UNIT III

Context Free Grammar and

Languages

Ms. Shital Pawar

Assistant Professor

Computer Engineering Department

Bharati Vidyapeeth’s College of Engineering for Women,

Pune 43

Formal Definition

•

CFG stands for context-free grammar. It is  a formal grammar which is

used to generate all possible patterns of strings in a given formal

language. Context-free grammar G can be defined by four tuples as:

•

G = (V, T, P, S)  Where,

•

G is the grammar, which consists of a set of the production rule. It is

used to generate the string of a language.

•

T is the final set of a terminal symbol. It is denoted by lower case

letters.

•

V is the final set of a non-terminal symbol. It is denoted by capital

letters.

•

P is a set of production rules, which is used for replacing non-terminals

symbols(on the left side of the production) in a string with other

terminal or non-terminal symbols(on the right side of the production).

•

S is the start symbol which is used to derive the string. We can derive

the string by repeatedly replacing a non-terminal by the right-hand

side of the production until all non-terminal have been replaced by

terminal symbols.

Example 1:

Construct the CFG for the language having any number of a's

over the set ∑= {a}.

Solution:

As we know the regular expression for the above language is

r.e. = a*

Production rule for the Regular expression is as follows:

S → aS    rule 1

S → ε     rule 2

Now if we want to derive a string "aaaaaa", we can start with start

symbols.

 S

aS

aaS          rule 1

aaaS         rule 1

aaaaS        rule 1

aaaaaS       rule 1

aaaaaaS      rule 1

aaaaaaε      rule 2

aaaaaa

Example 2

Construct a CFG for the regular expression (0+1)*

Solution:

The CFG can be given by,

Production rule (P):

S → 0S | 1S                        e.g.    1010             1S        (S



1S)

S → ε                                                                   10S      (S



0S)

                                                                             101S    (S



1S)

                                                                             1010S   (S



0S)

                                                                              1010    (S



 ε

)

     The rules are in the combination of 0's and 1's with the start

symbol. Since (0+1)* indicates {ε, 0, 1, 01, 10, 00, 11, ....}. In this set,

ε is a string, so in the rule, we can set the rule S → ε.

Example 3

Construct a CFG for a language L = {wcwR | where w € (a, b)*}

Solution:

The string that can be generated for a given language is {aacaa, bcb,

abcba, bacab, abbcbba, ....}

The grammar could be:

S → aSa     rule 1

S → bSb     rule 2

S → c       rule 3

Now if we want to derive a string "abbcbba", we can start with start

symbols.

S → aSa

S → abSba          from rule 2

S → abbSbba     from rule 2

S → abbcbba     from rule 3

Thus any of this kind of string can be derived from the given

production rules.

Example 4

Construct a CFG for the language L = a

n

b

2n

 where n>=1.

Solution:

The string that can be generated for a given language is {abb, aabbbb,

aaabbbbbb....}.

The grammar could be:

S → aSbb | abb

Now if we want to derive a string "aabbbb", we can start with start

symbols.

S → aSbb

S → aabbbb

Example 5

Construct a CFG for the language L={w

ϵ

{a,b}*|w is palindrome of

odd length}

Solution:

     As string is odd length palindrome middle letter can be either a or b.

     Smallest string for given language can be either a or b.

e.g: L={a, b, aba, bab, babab, abbba, aabaa, baaab,….}

S



aSa

S



bSb

S



a|b

It can be written as

S



 aSa | bSb | a | b

Example 6

Construct a CFG for the language L={w

ϵ

{a,b}*|w is palindrome of

even length with |w| > 0}

Solution:

     As string is odd length palindrome middle letter can be either a or b.

     Smallest string for given language can be either aa or bb.

e.g: L={aa, bb, abba, baab, babbab, abbbba, aabbaa, baaaab,….}

S



aSa

S



bSb

S



aa|bb

It can be written as

S



 aSa | bSb | aa | bb

Example 7

Construct a CFG for the language L={w

ϵ

{a,b}*|w is palindrome of

even length or odd length with |w| > 0}

Solution:

     As string is odd length palindrome middle letter can be either a or b.

     Smallest string for given language can be either a or b.

e.g: L={a, b, aba, bab, babab, abbba, aabaa, baaab,aa, bb, abba, baab,

babbab, abbbba, aabbaa, baaaab,….}

S



aSa

S



bSb

S



 a|b|aa|bb

It can be written as

S



 aSa | bSb | a | b | aa | bb

Example 8

Construct a CFG for the language L={a

i

 b

j

c

k

 | i = j + k}

Solution:

Outer a’s should be matched with c’s then the remaining  a’s should be

matched with b’s .

e.g. L = {aabc, aaabcc, aaabbc, aaaabbcc, aaaabccc,…..}

S



 aSc |aXc

X



 aXb |ab

Example 9

Construct a CFG for the language L={a

i

 b

j

c

k

 | j = i + k}

Solution:

Outer a’s should be matched with c’s then the remaining  a’s should be

matched with b’s .

e.g. L = {abbc,aabbbc,abbbcc,aabbbbcc,………}

  a

i

 b

i

b

k

c

k

S



 XY

X



 aXb |ab

Y



 bYc | bc

Example 10

Construct a CFG for the language (011+1)*(01)*

Solution:

Let us consider that (011 + 1)* is generated by variable X

X



 011X | 1X |

ε

Let us consider that (01)* is generated by variable Y

Y



 01Y |

ε

By using concatenation rule, we can combine above two production

rules:

So, CFG for given language is,

S



 XY

X



 011X | 1X |

ε

Y



 01Y |

ε

Example 11

Construct a CFG for the language L={a

n

 b

m

| n

 ≠ m

}

Solution:

As n ≠ m number a’s are different than number of b’s.

Let us consider a

n

 is generated

 by variable X

X



 aX | a

Let us consider b

m

is generated

 by variable Y

Y



 bY | b

So, CFG for given language is,

S



 aSb | X | Y

X



 aX | a

Y



 bY | b

Derivation

•

Derivation is a sequence of production rules. It is used to get

the input string through these production rules. During

parsing, we have to take two decisions. These are as follows:

•

We have to decide the non-terminal which is to be replaced.

