CRTP: A Guide to Crazyflie's Real-Time Protocol
The Crazy Real
Time Protocol
What is the CRTP?
The CRTP is the Crazyflie’s custom packet communication system
between the crazyflie client, the python library, or custom ground
stations
What can be accessed with the CRTP?
The CRTP allows for communication over:
-
The onboard console of the crazyflie (no display unless connected to a client that can)
-
Getting and setting parameters of the Crazyflie firmware
-
The high level commander (so setpoints can be sent over the CRTP)
-
Non-volatile memory
-
Data logging
-
Anything related to localization i.e. the overhead camera system
-
It can send generic setpoints
Port Allocation for all the things just mentioned
How to send packets via the CRTP
Currently there are two ways to use the CRTP, the Crazyradio and USB.
Unfortunately, it seems there is no support for CRTP to communicate over WiFi. However,
this doesn’t mean it is impossible to emulate it. Some discussion about this can be found here:
https://forum.bitcraze.io/viewtopic.php?t=4373
and here:
https://forum.bitcraze.io/viewtopic.php?t=3435
CRTP Packet Header
Detailed information on how to use each port
can be found here:
https://www.bitcraze.io/documentation/repositor
y/crazyflie-firmware/master/functional-
areas/crtp/
Some miscellaneous helpful
information/tips
-
The TOC (table of contents) holds all the parameters for the Crazyflie firmware (or at
least the parameters the firmware specifies to be apart of the TOC)
-
To retrieve a specific TOC parameter, users need the id of the parameter. There is no
list of all the IDs connected to the parameters as each crazyflie does not have the same
ID setup. The TOC can be downloaded and then users can find the IDs they are looking
for.
-
Custom parameters can be added to the TOC.
-
Be mindful about the contents of the packet being sent to the crazyflie. The CRTP is
pretty strict and users will not get the result they are looking for if there are accidental
garbage values or the packet is not the correct size.
