Dozer Performance Characteristics in Construction

Dozer
Lecture 5
TSP-
308 MPK


Ferdinand Fassa
2
OUTLINE
1.
Introduction
2.
Dozer Performance Characteristics
Classified on the basis of running gear
Blade
Dozer Function
3.
Dozer Production Estimating
4.
Dozer Safety
Introduction


A dozer is Tractor unit that has blade attached to push
material from one location to another.

It is designed to provide for drawbar work.

The amount of material the dozer moves is
dependent
 on the
quantity that will remain in front
of the blade during the
push.

3
Introduction (2)
4

M
achine used to push or pull objects
/ material by means of mounted
attachment or drawbar
Function
To doze dirt
To push or pull (add traction - drawbar)
moving equipment
To pull ripper
5
6
7
8
9
10
11
12
13
14
15

16
Dimension & Dozing Position
Dozer Performance Characteristics (2)
Dozer Performance Characteristics
17
Classified on the basis of running gear:
Crawler type
Wheel type

Dozer Function
Stripping
Backfilling
Spreading
18
Dozer Performance Characteristics (3)
19
Dozing Productivity
Blade volume,
V
b
 = 0.8HWL
Production,
P
b
 = (V
b
)/(T
p
 + T
r
 + T
m
)
H

= height of pile of dirt at the inside edge of each track
W

= width of pile at the inside edge of each track
L

= length of dirt pile
  width of blade
T
p

= time to push (doze)
T
r

= time to return (usually backward in reverse)
T
m

= time to maneuver
Dozer Production Estimating
20
Blade Volume
Blade Volume

Doze a full blade, then
lift blade while moving
forward on a level
surface until a pile is
formed.
Measure the width of
the pile (W)
perpendicular to the
blade and in the same
line with the inside track
or wheel.

Average the two
measurements.
Measure the height (H)
of the pile in a similar
manner.
Measure the length (L) of
the pile.
Blade Load (LCY) =
0.0139 x H x W x L
21
Estimating Dozer Production
Estimating Dozer Production
Total Cycle Time = Fixed Cycle Time + Variable
Cycle Time
Dozer Production = (Blade Capacity * Efficiency)/ Total Cycle Time
22
Estimating Dozer Production
Estimating Dozer Production
Fixed Cycle Time:
Maneuver, Gear Change, Loading & Dumping.
23
Estimating Dozer Production
Estimating Dozer Production
Variable Cycle Time:
Doze & Return.
24
Dozer Production
Dozer Production
25
Dozer Production Example
Dozer Production Example
A power-shift crawler tractor has a rated blade
capacity of 10 LCY.
The dozer is excavating loose common earth and
pushing it a distance of 200 ft.
Maximum reverse speed in third range is 5 mph.
Estimate the production of the dozer if job
efficiency is 50 min/h.
26
Dozer Production Example
Dozer Production Example
Fixed Time = 0.05 min        (Table
slide 22
)
Dozing Speed = 2.5 mph     (Table
slide 23
)


The machine in example above has an Owning & Operating cost
of $ 40.5 per hour. Operator in the area where the proposed
work will be performed are paid a wage of $ 15.5 per hour.
What is the unit cost for pushing the material?
27
28
Job Management ~ Techniques
Job Management ~ Techniques

Downhill Dozing
Downhill Dozing
Minimal grade resistance
Blade load is increased
Reduces cycle times
Slot Dozing
Slot Dozing
Shallow trench or path cut between loading and dumping
areas to increase the blade capacity that can be carried
on each cycle.
As much as 50% increase in capacity.
Blade-to-Blade Dozing
Blade-to-Blade Dozing
Combined capacity is greater than each separately.
Can be mechanically coupled for large jobs.
29
Slot Dozing
30
Blade to Blade Dozing
Practice
31
Dozing performed at a slow speed 2 mph. Return speed Is  4
mph whit maneuve time is about 0.05 min.
The dozer is
excavating loose common earth and pushing it a distance
of 95 ft. A track dozer can  push an average blade load 7
lcy.
Owning & Operating cost of $ 50 per hour. Operator in the
area where the proposed work will be performed are paid a
wage of $ 12 per hour.
Q..?
1.
What production in loose cubic yard can be expected?
2.
Assume a percent swell of 0.25 and a job efficiency equal to
45 min per hour. What is the actual production that can be
expected in bank cubic yard..?
3.
What is the unit cost for pushing this material?
32
Practice
33
Answer
Practice (2)
34
Answer
Thank You
35
Slide Note
Embed
Share

A dozer is a significant tractor unit with a blade used for pushing materials in construction projects. It is classified based on running gear as crawler or wheel type, each with its distinct advantages. Dozers play essential roles in various functions like dozing dirt, pushing equipment, and more. Understanding their performance characteristics is crucial for efficient operation and project success.