•

We have to decide the production rule by which the non-

terminal will be replaced.

•

We have two options to decide which non-terminal to be

placed with production rule.

Leftmost Derivation

•

In the leftmost derivation, the input is scanned and replaced with the

production rule from left to right. So in leftmost derivation, we read the

input string from left to right.

Example:



Production rules:

E = E + E

E = E - E

E = a | b



Input

a - b + a



The leftmost derivation is:

E = E + E

E = E - E + E

E = a - E + E

E = a - b + E

E = a - b + a

 Rightmost Derivation

•

In rightmost derivation, the input is scanned and replaced with the

production rule from right to left. So in rightmost derivation, we read the

input string from right to left.

•

Example

•

Production rules:

•

E = E + E

•

E = E - E

•

E = a | b

•

Input

•

a - b + a

•

The rightmost derivation is:

•

E = E - E

•

E = E - E + E

•

E = E - E + a

•

E = E - b + a

•

E = a - b + a



Note:

 When we use the leftmost derivation or rightmost derivation, we

may get the same string. This type of derivation does not affect on getting

of a string.

Example 1

Derive the string "abb" for leftmost derivation and rightmost

derivation using a CFG given by,

S → AB | ε

A → aB

B → Sb

Solution:

•

Leftmost derivation:                                           Rightmost derivatio

n:

Example 2

Derive the string "aabbabba" for leftmost derivation and rightmost

derivation using a CFG given by,

S → aB | bA

A → a | aS | bAA

B → b | bS | aBB

Solution:

Leftmost derivation:

S

aB            S → aB

aaBB          B → aBB

aabB          B → b

aabbS         B → bS

aabbaB        S → aB

aabbabS       B → bS

aabbabbA      S → bA

aabbabba      A →

a

Example 2

Derive the string "aabbabba" for leftmost derivation and rightmost

derivation using a CFG given by,

S → aB | bA

A → a | aS | bAA

B → b | bS | aBB

Rightmost derivation:

S

aB            S → aB

aaBB          B → aBB

aaBbS         B → bS

aaBbbA        S → bA

aaBbba        A → a

aabSbba       B → bS

aabbAbba      S → bA

aabbabba      A → a

Example 3

Derive the string "00101" for leftmost derivation and rightmost

derivation using a CFG given by,

S → A1B

A → 0A | ε

B → 0B | 1B | ε

Solution:

Leftmost derivation:

S

A1B

0A1B

00A1B

001B

0010B

00101B

00101

Example 3

Derive the string "00101" for leftmost derivation and rightmost

derivation using a CFG given by,

S → A1B

A → 0A | ε

B → 0B | 1B | ε

Rightmost derivation:

S

A1B

A10B

A101B

A101

0A101

00A101

00101

Derivation Tree

•

Derivation tree is a graphical representation for the derivation

of the given production rules for a given CFG. It is the simple

way to show how the derivation can be done to obtain some

string from a given set of production rules. The derivation tree

is also called a parse tree.

•

Parse tree follows the precedence of operators. The deepest

sub-tree traversed first. So, the operator in the parent node

has less precedence over the operator in the sub-tree.

Properties of parse tree

•

The root node is always a node indicating start symbols.

•

The derivation is read from left to right.

•

The leaf node is always terminal nodes.

•

The interior nodes are always the non-terminal nodes.

Step 1:                                                                          Step 3:

Step 2:                                                                         Step 4:

Example 1

Production rules:

E = E + E

E = E * E

      E = a | b | c

Input

a * b + c

Example 2

Draw a derivation tree for the string "bab" from the CFG given by

S → bSb | a | b

Solution:

Now, the derivation tree for the string "bbabb" is as follows

:

•

The above tree is a derivation tree drawn for deriving a string bbabb. By

simply reading the leaf nodes, we can obtain the desired string. The same

tree can also be denoted by,

Example 3

Construct a derivation tree for the string aabbabba for the CFG

given by,

S → aB | bA

A → a | aS | bAA

B → b | bS | aBB

Solution:

•

To draw a tree, we will first try to obtain derivation for the string aabbabba

Derivation

Derivation Tree

Ambiguity in Grammar

•

A grammar is said to be ambiguous if there exists more

than one leftmost derivation or more than one rightmost

derivation or more than one parse tree for the given

input string. If the grammar is not ambiguous, then it is

called unambiguous.

•

If the grammar has ambiguity, then it is not good for

compiler construction. No method can automatically

detect and remove the ambiguity, but we can remove

ambiguity by re-writing the whole grammar without

ambiguity.

Example 1

Let us consider a grammar G with the production rule

E → I

E → E + E

E → E * E

E → (E)

I →

ε | 0 | 1 | 2 | ... | 9

Solution:

      For the string "3 * 2 + 5", the above grammar can generate two parse

trees by leftmost derivation:

Since there are two parse trees for a single string "3 * 2 + 5", the grammar G is

ambiguous.

Example 2

Check whether the given grammar G is ambiguous or not.

S → aSb | SS

S → ε

Solution:

For the string "aabb" the above grammar can generate two parse trees

Since there are two parse trees for a single string "aabb", the grammar

G is ambiguous.

Example 3

Check whether the given grammar G is ambiguous or not.

A → AA

A → (A)

A → a

Solution:

     For the string "a(a)aa" the above grammar can generate two

parse trees:

Unambiguous Grammar

•

A grammar can be unambiguous if the grammar does not

contain ambiguity that means if it does not contain more

than one leftmost derivation or more than one rightmost

derivation or more than one parse tree for the given

input string.

•

To convert ambiguous grammar to unambiguous grammar, we

will apply the following rules:

1.  If the left associative operators (+, -, *, /) are used in the

production rule, then apply left recursion in the production

rule. Left recursion means that the leftmost symbol on the

right side is the same as the non-terminal on the left side. For

example,

           X → Xa

2.   If the right associative operates(^) is used in the production

rule then apply right recursion in the production rule. Right

recursion means that the rightmost symbol on the left side is

the same as the non-terminal on the right side. For example,

          X → aX

Example 1

Consider a grammar G is given as follows:

S → AB | aaB

A → a | Aa

B → b

      Determine whether the grammar G is ambiguous or not. If G is

ambiguous, construct an unambiguous grammar equivalent to G.

