1. Lesson 5 Decision Tree (Rule Based Approach)

2. Example

3. Example Features

4. Example Class

5. Example Given : <sunny, cool, high, true> Predict, if there will be a match?

6. Example Given : <sunny, cool, high, true> Predict, if there will be a match? Assume that I have a set of rules: - If ((lookout=sunny) and ( humudity=high) and (windy=false)) then (yes) else (no) - If (lookout=overcast) then (yes) If ((lookout=sunny) and ( humudity=high)) then (yes) else (no) so on .. - -

7. Set of rules can be visualized as a tree.

8. Set of rules can be visualized as a tree. Rule 1: If ((lookout=sunny) and ( humudity=high)) then (yes) else (no)

9. Set of rules can be visualized as a tree. Rule 1: If ((lookout=sunny) and ( humudity=high)) then (yes) else (no) Rule 2: If (lookout=overcast) then (yes)

10. Set of rules can be visualized as a tree. Rule 1: If ((lookout=sunny) and ( humudity=high)) then (yes) else (no) Rule 2: If (lookout=overcast) then (yes) Rule 3: If ((lookout=rain) and ( windy=true)) then (no) else (yes)

11. Many possible Trees

12. Many possible Trees Which Tree is the Best?

13. Which feature should be used to break the dataset? Types of DT ID3 (Iterative Dichotomiser 3) C4.5 (Successor of ID3) CART (Classification and Regression Tree) Random Forest

14. ID3

15. ID3 1. Calculate the entropy of the total dataset => H(S)=0.9911 we get a database with single class p+nlog2( p+n) p+nlog2( p+n) p p n n Entropy(S)= Entropy(4F,5M) = -(4/9)log2(4/9) - (5/9)log2(5/9) = 0.9911

16. ID3 1. Calculate the entropy of the total dataset 2. Choose and attribute and Split the dataset by an attribute we get a database with single class

17. ID3 Calculate the entropy of the total dataset Choose and attribute and Split the dataset by an attribute Calculate the entropy of each branch get a database with single class 1. 2. 3. Entropy(3F,2M) = -(3/5)log2(3/5) - (2/5)log2(2/5) = 0.9710 Entropy(1F,3M) = -(1/4)log2(1/4) - (3/4)log2(3/4) = 0.8113

18. ID3 Calculate the entropy of the total dataset Choose and attribute and Split the dataset by an attribute Calculate the entropy of each branch Calculate Information Gain of the split 1. 2. 3. 4. get a database with single class ??(?1) = ? ? [? ?1? ?1 + ? ?2? ?2] Gain(Hair Length <= 5) = 0.9911 (4/9 * 0.8113 + 5/9 * 0.9710 ) = 0.0911 Entropy(3F,2M) = -(3/5)log2(3/5) - (2/5)log2(2/5) = 0.9710 Entropy(1F,3M) = -(1/4)log2(1/4) - (3/4)log2(3/4) = 0.8113

19. What is Information Gain?

20. What is Information Gain?

21. Which split is better?

22. What is information gain?

23. What is information gain? Reduction in uncertainty of the parent dataset after the split. ??(?1) = ? ? [? ?1? ?1 + ? ?2? ?2]

24. ID3 Calculate the entropy of the total dataset Choose and attribute and Split the dataset by an attribute Calculate the entropy of each branch Calculate Information Gain of the split 1. 2. 3. 4. get a database with single class ??(?1) = ? ? [? ?1? ?1 + ? ?2? ?2] Gain(Hair Length <= 5) = 0.9911 (4/9 * 0.8113 + 5/9 * 0.9710 ) = 0.0911 Entropy(3F,2M) = -(3/5)log2(3/5) - (2/5)log2(2/5) = 0.9710 Entropy(1F,3M) = -(1/4)log2(1/4) - (3/4)log2(3/4) = 0.8113

25. ID3 Calculate the entropy of the total dataset Choose and attribute and Split the dataset by an attribute Calculate the entropy of each branch 1. 2. 3. Calculate Information Gain of the split 4. Repeat 2, 3, 4 for all Attributes The attribute that yields the largest IG is chosen for the decision node. 5. 6. Gain(Hair Length <= 5) = 0.0911 Gain(Weight <= 160) = 0.5900 Gain(Age <= 40) = 0.0183

26. ID3 Calculate the entropy of the total dataset Choose and attribute and Split the dataset by an attribute Calculate the entropy of each branch 1. 2. 3. Calculate Information Gain of the split 4. Repeat 2, 3, 4 for all Attributes The attribute that yields the largest IG is chosen for the decision node. 5. 6.

27. ID3 Calculate the entropy of the total dataset 1. Choose and attribute and Split the dataset by an attribute 2. Calculate the entropy of each branch 3. Calculate Information Gain of the split 4. Repeat 2, 3, 4 for all Attributes 5. The attribute that yields the largest IG is chosen for the decision node. 6. Repeat 1 to 6 for all sub-databases till we get sub- databases with single class 7.

28. ID3 Calculate the entropy of the total dataset 1. Choose and attribute and Split the dataset by an attribute 2. Calculate the entropy of each branch 3. Calculate Information Gain of the split 4. Repeat 2, 3, 4 for all Attributes 5. The attribute that yields the largest IG is chosen for the decision node. 6. Repeat 1 to 6 for all sub-databases till we get sub- databases with single class 7.
