1. Embracing Heterogeneity with Dynamic Core Boosting Hyoun Kyu Cho and Scott Mahlke University of Michigan May 20, 2014 1 University of Michigan Electrical Engineering and Computer Science

2. Parallel Programming Core1 Core2 Workload Core3 Core4 2 University of Michigan Electrical Engineering and Computer Science

3. Workload Imbalance Among Threads Asymmetric S/W Control flow divergence Non-deterministic memory latencies Synchronization operations Asymmetric H/W Heterogeneous multicores Core-to-core process variation 3 University of Michigan Electrical Engineering and Computer Science

4. Performance Impact of Asymmetric H/W Symmetric 8 Cores vs. 8 Cores w/ variations 4 University of Michigan Electrical Engineering and Computer Science

5. CPU Time Wasted for Synchronization Homogeneous Heterogeneous 5 University of Michigan Electrical Engineering and Computer Science

6. Thread Criticality due to Workload Imbalance Barrier Idle T1 T2 T3 T4 T5 time T1 T2 T3 T4 T5 time 6 University of Michigan Electrical Engineering and Computer Science

7. Accelerating Critical Path w/ Core Boosting Barrier Idle T1 T2 T3 T4 T5 time T1 T1 T2 T2 T3 T3 T4 T4 T5 T5 time time 7 University of Michigan Electrical Engineering and Computer Science

8. Modeling Workload Imbalance & Boosting 8 University of Michigan Electrical Engineering and Computer Science

9. Boosting Assignment Data parallel programs Worker Worker Worker Worker Worker Pipeline parallel programs Stage4 Stage3 Stage1 Stage2 9 University of Michigan Electrical Engineering and Computer Science

10. Boosting Data Parallel Programs Greedy scheduling 10 University of Michigan Electrical Engineering and Computer Science

11. Boosting Pipeline Parallel Programs Epoch-based scheduling Monitors CPU utilization with H/W performance counter Assigns boosting budget at the end of epoch 11 University of Michigan Electrical Engineering and Computer Science

12. Dynamic Core Boosting 12 University of Michigan Electrical Engineering and Computer Science

13. Progress Monitoring Example pthread_barrier_wait(barrier); period = calc_period_LID_007(start, end); for ( i = start ; i < end ; i++ ) { compute( ); if ( side_exit ) { SET_PROGRESS_TO(MAX_PROGRESS_007); break; } if ( ( ( end i ) % period ) == 0 ) PROGRESS_STEP_FORWARD; } pthread_barrier_wait(barrier); 13 University of Michigan Electrical Engineering and Computer Science

14. Evaluation Methodology Asymmetry emulation with Dynamic Binary Translation Slow down proportionally instead of accelerating 8 cores with frequency variation 1 core boosted, boosting rate = 1.5x Compares Heterogeneous Reactive DCB 14 University of Michigan Electrical Engineering and Computer Science

15. Performance Improvement Heterogeneous Reactive DCB 1.0 Normalized Execution Time 0.9 0.8 0.7 0.6 0.5 15 University of Michigan Electrical Engineering and Computer Science

16. Synchronization Overheads Heterogeneous Reactive DCB 80% 70% Relative CPU Time 60% 50% 40% 30% 20% 10% 0% 16 University of Michigan Electrical Engineering and Computer Science

17. Thread Arrival Time 17 University of Michigan Electrical Engineering and Computer Science

18. Conclusion DCB mitigates workload imbalance in performance asymmetric CMPs Accelerating critical threads Coordinating compiler, runtime, and architecture for near-optimal assignment Overall, improves performance by 33%, outperforming a reactive boosting scheme by 10% 18 University of Michigan Electrical Engineering and Computer Science

19. Thank you! 19 University of Michigan Electrical Engineering and Computer Science

20. Core Boosting with Frequency Scaling Transition time < 10ns [Dreslinski`12] 20 University of Michigan Electrical Engineering and Computer Science

21. Asymmetry Emulation with DBT 21 University of Michigan Electrical Engineering and Computer Science

22. Evaluation Platform Accuracy 12% 10% Relative Error 8% 6% 4% 2% 0% 22 University of Michigan Electrical Engineering and Computer Science