Solution:

Let us derive the string "aab"

As there are two different parse tree for

deriving the same string, the given

grammar is ambiguous.

Unambiguous grammar will be:

S → AB

A → Aa | a

B → b

Example 2

Show that the given grammar is ambiguous. Also, find an

equivalent unambiguous grammar.

S → ABA

A → aA | ε

B → bB | ε

Solution:

•

The given grammar is ambiguous because we can derive two different

parse tree for string aa.

The unambiguous grammar

is:

S → aXY | bYZ | ε

Z → aZ | a

X → aXY | a | ε

Y → bYZ | b | ε

Example 3

Show that the given grammar is ambiguous. Also, find an

equivalent unambiguous grammar.

E → E + E

E → E * E

E → id

Solution:

Let us derive the string "id + id * id“

As there are two different parse tree

for deriving the same string, the

given grammar is ambiguous.

Unambiguous grammar will be:

E → E + T

E → T

T → T * F

T → F

F → id

Example 4

Check that the given grammar is ambiguous or not. Also, find an

equivalent unambiguous grammar.

 S → S + S

S → S * S

S → S ^ S

S → a

Solution:

The given grammar is ambiguous because the derivation of string aab

can be represented by the following string:

Unambiguous grammar will be:

S → S + A |

A → A * B | B

B → C ^ B | C

C → a

Simplification of CFG

•

As we have seen, various languages can efficiently be

represented by a context-free grammar. All the grammar are

not always optimized that means the grammar may consist of

some extra symbols(non-terminal). Having extra symbols,

unnecessary increase the length of grammar.

•

Simplification of grammar means reduction of grammar by

removing useless symbols. The properties of reduced

grammar are given below:

•

Each variable (i.e. non-terminal) and each terminal of G

appears in the derivation of some word in L.

•

There should not be any production as X → Y where X and Y

are non-terminal.

•

If ε is not in the language L then there need not to be the

production X → ε.

•

Let us study the reduction process in detail.

Non

Reachable

Symbol

Non

generating

Symbol

Removal of Useless Symbols

•

A symbol can be useless if it does not appear on the right-

hand side of the production rule and does not take part in the

derivation of any string.

     That symbol is known as a useless symbol.

•

Similarly, a variable can be useless if it does not take part in

the derivation of any string.

     That variable is known as a useless variable.

Example 1

Remove the useless symbols from given grammar

T → aaB | abA | aaT                  A → aA

B → ab | b                                   C → ad

•

In the above example, the variable 'C' will never occur in the

derivation of any string, so the production C → ad is useless.

•

 So we will eliminate it, and the other productions are written in

such a way that variable C can never reach from the starting

variable 'T'.

•

Production A → aA is also useless because there is no way to

terminate it. If it never terminates, then it can never produce a

string. Hence this production can never take part in any derivation.

•

To remove this useless production A → aA, we will first find all the

variables which will never lead to a terminal string such as variable

'A'. Then we will remove all the productions in which the variable

‘A' occurs.

•

Simplified Grammar is:

      T → aaB | aaT

B → ab | b

Elimination of ε Production

•

The productions of type S → ε are called ε productions. These

type of productions can only be removed from those

grammars that do not generate ε.

•

Step 1:

 First find out all null able non-terminal variable which

derives ε.

•

Step 2:

 For each production A → a, construct all production A

→ x, where x is obtained from a by removing one or more

non-terminal from step 1.

•

Step 3:

 Now combine the result of step 2 with the original

production and remove ε productions.

Example 2

Remove the ε production from the following CFG by preserving

the meaning of it.

S → XYX

X → 0X | ε

Y → 1Y | ε

Solution:

      Now, while removing ε production, we are deleting the rule X → ε

and Y → ε. To preserve the meaning of CFG we are actually placing

ε at the right-hand side whenever X and Y have appeared.

Let us take

S → XYX

If the first X at right-hand side is ε. Then

S → YX

if the last X in R.H.S. = ε. Then

S → XY

If Y = ε then

S → XX

If Y and X are ε then,

S → X

Example 3

Remove the production from the following CFG by preserving the

meaning of it.

S → XYX

X → 0X | ε         Y → 1Y | ε

Solution:

If both X are replaced by ε

S → Y

Now,

S → XY | YX | XX | X | Y

Now let us consider

X → 0X

If we place ε at right-hand side for X then,

X → 0

X → 0X | 0

Similarly Y → 1Y | 1

Collectively we can rewrite the CFG with removed ε production as

S → XY | YX | XX | X | Y

X → 0X | 0

Y → 1Y | 1

Removing Unit Productions

•

The unit productions are the productions in which one non-terminal

gives another non-terminal. Use the following steps to remove unit

production:

•

Step 1:

 To remove X → Y, add production X → a to the grammar rule

whenever Y → a occurs in the grammar.

•

Step 2:

 Now delete X → Y from the grammar.

•

Step 3:

 Repeat step 1 and step 2 until all unit productions are

removed.

Example 4

 construct reduced grammar equivalent to the grammar

S → 0A | 1B | C

A → 0S | 00

B → 1 | A

C → 01

Solution:

S → C is a unit production. But while removing S → C we have to consider

what C gives. So, we can add a rule to S.

