1. S2.6 High Stored Energy Emergency discharge systems; Capacitor short circuiting and grounding Carlos A. Martins, ESS Safety Review on 660kVA klystron modulators for RFQ/DTL and MBeta

2. High Stored Energy Where is the energy stored in the system? o 1)- Local capacitor bank of DC-link busses of AC/DC+DC/DC power stacks (Cdc A,B,C); o 2)- Main capacitor banks; o 3)- Local capacitor bank of H-bridge power stacks; KLYSTRON CABINET #1 HV CABLE 1 HV OIL TANK 10 AUX PS1 AUX PS4 DA+ FHB 1 1 DC/AC #1 LEM Ipulse 1 14 24 A2 13 23 A1 + - + - HVHF 1) CT 1+ CAPACITOR CHARGER #A 6 Transformer 1 HVL1 AUX TRANSF 13 23 14 24 RGsw 1 LEM DC-A Cbk 1 ROSS 1 230V ac DC/DC #A DRIVER DRIVER AC/DC #A 2) 400V CM Filter A LEM R-A (TRF 1) Lf R-A AUX POWER SUPPLY 24V AUX POWER SUPPLY 24V Rds A1 LEM CB-A Rds 1 Kds CBK Cdc A GSw KLYSTRON 1 OIL TANK Ccm CT 1- Rcb A Tcb A DRIVER DRIVER DRIVER DRIVER Lf S-A LEM S-A 600V HV Box 1 4Ccm DC/AC #2 Rds A2 Ldc A Lf T-A Lcm HVHF Kds A CT 2+ KLYSTRON 4Ccm FHB 2 HVL2 Transformer 2 E X T . U P S RGsw 2 LEM T-A KAC A Rds 2 HV CABLE CB AUX 2 DRIVER DRIVER Cbk 2 CBprechA 2 14 Ccm 5 3) CB AUX 1 RC 1 2 4 13 LEM Ipulse 2 8 A1 A2 Rpch CBdcPrechA Rpch CT 2- KprechA DA- CF 1 + - 7 9 HV Box 2 ROSS 2 13 14 23 24 RC 2 DC/AC #3 14 24 A2 13 23 A1 HVHF 1) CAPACITOR CHARGER #B CT 3+ 6 CF 2 FHB 3 DB+ Transformer 3 HVL3 KLYSTRON 2 OIL TANK LEM DC-B 230V ac DC/DC #B DRIVER DRIVER Cbk 3 AC/DC #B 2) LEM R-B Lf R-B CM Filter B Lfg - R Rds B1 LEM CB-B RGsw 3 Cdc B Rds 3 Kds CBK R Rcb B Ccm GSw CT 3- 10 KLYSTRON DRIVER DRIVER DRIVER DRIVER Lf S-B LEM S-B Lfg - S S EMC FILTER HV Box 3 HV CABLE 4Ccm 3 Lcm-out Tcb B DC/AC #4 Rf Rds B2 Lf T-B Ldc B Lfg - T Lcm HVHF Kds B CT 4+ T 3 4Ccm FHB 4 Transformer 4 LEM Ipulse 3 HVL4 LEM T-B 4Cfg 4Cfg RGsw 4 KAC B Rds 4 4Cfg DRIVER DRIVER CBprechB Cbk 4 Cfg Cfg Cfg 14 Ccm 5 Rb 3) ROSS 3 4 Rfg SDE 13 Rfg Rfg Rpch 8 Rpch A1 A2 CBdcPrechB CT 4- KprechB + - DB- 7 OF 9 HV Box 4 Cfgcm KLYSTRON 3 OIL TANK 1 13 14 23 24 DC/AC #5 14 24 A2 13 23 A1 HVHF AC fg CAPACITOR CHARGER #C 1) CT 5+ 6 SD FHB 5 DC+ Transformer 5 HVL5 LEM DC-C KLYSTRON DC/DC #C 230V ac DRIVER DRIVER Cbk 5 AC/DC #C 2) 3 LEM R-C CM Filter C Lf R-C 24 V Rds C1 LEM CB-C HV CABLE dc CT1 RGsw 5 4 Rds 5 Kds CBK Cdc C Rcb C Ccm GSw CT 5- 10 DRIVER DRIVER DRIVER DRIVER Lf S-C LEM S-C 4 LEM Ipulse 4 No Volt Coil HV Box 5 HV DIV 4Ccm DC/AC #6 Tcb C Rds C2 2 Ldc C Lf T-C Lcm HVHF Kds C CT 6+ ROSS 4 4Ccm FHB 6 MCB Transformer 6 HVL6 LEM T-C ON 3) RGsw 6 KAC C DRIVER Rds 6 Cbk 6 DRIVER DRIVER CBprechC 14 Ccm 5 KLYSTRON 4 OIL TANK OFF 4 13 8 CBdcPrechC Rpch A1 A2 Rpch KprechC CT 6- HV Box 6 Rgnd + - DC- 7 Arc Protec 9 13 14 23 24 11 PART I LV POWER CONVERSION STAGE

