1. CS 5600 Computer Systems Lecture 13: Exploits and Exploit Prevention

2. Basic Program Exploitation Protecting the Stack Advanced Program Exploitation Defenses Against ROP Kernel Exploits and Rootkits 2

3. Setting the Stage Game executable is setuid [cbw@finalfight game] ls -lh -rw------- 1 amislove faculty 180 Jan 23 11:25 secrets.txt -rwsr-sr-x 4 amislove faculty 8.5K Jan 23 11:25 guessinggame Suppose I really want to see the secret answers But I m not willing to play the game How can I run arbitrary code as amislove? If I could run code as amislove, I could read secrets.txt Example: execvp( /bin/sh , 0); 3

4. Looking for Vulnerabilities Code snippet for guessinggame char buf[8]; for (int x = 1; x < argc; ++x) { strcpy(buf, argv[x]); num = atoi(buf); check_for_secret(num); } Stack buffer overflow 4

5. Confirmation [cbw@finalfight game] ls -lh -rw------- 1 amislove faculty 180 Jan 23 11:25 secrets.txt -rwsr-sr-x 4 amislove faculty 8.5K Jan 23 11:25 guessinggame [cbw@finalfight game] ./guessinggame 1 2 3 Sorry, none of those number are correct :( [cbw@finalfight game] ./guessinggame AAAAAAAAAAAAAAAAAAAAAAA Sorry, none of those number are correct :( Segmentation fault (core dumped) (gdb) bt #0 0x0000000000400514 in myfunc () #1 0x4141414141414141 in ?? () #2 0x4141414141414141 in ?? () #3 0x4141414141414141 in ?? () #4 0x0000004141414141 in ?? () A = 0x41 in ASCII 5

6. Exploiting Stack Buffer Overflows Stack Preconditions for a successful exploit 1. Overflow is able to overwrite the return address 2. Contents of the buffer are under the attackers control Stuff from previous frame Malicious assembly instructions execvp( /bin/sh , 0); ESP - 20 ESP - 16 ESP - 12 ESP - 8 return address Address of assembly int num int x Garbage char buf[8] ESP 6

7. Exploitation, Try #1 [cbw@finalfight game] ./guessinggame [16-bytes of garbage][4-byte stack pointer][evil shellcode assembly] Segmentation fault (core dumped) This is not what we want :( Problem: how do you know the address of the shellcode on the stack? To execute the shellcode, you have to return to its exact start address This is a small target 7

8. NOP Sled Stack To execute the shellcode, you have to return to its exact start address You can increase the size of the target using a NOP sled (a.k.a. slide, ramp) Stuff from previous frame Malicious assembly instructions Full of 0x90 (NOP x86 instructions) NOP sled execvp( /bin/sh , 0); ESP - 20 ESP - 16 ESP - 12 ESP - 8 return address Address of assembly int num int x Garbage char buf[8] ESP 8

9. Exploitation, Try #2 turned into /bin/sh ./guessinggame ran the shellcode, [cbw@finalfight game] ./guessinggame [16 bytes of garbage][4 byte stack pointer][2048 bytes of 0x90][evil shellcode assembly] $ There is a lot more to writing a successful exploits Depending on the type of flaw, compiler countermeasures, and OS countermeasures If you like this stuff, take a security course 9

10. Types of Exploitable Flaws Stack overflow Heap overflow char * buf = malloc(100); strcpy(buf, argv[1]); Double free free(buf); free(buf); Format string printf(argv[1]); Off-by-one int vectors[100]; for (i = 0; i <= 100; i++) vector[i] = x; and many more 10

11. Triggering Exploitable Flaws Local vulnerabilities: Command line arguments Environment variables Data read from a file Date from shared memory or pipes Remote vulnerabilities Data read from a socket Basically, any place where an attacker can give input to your process Attacker can inject code into your machine via the Internet 11

12. Leveraging an Exploit After a successful exploit, what can the attacker do? Anything the exploited process could do The shellcode has full API access Typical shellcode payload is to open a shell Remote exploit: open a shell and bind STDIN/STDOUT to a socket (remote shell) If process is uid=root or setuid=root, exploitation results in privilege escalation If the process is the kernel, the exploit also results in privilege escalation 12

