1. Review of clash9 John Ousterhout

2. Classes int main(int argc, char* argv[], char* envp[]) { vector<string> args, envs; for (int i = 0; i < argc; ++i) { args.push_back(string(argv[i])); } for (int i = 0; envp[i] != NULL; ++i) { envs.push_back(string(envp[i])); } Clash clash(args, envs); return clash.run_clash(); } Parse command line Read commands Execute builtin commands Manage variables, PATH ClashMain Clash Parse commands ClashParser Executor Fork/exec Configure pipeline I/O SubstrParser Escape/unescape Search/replace (quote- sensitive) CS 190 Lecture Notes: Clash Review (2020) Slide 2

3. Clash, ClashParser, Executor class Clash { Clash( vector<string>& argv, vector<string>& env); class Executor { struct Command {...}; static void execute( vector<Command>& pipedCommands, vector<string>& env, string& output, int& exitStatus); }; int run_clash(); }; class ClashParser { ClashParser(std::string script); vector<Executor::Command> get_next_pipelined_command( string clashPath, vector<string>& clashEnvironment, unordered_map<string, string>& variables); }; CS 190 Lecture Notes: Clash Review (2020) Slide 3

4. SubstrParser SubstrParser(char escapeSymbol); string substring_substitution( string inputString, vector<strLocation>& strLocation, unordered_map<string, string>& substitutionMapping); string escape_chars( string inputString, unordered_set<char>& charsToEscape); string unescape_chars( string inputString, unordered_set<char>& charsToUnescape); vector<SubstrParser::strLocation> find_substrs_between( string inputString, char substrSymbol); string escape_all_in_substrs( string inputString, char substrSymbol, bool escapeLast, unordered_set<char> skipArea); vector<unsigned> search_symbol( string inputString, char symbolToSearch); string remove_chars( string inputString, unordered_set<char>& charsToRemove); string unescape_all_in_substrs( string inputString, char substrSymbol, bool escapeLast, unordered_set<char> skipArea); vector<string> break_into_substrs( string inputString, unordered_set<char>& separators); CS 190 Lecture Notes: Clash Review (2020) Slide 4

5. SubstrParser Example echo abc\'def\' 'xyz' quoted 'text' escape_all_in_substrs(input, '\'', true, {'\ '}); echo abc\'def\' \x\y\z' quoted 'text' Interfaces are fairly general-purpose, but complex CS 190 Lecture Notes: Clash Review (2020) Slide 5

6. Example Usage parsedResult = parser.escape_all_in_substrs( parsedResult, '\'', false, unordered_set<char>({'"', '`'})); parsedResult = parser.escape_all_in_substrs(parsedResult, '"'); parsedResult = parser.escape_all_in_substrs(parsedResult, '` ); Escape vector<unsigned> singleLocs = parser.search_symbol(parsedResult, '\''); if (singleLocs.size() > 0) hasSingleQuote = true; Operate on escaped text unordered_set<char> singleQuote({'\''}); parsedResult = parser.remove_chars(parsedResult, singleQuote); parsedResult = parser.unescape_all_in_substrs(parsedResult, '`'); parsedResult = parser.unescape_all_in_substrs(parsedResult, ' ); Unescape Hard to keep track of what s in parsedResult CS 190 Lecture Notes: Clash Review (2020) Slide 6

7. Parser Alternatives Left-to-right scan of command: Traditional approach to parsing Hard to do in a single pass May have to remember what was quoted in previous passes Whole-command processing (e.g. raft9) Series of operations to perform various substitutions, etc. Remove all of the top-level single-quote characters, and backslash every character that was between them Tends to result in complex APIs, more code CS 190 Lecture Notes: Clash Review (2020) Slide 7

8. Main/Clash Interface Move to main program: Parsing command-line arguments Reading commands Might want to use shell with other command sources? Clash interface: Execute commands (optionally return stdout) Get/set variables CS 190 Lecture Notes: Clash Review (2020) Slide 8