S → 0A | 1B | 01

•

Similarly, B → A is also a unit production so we can modify it as

B → 1 | 0S | 00

•

Thus finally we can write CFG without unit production as

S → 0A | 1B | 01

A → 0S | 00

B → 1 | 0S | 00

C → 01

•

As C is non-reachable symbol, we have to remove C. so simplified

grammar after removing C is:

S → 0A | 1B | 01

A → 0S | 00

B → 1 | 0S | 00

Example 5

construct reduced grammar equivalent to the grammar

S



aAa

A



Sb | bcc | DaA

C



abb | DD

D



 aDA

E



 ac

•

Finding non - generating symbols:  D is non – generating symbol

•

So, reduced grammar is after elimination of non – generating symbol D is:

      S



 aAa

A



 Sb | bcc

C



 abb

E



ac

•

Finding Non- reachable symbols: C and E are non- generating symbols:

•

So, reduced grammar after elimination of non -reachable symbols A and E is

       S



 aAa

A



 Sb | bcc

•

As there are no unit productions and

ε

 productions in given grammar so

reduced grammar is :

        S



 aAa

 A



 Sb | bcc

Example 6

Simplify the following grammar:

S



 0A0 | 1B1 | BB

A



 C

B



 S| A

C



 S|

ε

Solution:

•

Elimination of

ε

 production:

S



 0A0 | 1B1 | BB | 00 | 11 | B

A



 C

B



 S| A

C



 S

•

Eliminate Unit Productions: As B



 A



 C



 S



 B

S



 0A0 | 1B1 | BB | 00 | 11

      A



 0A0 | 1B1 | BB | 00 | 11

B



 0A0 | 1B1 | BB | 00 | 11

C



 0A0 | 1B1 | BB | 00 | 11

•

Elimination of non reachable symbol C:

S



 0A0 | 1B1 | BB | 00 | 11

 A



 0A0 | 1B1 | BB | 00 | 11

 B



 0A0 | 1B1 | BB | 00 | 11

Example 7

Simplify the following grammar:

S



 ASB |

ε

A



aAS  | a          B



 SbS | A | bb

Solution:

Eliminate

ε

 productions:

       S



 ASB | AB

       A



 aAS| aA | a

       B



 SbS | Sb | bS | b | A | bb

Eliminate Unit Production: Eliminate unit production A form production rule B

       S



 ASB | AB

       A



 AaS | Aa | a

       B



 SbS | Sb | bS | b | aAS | aA | bb |a

As there are no useless symbols , so simplified grammar is:

       S



 ASB | AB

       A



 AaS | Aa | a

       B



 SbS | Sb | bS | b | aAS | aA | bb |a

Example 8

Simplify the following grammar:

S



 aC| SB

A



 bSCa

B



 aSB|bBC

C



aBC|ad

Solution:

Elimination of non generation symbols: symbol B is non generating

symbol

      S



 aC

A



 bSCa

C



 ad

Elimination of non reachable symbols: Symbol A is non reachable

symbol

       S



 aC

 C



 ad

As there is no

ε

 production and there is no unit production in given

grammar the reduced grammar is:

S



 aC

C



 ad

Example 9

Simplify the following grammar

S



ABA | BA | AA | AB | A | B

A



Aa | a

B



bB | b

Solution:

Eliminate unit production: A and B are unit productions.

      S



ABA | BA | AA | AB | Aa | a | bB | b

A



Aa | a

B



bB | b

As there is no

ε

 production and useless symbol in this grammar. So

simplified grammar is:

      S



ABA | BA | AA | AB | Aa | a | bB | b

A



Aa | a

B



bB | b

Chomsky's Normal Form (CNF)

•

CNF stands for Chomsky normal form. A CFG(context free

grammar) is in CNF(Chomsky normal form) if all production

rules satisfy one of the following conditions:

•

Start symbol generating ε. For example, A → ε.

•

A non-terminal generating two non-terminals.

     For example, S → AB.

•

A non-terminal generating a terminal. For example, S → a.

Example

•

G1 = {S → AB, S → c, A → a, B → b}

•

G2 = {S → aA, A → a, B → c}

•

The production rules of Grammar G1 satisfy the rules

specified for CNF, so the grammar G1 is in CNF.

•

However, the production rule of Grammar G2 does not satisfy

the rules specified for CNF as S → aA contains terminal

followed by non-terminal. So the grammar G2 is not in CNF.

Steps for converting CFG into CNF

•

Step 1:

 In the grammar, remove the null, unit and useless

productions. (simplification of grammar)

•

Step 2:

 Eliminate terminals from the RHS of the production if

they exist with other non-terminals or terminals. For example,

production S → aA can be decomposed as:

•

S → RA

•

R → a

•

Step 3:

 Eliminate RHS with more than two non-terminals. For

example, S → ASB can be decomposed as:

•

S → RB

•

R → AS

Example 1

Convert the given CFG to CNF. Consider the given grammar G1

S → a | aA | B

A → aBB | ε

B → Aa | b

Solution:

Step 1:

 As grammar G1 contains A → ε null production, its

removal from the grammar yields:

S → a | aA | B

A → aBB

B → Aa | b | a

 Now, as grammar G1 contains Unit production S → B, its

removal yield:

S → a | aA | Aa | b

A → aBB

B → Aa | b | a

S → a | aA | B

A → aBB | ε

B → Aa | b

Step 2:

 In the production rule S → aA | Aa, S → aA | Aa, A → aBB and

B → Aa, terminal a exists on RHS with non-terminals. So we will

replace terminal a with X:

 S → a | XA | AX | b

A → XBB

B → AX | b | a

X → a

Step 3:

 In the production rule A → XBB, RHS has more than two

symbols, removing it from grammar yield:

S → a | XA | AX | b

A → RB

B → AX | b | a

X → a

R → XB

Hence, for the given grammar, this is the required CNF.

Example 2

Convert the following CFG into CNF

S → ASA | aB, A → B | S |  ε, B → b | ε

Solution:

1.

 Now we will remove the null productions −

     B →

∈

 and A →

∈

After removing B → ε, the production set becomes −

     S→ ASA | aB | a,        A → B | S |

∈

,              B → b

After removing A →

∈

, the production set becomes −

    S→ ASA | aB | a | AS | SA ,          A → B | S,        B → b

2.

 After removing unit production A→ B, the production set becomes −

     S→ ASA | aB | a | AS | SA  ,             A → S | b  ,                      B → b

   After removing A→ S, the production set becomes −

    S→ ASA | aB | a | AS | SA

   A → b |ASA | aB | a | AS | SA

   B → b

S → ASA | aB, A → B | S, B → b | ε

3.

Now we will find out more than two variables in the R.H.S

Here, S → ASA, A→ ASA violates two Non-terminals in R.H.S.