13. Basic Program Exploitation Protecting the Stack Advanced Program Exploitation Defenses Against ROP Kernel Exploits and Rootkits 13

14. Defending Against Stack Exploits Exploits leverage programmer bugs Programmers are never going to write code that is 100% bug-free What can the system do to help prevent processes from being exploited? Mechanisms that prevent stack-based exploits Stack canaries Non-executable stack pages (NX-bit) 14

15. The Canary in the Coal Mine Miners used to take canaries down into mines The birds are very sensitive to poisonous gases If the bird dies, it means something is very wrong! The bird is an early warning system 15

16. Stack Canaries Stack A stack canary is an early warning system that alerts you to stack overflows Malicious shellcode Automatically added by the compiler Overflow destroys the canary, assert fails, program safely exits Stuff from previous frame int canary = secret_canary; char buf[8]; for (x = 1; x < argc; ++x) { strcpy(buf, argv[x]); num = atoi(buf); check_for_secret(num); } ... assert(canary==secret_canary); return 0; NOP sled ESP - 24 return address canary value Pointer to sled ESP - 20 ESP - 16 ESP - 12 ESP - 8 int num int x Garbage char buf[8] ESP 16

17. Canary Implementation Canary code and data are inserted by the compiler gcc supports canaries Disable using the fno-stack-protector argument Canary secret must be random Otherwise the attacker could guess it Canary secret is stored on its own page at semi- random location in virtual memory Makes it difficult to locate and read from memory 17

18. Canaries in Action [cbw@finalfight game] ./guessinggame AAAAAAAAAAAAAAAAAAAAAAA *** stack smashing detected ***: ./guessinggame terminated Segmentation fault (core dumped) Note: canaries do not prevent the buffer overflow The canary prevents the overflow from being exploited 18

19. When Canaries Fail Stack ESP - 1036 ESP - 1032 ESP - 1028 ESP - 1024 Canary is left intact return address canary value Pointer to sled void my_func() { ... } fptr Function pointer int canary = secret_canary; void (*fptr)(void); char buf[1024]; fptr = &my_func; strcpy(buf, argv[1]); fptr(); assert(canary==secret_canary); return 0; Malicious shellcode Calling fptr triggers the exploit char buf[1024] NOP sled ESP 19

20. ProPolice Compiler Stack ESP - 1036 ESP - 1032 ESP - 1028 return address canary value Security oriented compiler technique Attempts to place arrays above other local variables on the stack Integrated into gcc char buf[1024] ESP - 4 ESP fptr 20

21. When ProPolice Fails void my_func() { ... } The C specification states that the fields of a struct cannot be reordered by the compiler struct my_stuff { void (*fptr)(void); char buf[1024]; }; int canary = secret_canary; struct my_stuff stuff; stuff.fptr = &my_func; strcpy(stuff.buf, argv[1]); stuff.fptr(); assert(canary==secret_canary); return 0; 21

22. Non-Executable Stack Problem: compiler techniques cannot prevent all stack-based exploits Key insight: many exploits require placing code in the stack and executing it Code doesn t typically go on stack pages Solution: make stack pages non-executable Compiler marks stack segment as non-executable Loader sets the corresponding page as non- executable 22

23. x86 Page Table Entry, Again On x86, page table entries (PTE) are 4 bytes 31 - 12 11 - 9 8 7 6 5 4 3 2 1 0 Page Frame Number (PFN) Unused G PAT D A PCD PWT U/S W P W bit determines writeable status but there is no bit for executable/non-executable On x86-64, the most significant bit of each PTE (bit 63) determines if a page is executable AMD calls it the NX bit: No-eXecute Intel calls it the XD bit: eXecute Disable 23

24. When NX bits Fail NX prevents shellcode from being placed on the stack NX must be enabled by the process NX must be supported by the OS Can exploit writers get around NX? Of course ;) Return-to-libc Return-oriented programming (ROP) 24

