GGBS in Concrete Technology
Building
and
Construction
Engineering
Department
Constructional
Technology
2
nd
class
Lecture
(5
): supplementary cementitious
materials (SCMs) part 2
lecturer
:
Ruqayah Hayder
Ground granulated blast slag (GGBS)
GGBS (Ground Granulated Blast-furnace Slag)
is a cementitious
material whose main use is in concrete.
GGBS
is a by-product from the blast-furnaces used to make iron.
How is it produced?
Blast-furnaces operate at temperatures of about
1,500°C and are fed with a carefully controlled mixture of iron ore, coke
and limestone. The iron ore is reduced to iron and the remaining materials
form a slag that floats on top of the iron.
This slag is periodically tapped off as a molten liquid and if it is to be used
for the manufacture of GGBS it has to be rapidly quenched in large
volumes of water.
(GGBS)
production
https://www.youtube.com
/watch?v=0EqizKAD7vc
Typical chemical and physical composition of
GGBS
GGBS concrete
Ground granulated blast-furnace slag is off-white in color and
substantially lighter than Portland cement CEM I.
This whiter colour is also seen in concrete made with GGBS, especially at
50% replacement.
GGBS concrete
On its own, GGBS hardens slowly
for use in concrete, it needs to be activated by combining it with an
activator (typically Portland cement CEM I but alkali activation is also
used).
A typical combination is 50% GGBS with 50% CEM I
But, percentages of GGBS anywhere between 20 and 80% are commonly
used.
The greater the percentage of GGBS, the greater will be the effect on
concrete properties
GGBS concrete
Setting times
With GGBS, the setting time will be extended slightly.
An extended setting time is advantageous in that the concrete will remain
workable longer.
This is particularly useful in warm weather.
Water demand
There will be small reduction in water demand due to the difference in the
rheological behavior between GGBS and Portland cement
GGBS concrete
Strength gain in GGBS concrete
•
The rate of reaction and strength development of GGBS concrete is slower
than equivalent concrete made with Portland cement CEM
•
Typically the 7-day strength of a ggbs concrete will be 55-65% of the 28-
day strength compared to 70-80% for a similar CEM I Portland cement
concrete.
•
The reduction in early-strength will be more noticeable at high GGBS
levels and low temperatures
GGBS concrete
Relative strength development of concrete with different cement types
GGBS concrete
Relative strength development of concrete with different cement types
GGBS concrete
Relative strength development of concrete with different cement types
Advantages of GGBS
Increases the strength and durability of the concrete structure
Better workability, making placing and compaction easier
Reduces the risk of thermal cracking in large pouring
Reduced shrinkage cracks
It reduces voids and permeability in concrete
Gradual hydration of GGBS generates both lower peak and less total
overall heat
Considerable sustainability benefits
application of GGBS
GGBS is used to make durable concrete
structures in combination with ordinary
portland cement
Major uses of GGBS are in the production of
quality-improved slag cement and in the
production of ready-mixed concrete.
application of GGBS
https://www.youtube.com/watch?v=YB-MpWCgUuo
•
https://ukcsma.co.uk/what-is-ggbs/
•
https://ukcsma.co.uk/ggbs-concrete/
•
https://www.made-in-china.com/showroom/lipeibao/product-
detailtMOQyAuCXnUF/China-GGBS-Ground-Granulated-
Blast-Furnace-Slag-.html
•
https://www.constrofacilitator.com/what-are-the-advantages-
and-applications-of-ggbs/