Hence we will apply step 4 and step 5 to get the following final

production set which is in CNF −

S→ AX | aB | a | AS | SA

A → b |AX | aB | a | AS | SA

B → b

X → SA

4.

 We have to change the productions  S→ aB, A→ aB

And the final production set becomes −

S→ AX | YB | a | AS | SA

A → b |AX | YB | a | AS | SA

B → b

X → SA

Y → a

Example 3

Check whether given grammar is CNF

S



 bA | aB            A



bAA| aS | a        B



 aBB|bS|b

 if it is not in CNF then find equivalent CNF.

•

The grammar is not in CNF as following productions are not allowed

in CNF.

      S



 bA | aB                     A



bAA| aS                  B



 aBB|bS

Step 1: Simplification of grammar: grammar is already simplified.

Step 2: Some productions i.e.

S



 bA | aB  , A



bAA| aS  and  B



aBB|bS are violating the rules of CNF. So we replace the terminals a

with variable X and terminal b with Y.

   S



 YA | XB                     A



YAA| XS |a                 B



 XBB|YS |b

   X



a                                   Y



b

Now,  a-



YAA is violating the rules of CNF. So we replace AA with W

and BB with Z.

     S



 YA | XB                     A



YW| XS |a                 B



 XZ|YS |b

     W



 AA                 Z



 BB                     X



a                          Y



b

Example 4

Convert given grammar in CNF form

S



Aba  A



aab    B



Ac

1. Simplification of given grammar

B is non reachable . So grammar after removing B is:

    S



Aba

    A



aab

2. Both productions

S



Aba and A



aab are violating the rules of CNF.

So we replace a with X and b with Y

   S



AYX

   A



XXY

   X



a

   Y



b

3. Now ,

S



AYX and A



XXY are violating the rules of CNF. So we

replace AY with R and XX with W.

  S



RX            A



RY             R



 AY                   W



XX

  X



a               Y



b

Example 5

Convert the following grammar into CNF form

S



AACD       A



aAb|

ε

C



aC|a         A



aDa|bDb|

 ε

1. Simplification of grammar:

Removing

ε

 production from production A .

S



AACD | ACD | CD

        A



 aAb |ab

        C



 aC |a

        A



 aDa | bDb

Removing non reachable symbol D.

       S



C

       A



aAb | ab

       C



 aC | a

Removing unit production S



C

     S



 aC|a

     A



aAb | ab

     C



 aC|a

 Example 5

Convert the following grammar into CNF form

S



AACD       A



aAb|

ε

C



aC|a         A



aDa|bDb|

 ε

2. S



 aC  and C



 aC are violating the CNF rules. So we replace a with X and

replace b with Y.

     S



XC|a

    A



XAY | XY

     C



XC|a

     X



a

As A



 XAX is voilating the riles of CNF .So, Now substitute new production

Z



XA.

    S



XC|a

    A



ZY | XY

    C



XC|a

    X



a

     Z



XA

Now, the grammar is in CNF form.

Example 6

Convert following grammar into CNF form.

S



AACD       A



aAb|

ε

C



aC|a         D



aDa|bDb|

 ε

1.Simplification of grammar:

Removing

ε

 productions from production A and D.

S



AACD | ACD | CD | AAC | AC | C

      A



aAb|ab

      C



aC|a

      D



aDa|bDb|aa |bb

Removing unit

productions S



C

      S



AACD | ACD | CD | AAC | AC | aC|a

      A



aAb|ab

      C



aC|a

      D



aDa|bDb|aa |bb

Example 6

Convert following grammar into CNF form.

S



AACD       A



aAb|

ε

C



aC|a         D



aDa|bDb|

 ε

To convert above grammar in CNF form. Let we add two variables X for

a and Y for b.

      S



AACD | ACD | CD | AAC | AC | XC | a

      A



XAY|XY

      C



XC|a

      D



XDX|YDY|XX|YY

Let we add some more variables to above grammar to  convert it in

CNF form.

      S



 PQ | AQ | CD | PC | AC | XC |a

      A



 RY | XY

      C



XC | a

      D



 TX | UY |XX |YY

      P



AA          Q



 CD      R



 XA         T



 XD        U



YD

      X



a           Y



b

Greibach Normal Form (GNF)

•

GNF stands for Greibach normal form. A CFG(context free

grammar) is in GNF(Greibach normal form) if all the

production rules satisfy one of the following conditions:

•

A start symbol generating ε. For example, S → ε.

•

A non-terminal generating a terminal. For example, A →

a.

•

A non-terminal generating a terminal which is followed

by any number of non-terminals. For example, S → aASB.

Example

•

G1 = {S → aAB | aB, A → aA| a, B → bB | b}

•

G2 = {S → aAB | aB, A → aA |

ε,

B → bB |

ε}

•

The production rules of Grammar G1 satisfy the rules

specified for GNF, so the grammar G1 is in GNF. However, the

production rule of Grammar G2 does not satisfy the rules

specified for GNF as A →

ε

and B →

ε

contains

ε(

only start

symbol can generate

ε).

So the grammar G2 is not in GNF.

Steps for converting CFG into GNF

•

Step 1:

 Convert the grammar into CNF.

•

If the given grammar is not in CNF, convert it into CNF. You can

refer the following topic to convert the CFG into CNF:

Chomsky normal form

•

Step 2:

 If the grammar exists left recursion, eliminate it.

•

If the context free grammar contains left recursion, eliminate

it. You can refer the following topic to eliminate left recursion:

Left Recursion

•

Step 3:

 In the grammar, convert the given production rule into

GNF form.

•

If any production rule in the grammar is not in GNF form,

convert it.

Removing Left Recursion

The production of the form A



A

α

 is called as

left recursive

as the left

side variable appears as the first symbol on the right hand side.

Examples:

1. A



Aa | b

Grammar without left recursion is:

A



b | bA

B



 aB | a

2. A



Aa | b | c

Grammar without left recursion is:

A



 b | c | bA | cA

B



 aB | a

Example 1

Construct the grammar in GNF which is equivalent to the grammar

S → XB | AA         A → a | SA

B → b             X → a

Solution:

As the given grammar G is already in CNF and there is no left recursion,

so we can skip step 1 and step 2 and directly go to step 3.