25. Basic Program Exploitation Protecting the Stack Advanced Program Exploitation Defenses Against ROP Kernel Exploits and Rootkits 25

26. Return to libc /bin/sh char ** argv 0 Ptr to string char * file Parameters for a call to execvp() Fake return addr return address Current stack frame 0x007F0A82 Example exploits thus far have leveraged code injection Why not use code that is already available in the process? execvp(char * file, char ** argv); libc Library execvp() 0x007F0A82 0x007F0000

27. Stack Control = Program Control Return to libc works by crafting special stack frames and using existing library code No need to inject code, just data onto the stack Return-oriented programming (ROP) is a generalization of return to libc Why only jump to existing functions? You can jump to code anywhere in the program Gadgets are snippets of assembly that form a Turing complete language Gadgets + control of the stack = arbitrary code execution power 27

28. Basic Program Exploitation Protecting the Stack Advanced Program Exploitation Defenses Against ROP Kernel Exploits and Rootkits 28

29. Defending Against Return to libc Virtual Memory Return to libc and ROP work by repeatedly returning to known pieces of code This assumes the attacker knows the addresses of this code in memory Key idea: place code and data at random places in memory Address Space Layout Randomization (ASLR) Supported by all modern OSes 264-1 Stack Stack Stack Region Stack Heap Heap Region Heap Heap Code Code Region Code Code 0

30. Randomizing Code Placement Virtual Memory 264-1 It s okay for stack and heap to be placed randomly Example: stack is accessed relative to ESP Problem: code is typically compiled assuming a fixed load address Addr of foo(): 0x0DEB49A3 Process 2 Process 1 Addr of foo(): 0x000FE4D8 0

31. Position Independent Code Example Modern compilers can produce Position Independent Code (PIC) Also called Position Independent Executable (PIE) e8 is the opcode for a relative function call Address is calculated as EIP + given value Example: 0x4004cc + 0xffffffe8 = 0x4004b4 004004b4 <func>: Global data is accessed relative to EIP int global_var = 20; 004004bf <main>: 4004bf: 55 4004c0: 48 89 e5 4004c3: 48 83 ec 10 4004c7: e8 e8 ff ff ff 4004cc: 89 45 fc 4004cf: c7 05 3f 0b 20 00 10 mov 4004d6: 00 00 00 4004d9: b8 00 00 00 00 4004de: c9 4004df: c3 push ebp mov ebp, esp sub esp, 0x10 call 4004b4 <func> mov [ebp-0x4], eax int func() { return 30; } int main() { int x = func(); global_var = 10; return 0; } [eip+0x200b3f], 0x10 mov eax, 0x0 leave ret 31

32. Tradeoffs with PIC/PIE Pro Enables the OS to place the code and data segments at a random place in memory (ASLR) Con Code is slightly less efficient Some addresses must be calculated In general, the security benefits of ASLR far outweigh the cost 32

33. When ASLR Fails ASLR is much less effective on 32-bit architectures Less ability to move pages around randomly May allow the attacker to brute-force the exploit Use a huge NOP sled If the sled is enormous, even a random jump will hit it Use heap spraying Technique that creates many, many, many copies of shellcode in memory Attempts to fill all available heap memory Jump to a random address is likely to hit a copy 33

34. Exploitation Prevention Wrap-up Modern OSes and compilers implement many strategies to prevent exploitation More advanced techniques exist and are under development Exploitation strategies are also becoming more sophisticated Just scratched the surface of attack strategies Bottom line: don t write buggy code Compiler and OS techniques don t fix bugs, they just try to prevent exploitation Even minor flaws can be exploited 34

35. Strategies for Writing Secure Code Assume all external data is under the control of an attacker Avoid unsafe library calls strcpy(), memcpy(), gets(), etc. Use bounded versions instead, i.e. strncpy() Use static analysis tools, e.g. Valgrind Use a fuzzer Runs your program repeatedly with crafted inputs Designed to trigger flaws Use security best-practices Drop privileges, use chroot jails, etc. 35

36. Basic Program Exploitation Protecting the Stack Advanced Program Exploitation Defenses Against ROP Kernel Exploits and Rootkits 36