  • Construction
  • Dozer
  • Performance
  • Characteristics
  • Equipment

Uploaded on Sep 18, 2024 | 0 Views


Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

E N D

Presentation Transcript


  1. Lecture 5 Dozer TSP-308 MPK Ferdinand Fassa

  2. OUTLINE Introduction Dozer Performance Characteristics Classified on the basis of running gear Blade Dozer Function Dozer Production Estimating Dozer Safety 1. 2. 3. 4. 2

  3. Introduction A dozer is Tractor unit that has blade attached to push material from one location to another. It is designed to provide for drawbar work. The amount of material the dozer moves is dependent on the quantity that will remain in front of the blade during the push. 3

  4. Introduction (2) Machine used to push or pull objects / material by means of mounted attachment or drawbar Function To doze dirt To push or pull (add traction - drawbar) moving equipment To pull ripper 4

  5. 5

  6. 7

  7. 9

  8. 12

  9. 13

  10. 15

  11. Dozer Performance Characteristics (2) Dimension & Dozing Position TILTING PITCHING 16 ANGLING

  12. Dozer Performance Characteristics Classified on the basis of running gear: Crawler type Wheel type Crawler Dozer Wheel Dozer Work on variety of soil Good on firm soils and concrete Work over almost terrain Best for level and downhill work wet weather Good for short work distances Good for long travel distances Can handle tight soil Best in handling loose soils Slow return speeds, 5-10 mph Fast Return speeds, 8 -26 mph Can push large blade loads Can handle only moderate blade loads 17

  13. Dozer Performance Characteristics (3) Dozer Function Stripping Backfilling Spreading 18

  14. Dozer Production Estimating Dozing Productivity Blade volume, Vb = 0.8HWL Production, Pb = (Vb)/(Tp + Tr + Tm) H W L Tp Tr Tm = height of pile of dirt at the inside edge of each track = width of pile at the inside edge of each track = length of dirt pile width of blade = time to push (doze) = time to return (usually backward in reverse) = time to maneuver L 19 H1 H2 W1 W2

  15. Estimating Dozer Production Total Cycle Time = Fixed Cycle Time + Variable Cycle Time Dozer Production = (Blade Capacity * Efficiency)/ Total Cycle Time 21

  16. Estimating Dozer Production Fixed Cycle Time: Maneuver, Gear Change, Loading & Dumping. Typical Dozer Fixed Cycle Times Operating Conditions Power-Shift Transmission Direct-Drive Transmission Hard Digging Time (min) 0.05 0.10 0.15 22

  17. Estimating Dozer Production Variable Cycle Time: Doze & Return. Typical Dozer Operating Speeds Operating Conditions Hard Materials, Haul < or = 100 ft Hard Materials, Haul > 100 ft Loose Material, Haul < or = 100 ft Loose Material, Haul > 100 ft Speeds (mph) 1.5 2.0 2.0 2.5 23

  18. Dozer Production = + + Cycle Time pushtime returntime maneuverti me blade load x 60 min Production = cycle time O & perhour x O operator perhour = U nitCost production on job efficiency 24

  19. Dozer Production Example A power-shift crawler tractor has a rated blade capacity of 10 LCY. The dozer is excavating loose common earth and pushing it a distance of 200 ft. Maximum reverse speed in third range is 5 mph. Estimate the production of the dozer if job efficiency is 50 min/h. 25

  20. Dozer Production Example Fixed Time = 0.05 min (Table slide 22) Dozing Speed = 2.5 mph (Table slide 23) 200 ft = = Dozing Time 60 min/ 0.91 min x hr 2.5 mph 5280 fpm 200 ft = = Return Time 60 / 0.45 min x mim hr 5.0 mph 280 5 fpm = + + = Cycle Time 0.05 0.91 0.45 1.41 min 26 lcy x 10 50 min hr = = Production 354.6 LCY hr 1.41 min

  21. The machine in example above has an Owning & Operating cost of $ 40.5 per hour. Operator in the area where the proposed work will be performed are paid a wage of $ 15.5 per hour. What is the unit cost for pushing the material? 15.5 + 40.5 = = nitCost U . 0 $ 157 perlcy 354.6 27

  22. Job Management ~ Techniques Downhill Dozing Minimal grade resistance Blade load is increased Reduces cycle times Slot Dozing Shallow trench or path cut between loading and dumping areas to increase the blade capacity that can be carried on each cycle. As much as 50% increase in capacity. Blade-to-Blade Dozing Combined capacity is greater than each separately. Can be mechanically coupled for large jobs. 28

  23. Slot Dozing 29

  24. Blade to Blade Dozing 30

  25. Practice Dozing performed at a slow speed 2 mph. Return speed Is 4 mph whit maneuve time is about 0.05 min. The dozer is excavating loose common earth and pushing it a distance of 95 ft. A track dozer can push an average blade load 7 lcy. Owning & Operating cost of $ 50 per hour. Operator in the area where the proposed work will be performed are paid a wage of $ 12 per hour. Q..? 1. What production in loose cubic yard can be expected? 2. Assume a percent swell of 0.25 and a job efficiency equal to 45 min per hour. What is the actual production that can be expected in bank cubic yard..? 3. What is the unit cost for pushing this material? 31

  26. = + + Cycle Time pushtime returntime maneuverti me blade load x 60 min Production = cycle time O & perhour x O operator perhour = U nitCost production on job efficiency 32

  27. Practice Answer 95 ft = = Dozing Time 60 min/ . 0 54 min x hr mph 2. 5280 fpm 95 ft = = Return Time 60 min/ . 0 27 min x hr mph 4 5280 fpm lcy x 7 60 min hr = = Production 488.37 LCY hr 0.86 min 33

  28. Practice (2) Answer 488.37 45 = = Production BCY 93 2 hr x 1.25 60 12 + 50 = = nitCost U . 0 $ 212 perbcy 293 34

  29. Thank You 35