The production rule A → SA is not in GNF, so we substitute S → XB |

AA in the production rule A → SA as:

S → XB | AA

A → a | XBA | AAA

B → b              X → a

The production rule S → XB and A → XBA is not in GNF, so we

substitute X → a in the production rule S → XB and A → XBA as:

S → aB | AA

A → a | aBA | AAA

B → b               X → a

Example 1

Construct the grammar in GNF which is equivalent to the grammar

S → XB | AA         A → a | SA

B → b             X → a

S → aB | AA

A → a | aBA | AAA

B → b               X → a

Now we will remove left recursion (A → AAA), we get:

S → aB | AA

A → aA | aBAA | a | aBA

C → AAC |  AA

B → b            X → a

The production rule S → AA is not in GNF, so we substitute A → aC |

aBAC | a | aBA in production rule S → AA as:

S → aB | aAA | aBAAA | aA | aBAA

A → aA | aBACA| a | aBA

C → AAC

C → aAA | aBAAA | aA | aBAA

B → b              X → a

Example 1

Construct the grammar in GNF which is equivalent to the grammar

S → XB | AA         A → a | SA

B → b             X → a

The production rule C → AAC is not in GNF, so we substitute A →

aC | aBAC | a | aBA in production rule C → AAC as:

S → aB | aCA | aBACA | aA | aBAA

A → aA | aBAA | a | aBA

C →  aCAA | aBAAAC | aAC | aBAAC

C → aCA | aBACA | aA | aBAA

B → b

X → a

Hence, this is the GNF form for the grammar G.

Example 2

Convert following grammar to GNF

S



 ABA | AB | BA | AA | A | B

A



 aA | a

B



 bB | b

Solution:

•

Removing unit productions: S



 A and S



B

      S



 ABA | AB | BA | AA | aA | a | bB | b

A



 aA | a

B



 bB | b

•

Production A  and B is already in GNF form. So, production S can be

brought into GNF form by using productions of A and B.

     S



 aABA | aBA | aAB | aB | bBA| bA |aAA |aA |a |b

     A



 aA| a

     B



 bB | b

Now the grammar is in GNF form.

Exapmle 3

Find GNF of given grammar

S



ABAb|ab

B



 ABA|a

A



a|b

Solution:

As given grammar is simplified.

Let’s substitute and Y for b

S



 ABAY|aY

B



 ABA|a

A



a|b

      Y



b

Now substitute A



a |b in productions of S and B

S



 aBAY|bBAY|aY

B



 aBA|bBA|a

A



a|b

      Y



b

Now, the grammar is in GNF form.

Chomsky Classification for Grammar

•

According to Noam Chomsky, there are four types of grammars −

Type 0, Type 1, Type 2, and Type 3. The following table shows how

they differ from each other −

Scope of each Type of Grammar

Type - 3 Grammar

•

Type-3 grammars

 generate regular languages. Type-3

grammars must have a single non-terminal on the left-hand

side and a right-hand side consisting of a single terminal or

single terminal followed by a single non-terminal.

•

The productions must be in the form

X → a or X → aY

•

where

X, Y

∈

 N

 (Non terminal)

•

and

a

∈

 T

 (Terminal)

•

The rule

S → ε

 is allowed if

S

 does not appear on the right

side of any rule.

•

Example

•

X → ε        X → a | aY         Y → b

Type - 2 Grammar

•

Type-2 grammars

 generate context-free languages.

•

The productions must be in the form

A → γ

•

where

A

∈

 N

 (Non terminal)

•

and

γ

∈

 (T

∪

 N)*

 (String of terminals and non-terminals).

•

These languages generated by these grammars are be

recognized by a non-deterministic pushdown automaton.

•

Example

•

S → X a        X → a         X → aX        X → abc          X → ε

Type - 1 Grammar

•

Type-1 grammars

 generate context-sensitive languages. The

productions must be in the form

•

α A β → α γ β

•

where

A

∈

 N

 (Non-terminal)

•

and

α, β, γ

∈

 (T

∪

 N)*

 (Strings of terminals and non-terminals)

•

The strings

α

 and

β

 may be empty, but

γ

 must be non-empty.

•

The rule

S → ε

 is allowed if S does not appear on the right side

of any rule. The languages generated by these grammars are

recognized by a linear bounded automaton.

•

Example

•

AB → AbBc   A → bcA    B → b

Type - 0 Grammar

•

Type-0 grammars

 generate recursively enumerable languages. The

productions have no restrictions. They are any phase structure

grammar including all formal grammars.

•

They generate the languages that are recognized by a Turing

machine.

•

The productions can be in the form of

α → β

 where

α

 is a string of

terminals and non-terminals with at least one non-terminal

and

α

 cannot be null.

β

 is a string of terminals and non-terminals.

•

Example

•

S → ACaB       Bc → acB       CB → DB         aD → Db

Closure Properties of Context Free

Languages

Closure Properties of CFLs

• CFLs are closed under:

–Union

 –Concatenation

–Kleene closure

 –Reversal

 • CFLs are not closed under intersection, difference, or

complement

Closure Under Union

•

Let L and M be CFLs with grammars G and H, respectively

• Assume G and H have no variables in common

 – Rename the variables if necessary

– Names of variables do not affect the language

• Let S1 and S2 be the start symbols of G and H

• Form a new grammar for L

∪

 M by combining all the symbols

and productions of G and H

Closure Under Union

•

Then, add a new start symbol S

 • Add productions S → S1 | S2

 • In the new grammar, all derivations start with S

 • The first step replaces S with either S1 or S2

 • In the first case, the result must be a string in L(G) = L, and in

the second case, the result must be a string in L(H) = M

Closure Under Concatenation

• Let L and M be CFLs with grammars G and H, respectively

• Assume G and H have no variables in common

 • Let S1 and S2 be the start symbols of G and H

 • Form a new grammar for LM by starting with all symbols and

productions of G and H

• Add a new start symbol S and production S → S1S2

• Every derivation from S results in a string in L followed by one

in M

Closure Under Star

•

Let L have grammar G, with start symbol S1

 • Form a new grammar for L* by introducing to G a new start

symbol S and the productions S → S1S | ε

 • A rightmost derivation from S generates a sequence of zero or

more S1’s, each of which generates some string in L

Closure of Under Reversal

•

If L is a CFL with grammar G, form a grammar for LR by

reversing the body of every production

 • Example: Let G have S → 0S1 | 01

• The reversal of L(G) has grammar

S → 1S0 | 10

CFLs are Not Closed Under Intersection

•

Unlike the regular languages, the class of CFLs is not closed

under intersection

• For example, we know that L1 = {0n1n2n : n ≥ 1} is not context-

free (use the pumping lemma)

