Freeing of the hands to use implements/ carry objects/ weapons/

offspring

o Exposure of a large surface area for thermoregulation/losing body



Display of sex organs /breasts as part of courtship

behaviour

Cranium

- Modern humans have a larger cranium

than the

ape-like beings

-

Modern humans have a less sloping forehead

than

the ape-like beings

-

Modern humans have a cranium that is more

rounded

than the ape-like beings

Significance

- This allowed space for a larger brain

in humans

than in ape-like beings, making the following

possible:

o Better co-ordination of movement

o Processing of a large amount of information

o Processing information faster

o Development of spoken and written languages to

communicate



Jaws

-

Humans have smaller jaws

than the ape-like

beings

-

Humans have jaws that are non-prognathous/ flat

face

-

compared to the jaws of ape-like beings which are

prognathous/sloping face

-

Humans have C-shaped jaws

/jaws that are gently

curved

-

compared to the U shaped jaws

in the ape-like

beings

Significance

-

This corresponds with a change in diet from hard, raw

food

in the ape- like beings

-

To softer, cooked foods

in humans

Dentition/Teeth

- In ape-like beings there are gaps/diastema between

incisors and canines

- but no gaps

between the teeth in humans

- Humans have smaller teeth/incisors and canines

than

the ape-like beings

- Humans have flatter molars and pre-molars

than the

ape-like beings

Significance

- This corresponds with the decreased need to bite and tear

-

and an increased need to grind and chew

in humans  in

view of the change in diet to soft, cooked food

Eyebrow ridges

- Humans have eyebrow ridges that are smaller

than those of

the ape-like beings



Significance

- There is a decreased need to strengthen the skull

of humans

- due to the smaller size of the jaws

-

Chin

- In humans the chin is more developed

compared

to the ape-like

beings

Significance

- Developed chin assists with speech

in humans

Zygomatic arch

- In humans the zygomatic arch/cheek bone is less developed

than

in the ape-like beings

Significance

- This corresponds with the decreased need for attachment of

strong muscles

-

due to the decreased jaw size

in humans



Hominid

: refers to the group including modern

humans, chimpanzees, gorillas and orangutans.



Hominin

: refers to modern humans and all the

extinct human species



Transitional fossils

: refers to the immediate

fossils between a group and their ancestor



Arboreal

:

refers to living in trees



Stereoscopic vision

:

refers to see the depth and

solidity of objects



Binocular vision

:

the process of looking at an

object with both eyes



Opposable thumb

:

the thumb is opposite the

fingers



Bipedalism

:

refers to a type of locomotion where

the animal moves on 2 hind legs in an upright

position



Dentition

:

refers to the development of teeth and

the way they are arranged in the mouth



Prognathous

:

refers to the projection of the jaws

and nose that leads to a pointed face.

1.

Characteristic/s that humans share with other

primates…

A.  Opposable thumbs

B.  Binocular vision

C.  Both A and B

D.  Neither A nor B

2.

Homo habilis

…

A.  was called Handyman because he was a

toolmaker.

B.  had a larger  brain capacity than

Homo

erectus

.

C.  was the first Homo species without brow

ridges.

D.  was the first Homo species to leave Africa.

3.

An opening on the primate skulls through which

the spinal cord passes…

A.  Foramen magnum

B.  Vertebral column

C.  Spine

D.  Vertebrae

4.

Capable of bipedal locomotion…

A.

Homo erectus

B.

Australopithecus africanus

C.  Both A and B

D.  Neither A nor B

5.

A branched diagram showing the evolutionary

relationships between species…

A.  Cladogram

B.  Phylogenetic tree

C.  Both A and B

D.  Neither A nor B

6.

The group consisting of modern humans,

chimpanzee, gorillas and orangutans and all

their ancestors is…

A.  Hominid

B.  Hominin

C.  Both A and B

D.  Neither A nor B

7.

Australopithecus, Panantropus

and

Ardipithecus

belong to…

A.  Hominid

B.  Hominin

C.  Both A and B

D.  Neither A nor B

8.

Walking on 2 legs…

A. Bipedalism

B.  Quadurpedalism

C.  Both A and B

D.  Neither A nor B

9.

A fossil that is intermediate between a group

and their ancestor…

A.  Middle fossil

B.  Mean fossil

C.  Transitional fossil

D.  None of the above

10.

Having a long face that sticks forward…

A.  Prognathous

B.  Non-prognathous

C.  Diastema

D.  Flatter face

11.

Chimpanzee…

A.  Prognathous

B.  Non-prognathous

C.  Both A and B

D.  Neither A nor B

12.

Humans…

A.  Prognathous

B.  Non-prognathous

C.  Both A and B

D.  Neither A nor B

13.

Structure or parts of the body…

A.  Ancestor

B.  Anatomy

C.  Both A and B

D.  Neither A nor B

14.

U-shaped jaw…

A.  Humans

B.

Australopithecus

C.  Both A and B

D.  Neither A nor B

15.

Prominent brow ridges…

A.  Humans

B.

Australopithecus

C.  Both A and B

D.  Neither A nor B

16.

Absence of cranial ridges…

A.  Humans

B.

Australopithecus

C.  Both A and B

D.  Neither A nor B

17.

Binocular vision…

A.  Humans

B.

Australopithecus

C.  Both A and B

D.  Neither A nor B

18.

Altricial development…

A.  Humans

B.

Australopithecus

C.  Both A and B

D.  Neither A nor B

19.

Forward foramen magnum…

A.  Humans

B.

Australopithecus

C.  Both A and B

D.  Neither A nor B

20.

Spatula shaped incisors…

A.  Humans

B.

Australopithecus

C.  Both A and B

D.  Neither A nor B

1.

C

2.

A

3.

A

4.

C

5.

C

6.

A

7.

B

8.

A

9.

C

10.

A

11.

A

12.

B

13.

B

14.

B

15.

B

16.

A

17.

C

18.

C

19.

C

20.

D