3. 1)- DC link capacitors discharge resistors DC/DC AC/DC Resistors: - RDS A1, A2 (DC-link bus A); - RDS B1, B2 (DC-link bus B); - RDS C1, C2 (DC-link bus C); Discharge time below 50V: Discharge peak power: Rugged type: 0.8s 2 x 6.3 kW each resistor accepts 5x nominal power for 10sec 2 x For each DC-link bus: 2 x (47 / 1000V / 800W) in series CJT 800 series

4. 1)- DC link capacitors discharge contactors DC/DC AC/DC Contactors: - KDS A (DC-link bus A); - KDS B (DC-link bus B); - KDS C (DC-link bus C); For each DC-link bus: LTC 100 type, 1-pole, NC Rugged type, railway applications

5. 2)- Main capacitor bank discharge resistors Automatic discharge system For each main capacitor bank: 2 x (2 / 1000V / 10 shots 50kJ) in series; Discharge time below 50V: 1.2s Discharge peak power: 2 x 125 kW

6. 2)- Main capacitor bank discharge contactor Automatic discharge system For each main capacitor bank: LTC 100 type, 1-pole, NC Rugged type, railway applications Peak current: 1000A, = 0.4s

7. 2)- Main capacitor bank discharge resistors Manual discharge and grounding system For each main capacitor bank: 2 x (0.5 / 1000V / 1 shot 50kJ) in series; Discharge time below 50V: 0.3s Discharge peak power: 2 x 500 kW

8. 2)- Main capacitor bank discharge contactor Manual discharge and grounding system For each main capacitor bank: 3 pole, 315 A Switch disconnectors type: OT315E12P Peak current: 1000A, = 0.4s

9. 3)- H-bridge capacitor bank discharge resistors Manual and automatic system In case the fuse breaks, it is important to keep a discharge path for the H-bridge capacitor banks For each capacitor bank: - 1 Resistor, 22 /(One 4.5kJ shot per 5h)/1kV, type rod 708A, for the manual discharge circuit; - 1 Resistor, 22 /(One 4.5kJ shot per 5h)/1kV, type rod 708A, for the automatic discharge circuit; Type rod 708A; Do= 20mm; L= 70mm

10. Internal&External Fast Stops, Door Switches One Internal Fast Stop (Red button) is present near the control cabinet; One External Fast Stop is available for remote protection in the hard- wired control port (RF-LPS interface cable); Every door is equipped with a door switch; Internal Fast Stop (Red button) All these signals are amongst the most critical for personnel safety and are therefore treated the same way (SIL 3 level): Each signal is individually hard-wired to a safety PLC (ABB Pluto series), using wires placed in mechanical protective conduits; Whenever one or several of these signals are activated: the safety PLC de-energises the Under-Voltage Release (UVR) coil of the Main Circuit Breaker (MCB); Simultaneously, the safety PLC de-energises the coils of the capacitor discharge contactors (LTC 100), triggering their automatic discharge; Simultaneously, the safety PLC sends a signal to the central controller to bring the state machine to off state (switch off all IGBT s, contactors, etc.); Safety PLC (ABB Pluto)
