Floating Point
Representation
Higher Computing Science
Introduction
•
In computer systems, decimal numbers are represented in memory
using
scientific notation
.
•
This means that a number such as 53458.243 can be represented as
0.53458243 x 10
5
•
To represent in this way, we move the decimal point to the
start
of
the number and then multiply by 10 to the power of
places moved
(which in this case is 5)
•
1234.56789 would become
0.123456789 x 10
4
•
3.424443 would become
0.3424443 x 10
1
Representing In Binary
•
At Higher level, you need to know how to use this for numbers in
binary
•
At National 5 level you will have already learned the terms
mantissa
and
exponent
•
The mantissa is used to store the
precision
of a number – any number
that comes after the decimal point
•
For example, the mantissa for the number 0.53458243 x 10
5
would be
53458243
•
The exponent is used to store the
range
of a number – the number
used as the power
•
For example, the exponent for the number 0.53458243 x 10
5
would be
5
Representing in Binary
•
The mantissa and exponent must be represented in
binary
•
This representation is known as
Floating Point
•
Denary numbers make use of 10 digits – 0, 1, 2, 3, 4, 5, 6, 7, 8 and 9
•
Binary makes use of only
two
digits –
0 and 1
•
Instead of multiplying by 10 to the power … we will now be
multiplying by
2 to the power
…
Structure
•
To help with this, we will use the table shown below
•
The
fixed point
will contain the original number
•
The
floating point
will show the number after being moved
•
The
sign bit
will be one binary digit
•
The
mantissa
will store the numbers after the decimal point
•
The
exponent
will store the number used as the power
Examples
•
We will look at four different examples
1.
Using a
positive
number and moving the decimal point to the
left
2.
Using a
positive
number and moving the decimal point to the
right
3.
Using a
negative
number and moving the decimal point to the
left
4.
Using a
negative
number and moving the decimal point to the
right
Example 1
•
How would 11011.0011 be represented in binary floating point
representation using 16 bits for the mantissa (including the sign bit) and 8
bits for the exponent?
•
To begin with, represent this number using floating point
•
0.110110011 x 2
5
•
As we are using binary, we cannot use the number 5
•
The number 5 converted into binary is:
•
Therefore, we can write this number as
0.110110011 x 2
101
Example 1 (cont.)
•
Next, we need to calculate the
sign bit
•
The sign bit indicates whether a number is
positive
or
negative
•
If it is positive then it is represented with a
0
•
If it is negative then it is represented with a
1
•
In this case, 11011.0011 is a positive number so the sign bit is
0
Example 1 (cont.)
•
Next, we need to calculate the mantissa
•
As we already know that this is the number after the decimal point in
floating point representation (0.110110011 x 2
101
), the mantissa is
110110011
•
There are a total of 9 digits used here (known as bits) but the question
states we must use 16 bits for the mantissa including the sign bit
•
As we have already used a bit for the sign, we now have 15 bits
•
We now need to add a 0 at the
end
of the
mantissa
until we use 15 bits
•
This would give us
110110011000000
•
We have added 6 bits at the end of the mantissa to now give us 15 bits
Example 1 (cont.)
•
Next, we need to calculate the exponent
•
We already know that we are moving 5 (101, which uses 3 bits in
total) places.
•
As we are using 8 bits, we need to add 5 0s at the
start
of the
exponent
.
•
This is
00000101
.
Example 2
•
How would 0.0001101 be represented in binary floating point
representation using 16 bits for the mantissa (including the sign bit) and 8
bits for the exponent?
•
To begin with, represent this number using floating point
•
0.1101 x 2
-3
•
Notice that we use
-3
(this is because we are moving in the
opposite
direction
)
•
The number 3 converted into binary is:
•
Therefore, we can write this number as
0.1101 x 2
-11
Example 2 (cont.)
•
Next, we need to calculate the
sign bit
•
The sign bit indicates whether a number is
positive
or
negative
•
If it is positive then it is represented with a
0
•
If it is negative then it is represented with a
1
•
In this case, 0.0001101 is a positive number so the sign bit is
0
Example 2 (cont.)
•
Next, we need to calculate the mantissa
•
As we already know that this is the number after the decimal point in
floating point representation (0.1101 x 2
-11
), the mantissa is
1101
•
There are a total of 4 bits used but the question states we must use 16 bits
for the mantissa including the sign bit
•
As we have already used a bit for the sign, we now have 15 bits
•
We now need to add a 0 at the
end
of the
mantissa
until we use 15 bits
•
This would give us
110100000000000
•
We have added 11 bits at the end of the mantissa to now give us 15 bits
Example 2 (cont.)
•
Next, we need to calculate the exponent
•
We already know that we are moving
-3
places
•
As we are using a negative number, this has to be represented using
two’s complement
•
This is
11111101
Example 3
•
How would -111.00011 be represented in binary floating point
representation using 16 bits for the mantissa (including the sign bit) and 8
bits for the exponent?
•
To begin with, represent this number using floating point
•
-0.11100011 x 2
3
•
As we are using binary, we cannot use the number 3
•
The number 3 converted into binary is:
•
Therefore, we can write this number as
-0.11100011 x 2
11
Example 3 (cont.)
•
Next, we need to calculate the
sign bit
•
The sign bit indicates whether a number is
positive
or
negative
•
If it is positive then it is represented with a
0
•
If it is negative then it is represented with a
1
•
In this case, -111.00011 is a negative number so the sign bit is
1
Example 3 (cont.)
•
Next, we need to calculate the mantissa
•
As we already know that this is the number after the decimal point in
floating point representation (-0.11100011 x 2
11
), the mantissa is
11100011
•
There are a total of 8 bits used but the question states we must use 16 bits
for the mantissa including the sign bit
•
As we have already used a bit for the sign, we now have 15 bits
•
We now need to add a 0 at the
end
of the
mantissa
until we use 15 bits
•
This would give us
111000110000000
•
We have added 7 bits at the end of the mantissa to now give us 15 bits
Example 3 (cont.)
•
Next, we need to calculate the exponent
•
We already know that we are moving 3 (11, which uses 2 bits in total)
places.
•
As we are using 8 bits, we need to add 6 0s at the
start
of the
exponent
.
•
This is
00000011
.
Example 4
•
How would -0.000000101 be represented in binary floating point
representation using 16 bits for the mantissa (including the sign bit) and 8
bits for the exponent?
•
To begin with, represent this number using floating point
•
-0.101 x 2
-6
•
Notice that we use
-6
(this is because we are moving in the
opposite
direction
)
•
The number 6 converted into binary is:
•
Therefore, we can write this number as -
0.101 x 2
-110
Example 4 (cont.)
•
Next, we need to calculate the
sign bit
•
The sign bit indicates whether a number is
positive
or
negative
•
If it is positive then it is represented with a
0
•
If it is negative then it is represented with a
1
•
In this case, -0.000000101 is a negative number so the sign bit is
1
Example 4 (cont.)
•
Next, we need to calculate the mantissa
•
As we already know that this is the number after the decimal point in
floating point representation (
-0.101 x 2
-6
), the mantissa is
101
•
There are a total of 3 bits used but the question states we must use 16 bits
for the mantissa including the sign bit
•
As we have already used a bit for the sign, we now have 15 bits
•
We now need to add a 0 at the
end
of the
mantissa
until we use 15 bits
•
This would give us
101000000000000
•
We have added 12 bits at the end of the mantissa to now give us 15 bits
Example 4 (cont.)
•
Next, we need to calculate the exponent
•
We already know that we are moving
-6
places
•
As we are using a negative number, this has to be represented using
two’s complement
•
This is
11111010
