Computers Version 9.0 Draft 2 Webinar Specifications
Computers Version 9.0
Draft 2 Specification Webinar
May 21, 2024
2
•
Please mute yourself when you are not speaking (use local mute or
dial *6)
•
Feel free to ask questions at any time
Webinar Participation
3
•
Introductions
•
Definitions
•
Internal Power Supply Requirements
•
Certification Criteria
•
External Power Supplies
•
Timeline and Next Steps
Agenda
4
Ryan Fogle, EPA
Fogle.Ryan@epa.gov
John Clinger, ICF
John.Clinger@icf.com
Abhishek Jathar, ICF
Abhishek.Jathar@icf.com
Introductions
5
ENERGY STAR Specification Development
Process
6
•
Sleep Mode - EPA has clarified the following:
•
Resume-time requirements are not applicable to workstations
•
For workstations capable of ACPI system level S4 (hibernate), this state
most commonly correlates with sleep mode for testing purposes
Definitions
7
•
Reverted IPS requirements below 500 watts to 80Plus Bronze
equivalent while retaining existing 10% load point requirement
•
Many products in this category cannot meet 80Plus Silver equivalent but are
more efficient at 10% loading point than products listed as 80Plus Bronze
•
Forcing adoption of 80Plus Silver equivalent would reduce efficiency at 10%
load in aggregate, a detriment to low load efficiency which is more relevant in
smaller power supplies.
•
EPA encourages partners to continue innovation on efficiency in low
loads of 10% (and less when feasible).
Internal Power Supply Requirements
8
•
Base Allowances:
•
The EPA has worked with ITI over the past couple months to address several
data quality issues and also significantly expand the size of the EPA data set
with many more non-certified configurations
•
Changes to the data set in conjunction with changes to the functional adders
have yielded new base allowances
•
The expanded data set also covers a larger variety of configuration types for
both certified and non-certified models currently available on the market
Certification Criteria – TEC Requirements
9
Certification Criteria – TEC Requirements
10
•
Functional Adders:
•
The EPA received feedback suggesting the update of several existing
functional adders to better align with current technology. Those changes
include:
•
Memory Adder – Reintroduced for notebooks and simplified / reduced for notebooks and
desktops
•
Switchable Graphics – Cut by more than half for both notebooks and desktops
•
Integrated Display – Revised to align with new notebook mode weightings introduced in
the Draft 1 specification
•
Mobile Workstations – Increased based on the changes to the notebook base allowances
and functional adders in the Draft 2 specification
•
Enhanced Performance Display – Simplified and reduced for larger screen sizes
Certification Criteria – TEC Requirements
11
Certification Criteria – TEC Requirements
12
•
The EPA is aware of new regulations in the EU allowing for shipment
without EPS for smaller electronics. The Agency still has the following
concerns regarding removing the current 35 watt limit for shipping
without an EPS:
•
The market current implements multiple charging cord types
•
The market current sells EPS at a variety of wattages. Mismatching an EPS and
notebook can result in
•
Potential safety concerns
•
An older EPS being used with a newer device where the EPS does not provide sufficient
power to realize the full capability of the product when plugged in
External Power Supplies
13
•
ENERGY STAR is a US based program and intends to retain the existing
35 watt requirement until further industry harmonization in both
connection type and EPS power delivery levels occurs.
•
The Agency maintains concerns about potential EPS / notebook mismatches if
customers attempt to re-use older EPSs.
•
It’s also not clear what existing notebook use cases are supported by
shipping without an EPS in the current market for most customers.
•
ENERGY STAR does not prohibit partners from shipping products that
meet certification criteria from shipping in the EU without EPSs.
External Power Supplies
14
•
The EPA does not intend to publish a Draft 3 specification given the
limited open items remaining in this specification revision process.
•
The EPA continues to work towards a goal of completing the Version
1.0 specification in Q3/Q4 of 2024, with a targeted effective date of Q2
2025.
Timeline and Next Steps
15
Ryan Fogle, EPA
Fogle.Ryan@epa.gov
Abhishek Jathar, ICF
Abhishek.Jathar@icf.com
John Clinger, ICF
John.Clinger@icf.com
Questions?
Stakeholders are encouraged to provide written comments for consideration
to
computers@energystar.gov
by June 4, 2024.
This webinar covers the specifications of Computers Version 9.0 Draft 2, including internal and external power supply requirements, certification criteria, and the ENERGY STAR specification development process. It also discusses definitions, sleep mode details, and internal power supply efficiency recommendations. Participants are encouraged to ask questions and provide comments for further development.