 • However, L2 = {0n1n2i : n ≥ 1, i ≥ 1} is context-free – CFG: S →

AB, A → 0A1 | 01, B → 2B | 2

• So is L3 = {0i1n2n : n ≥ 1, i ≥ 1}

 • But L1 = L2 ∩ L3 is not context-free

CFLs are Not Closed Under Difference

•

We can prove something more general: –

•

Any class of languages that is closed under difference is also

closed under intersection

 • Proof: L ∩ M = L – (L – M)

• Thus, if CFL’s were closed under difference, they would also be

closed under intersection, but they are not CFLs

CFLs are Not Closed Under Complement

•

L1 ∩ L2 = ¬(¬L1

∪

 ¬L2)

•

Recall that the context-free languages are closed under union.

•

So if they were closed under complement, they would also be

closed under intersection (which they are not)

CFLs are Not Closed Under Complement

•

Recall AnBnCn = {an bncn: n ≥ 0}.

•

Now consider L = ¬ (AnBnCn), which is L1

∪

 L2,

      where:

     L1 = {w

∈

 {a, b, c}* : the letters are out of order}

     L2 = {aibjck: i, j, k ≥ 0 and (i ≠ j or j ≠ k)}  (in other words,

unequal numbers of a’s, b’s, and c’s)

•

 A simple DFA can recognize L1. L2 can be built similar to the

one we created for accepting strings with an unequal number

of a’s and b’s.

•

Thus, ¬ (AnBnCn) is context-free, whereas AnBnCn is not

context-free (as we already proved).

Discussion Properties of CFL

•

Context Free Language

•

Context Free Languages(CFL) is the next

•

class of languages outside of Regular

•

Languages:

•

– Means for defining: Context Free Grammar

•

– Machine for accepting: Pushdown Automata

•

The decision properties of Context Free Language are:

•

Membership

•

Emptiness

•

Finiteness

Membership

•

Unlike FAs, we can’t just run the string through the

machine and see where it goes since PDAs are non-

deterministic.

•

 It must consider all possible paths.

•

Instead, start with your grammar in CNF.

•

The proof of the pumping lemma states that the longest

derivation path of a string of size n will be 2n – 1.

•

 Systematically generate all derivations with one step,

then two steps, …, then 2n – 1 steps where the length of

the string tested = n.

•

If one of the derivations derive x, return true, else return

false.

Emptiness

•

By the proof of the pumping lemma, if a grammar in CNF

has p states, the longest string, not subject to the pumping

lemma will have length n = 2 ^p+1

•

Systematically generate all strings with lengths less than n.

•

Test each one using membership algorithm.

•

If all fail and Epsilon not equal to L, then L is empty

•

Else L is not empty

•

We learned to eliminate variables that generate no

terminal string.

•

If the start symbol is one of these, then the CFL is empty;

otherwise not.

Finiteness

•

The idea is essentially the same as for regular languages.

•

Use the pumping lemma constant n.

•

If there is a string in the language of length between n and 2n-

1, then the language is infinite; otherwise not

.

Regular Grammar

•

The language accepted by finite automata can be described

using set of productions is known as regular grammar.

•

Let us consider some production rules:

     A



 a

     A



aA

     A



Ba

     A



ε

•

The language generated by regular grammar is known as

regular language.

•

There are two forms to represent the regular grammar.

1.

Right Linear form

2.

Left Linear form

Types of Regular Grammar

1.

Right Linear Grammar:

•

The productions of right linear grammar can be represented as:

        A



a

        A



 aB    [The variable B in this production appears at rightmost

                         position]

        A



ε

2.     Lef

t Linear Grammar:

•

The productions of left linear grammar can be represented as:

        A



a

        A



 Ba    [The variable B in this production appears at leftmost

                         position]

        A



ε

DFA to Right Linear Grammar

•

DFA can be described by using tuple set: M = (Q, ∑,

δ,

q

0

 , F)

•

Right linear grammar can be represented by using tuple set:          G= (V, T,

P, S)

•

Following are the steps to convert DFA to Right Linear Grammar:

1.

Rename

q

0

∈

 Q as S

∈

 V i.e. Relating start sate of M with start symbol of

G.

2.

Rename the states of Q as A, B,C,D,…. where A,B,C,D,…..

∈

 V

3.

Generating a set of productions P as:

       i) If

q

0 ,

∈

 F then add productions S



 ε

 to P.

       ii) for every production of the form

                             a

          Add production A



 aB where A is non final state.

          Add production  A



 aB, A



 a , where B is final state

A

B

A

 B

a

Example1

Convert following DFA to right linear grammar

Solution:

By Renaming states, we will get following DFA

From above DFA we can write following productions :

S



 aA| bB

A



 aS| bC| b

B



 bS| aC| a

C



 aB| bA

This is the right linear grammar for given DFA.

Example 2

Write a right linear grammar for given DFA.

Solution:

State D is dead state, so it is removed.

DFA after deletion of state D is:

From above DFA we can write following

productions:

A



ε

A



0B| 0

B



1C

C



 0B|0

Right Linear Grammar to DFA

•

Following are the steps to convert regular grammar to DFA:

1.

The production of the form A



 aB will generate the transition for

DFA as:

2. The production of the form A



aB| a will generate the transition as

3. The production of the form A



ε

 will make a final state.

4. The production of the form A



b, will generate a transition

Where F is new state and it should be final state

A

B

a

A

B

a

A

A

F

Example  1

Convert following right linear grammar to DFA.

S



 bB     B



 bC       B



 aB        C



 a        B



b

Solution:

By re-writing the productions grammar will be:

S



 bB     B



 bC  | b        C



 a        B



 aB

Transition diagram for above grammar will be:

By adding E state to handle Ø transitions , the Final DFA will be:

Example 2

Convert following RG to DFA

S



 0A | 1B        A



0C | 1A | 0

B



 1B | 1A | 1          C



 0 | 0A

Solution:

For production A



 0, B



1, C



0  add new state F .

Equivalent DFA for above transition diagram is:

DFA after renaming the states and dead state is introduced to handle Ø

transactions.

DFA to Left Linear Grammar

•

Following are the steps to write a left linear grammar to DFA:

1.

Interchange the starting state and final state .

2.

Reverse the direction of all transitions.

3.

Write the grammar from transition graph in left linear form.

Example 1

Write the left linear grammar for following DFA.

After interchanging the states and reversing the directions of

transitions , Transition graph will be

:

Equivalent left linear

grammar is:

S



 Ba | Ab

A



 Sb| Ca | a

B



 Sa | Cb | b

C



 Bb | Aa

Example 2

Write left linear grammar for following DFA

In given DFA , there are three final states S, A and B. we can draw an

equivalent DFA with single final state D by adding

ε

 transitions from S to

D, A to D and N to D.

By interchanging the starting state and final state and reversing the

direction of transitions , DFA will be:

An equivalent left linear grammar is:

S



 D

S



 A

S



B

C



Ba

B



 Cb | Ab

A



 Aa | Da | Ca | a

D



 Bb | Db | b

By removing unit productions:

S



 Cb | Ab | Aa | Da | Ca | a | Bb | Db | b

C



Ba

B



 Cb | Ab

A



 Aa | Da | Ca | a

D



 Bb | Db | b

Left Linear Grammar to DFA

Following are the steps to convert left linear grammar to DFA:

1.

Draw transition graph from the given left linear grammar.

2.

Reverse the direction of all the transitions.

3.

Interchange the start state and final state.

4.

Carry out conversion from FA to DFA.

Example 1

Construct DFA for accepting regular language generated by the linear

grammar given below:

S



 Ca | Bb

C



 Bb

B



 Ba | b

Solution:

Transition diagram for given left linear grammar is:

By reversing the directions of transitions and interchanging starting

state and final state:

State D is added for production B



b

Conversion of FA to DFA

Example 2

Construct DFA for accepting the language generated by left linear

grammar given below:

S



 B1 | A0 | C0

B



 B1 | 1

A



 A1 | B1 | C0 | 0

C



A0

Solution:

     By reversing direction of transitions

and interchanging starting and final

state:

Transition diagram for given left

linear grammar is:

Conversion from FA to DFA

Right Linear Grammar to Left linear

Grammar

•

Following are the steps to convert right linear grammar to Left

Linear Grammar:

1.

Represent the right linear grammar using transition graph

and mark

ε

 as a final state.

2.

Interchange the start state and final state.

3.

Reverse the direction of all transitions.

4.

Write left linear grammar from transition graph.

Example 1

Convert the following right linear grammar to an equivalent left

linear grammar

S



bB | b

B



bC

B



 aB

C



a

B



b

Solution:

Transition graph for given right linear grammar is:

By interchanging the start state with final state and reversing the

transitions:

Left linear

grammar is:

S



 b | Bb | Ca

B



Ba | b

C



 Bb

Example 2

Write an equivalent left linear grammar from the given right linear

grammar

S



0A | 1B

A



0C | 1A | 0

B



 1B | 1A | 1

C



0 | 0A

Solution:

Transition diagram for given right linear grammar is:

By interchanging the start state with final state and reversing direction of

transitions:

Left linear grammar is:

S



 C0 | A0 | B1

A



 A1 | C0 | B1 | 0

B



 B1 | 1

C



 A0

Left linear grammar to right linear

grammar

•

Following are the steps to convert left linear grammar to right

linear grammar:

1.

Represent the left linear grammar using transition graph and

mark

ε

  as a final state.

2.

Interchange the start state and final state.

3.

Reverse the direction of all transitions.

4.

Write right linear grammar from transition graph.

Example 1

Write an equivalent right linear grammar from the given left linear

grammar

S



 C0 | A0 | B1

A



 A1 | C0 | B1 | 0

B



 B1 | 1

C



 A0

Solution:

The transition diagram for given left linear grammar is:

By interchanging the start state with final state and reversing the

direction of transition

Right linear grammar is:

S



 1B | 0A

A



 0C | 1A | 0

B



 1B | 1A | 1

C



  0A | 0

Example 2

Construct right linear grammar corresponding to the regular

expression R = (1+(01)*)1*(0+1)

Solution:

The transition diagram for given regular expression is:

Right linear grammar is:

S



 1B | A

A



 01A | B

B



 1B| 0C | 1C | 0 | 1

After removing unit productions

grammar will be:

S



 1B | 01A | 1B | 0C | 1C | 0 | 1

A



 01A | 1B| 0C | 1C | 0 | 1

B



 1B| 0C | 1C | 0 | 1

Example 3

Construct left linear and right linear grammar for the language

0*(1(0+1))*

Solution:

Right linear grammar from above transition diagram can be

written as:

S



 0S | A |

ε

A



 1B

B



 0A | 1A | 0 | 1

After removing the unit production, right linear grammar will be:

S



 0S | 1B |

ε

A



 1B

B



 0A | 1A | 0 | 1

By interchanging start state with final state and reversing the

direction of transitions resulting transition diagram is:

Left linear grammar is:

S



 B0 | B1 | A |

ε

B



 S1

A



 A0 | 0

After removing unit production left linear

grammar will be:

S



 B0 | B1 | A0 | 0 |

ε

B



 S1

A



 A0 | 0

Applications of CFL

•

Following are the applications of CFG:

1.

Parser

2.

Markup languages(XML)