9. Review of clash8 John Ousterhout

10. Overall Comments 2 passes Each pass scans left to right Parser code relatively easy to read, economical: clash_parser.cpp: 455 lines clash_parser.h: 165 lines (Only handles single-digit variable names) Uses regular expressions for variable name parsing: static const std::regex VAR_TERM_REGEX( "^(?:(\\$([a-zA-Z][a-zA-Z0-9]*))|(\\$([0-9*#?]))|(\\$\\{(.*?)\\}))"); ... std::regex_search(input.cbegin() + i, input.cend(), var_term_match, VAR_TERM_REGEX) Reduces code (a bit) But, patterns are hard to read CS 190 Lecture Notes: Clash Review (2020) Slide 10

11. Parser Passes myprog < $x.c a $y b | wc > wc.out; echo all done! break_into_pipelines myprog a $y b < $x.c wc > wc.out echo all done! substitute_and_word_break myprog a foo b wc echo all done! CS 190 Lecture Notes: Clash Review (2020) Slide 11

12. clash_parser API Both APIs exposed to higher-level clash_engine class: vector<pipeline> break_into_pipelines(string input_line); parsed_words_t substitute_and_word_break(string input); Requires extra code in clash_engine: pipelines = parser.break_into_pipelines(input_line); ... for (size_t i = 0; i < pipeline.size(); i++) { ... Clash_parser::parsed_words_t argv = parser.substitute_and_word_break( pipeline[i].command_string); (must also substitute redirect file names) Instead, have parser return fully-substituted pipelines? CS 190 Lecture Notes: Clash Review (2020) Slide 12

13. Informaton Leakage Knowledge of syntactic elements spread across clash_parser: 10 checks for 10 checks for ` 7 checks for \ 4 checks for 2 checks for $ CS 190 Lecture Notes: Clash Review (2020) Slide 13

14. Variable and Command Substitution Variable bindings object passed into parser For command substitution, parser creates new clash_engine Why not just use existing engine recursively? An interesting approach from another project: Main class engine provides callbacks to parser for command and variable substitution Allows the parser to be separated cleanly from the rest of clash Invoke "clash -c for command substitution? Unexported variables won t be visible CS 190 Lecture Notes: Clash Review (2020) Slide 14

15. Cant Scan Lines Backwards if (ends_with(line, "\\")) { throw Parse_exception { "Input cannot end in a backslash." }; } if (ends_with(line, "|") && !ends_with(line, "\\|")) { throw Parse_exception { "Last command cannot end in a pipe." }; } What if line ends in \\|? Or \\\|? Only safe way to parse line is left to right CS 190 Lecture Notes: Clash Review (2020) Slide 15

16. Additional Comments on Clash

17. Overall Comments Lines of code: 1026, 1081, 1190, 1190, 1302, 1544, 1652, 1884, 2641 Common problems: Information leakage Many special cases (especially in parser) Temporal decomposition Opportunities for dividing up functionality: Process command line and read commands in main program Variable handling PATH handling Builtin commands CS 190 Lecture Notes: Clash Review (2020) Slide 17

18. My Parser Implementation Goals: Left-to-right parsing Allow multiple passes Keep track of characters that have been quoted! Encapsulate knowledge of various syntactic elements CS 190 Lecture Notes: Clash Review (2020) Slide 18

19. Token and TokenVector class TokenVector { public: TokenVector(); explicit TokenVector(const char *s); explicit TokenVector(const char *s, size_t size); explicit TokenVector(string *s); explicit TokenVector(Token *token, size_t size); Token &operator[](size_t index); void append(char c, uint8_t quoted = 0); void append(Token token); void append(Token *token, size_t size); void append(const char *s, size_t size); struct Token { char c; uint8_t quoted; Token(char c, uint8_t quoted = 0); Token(const Token& other); bool operator==(const char c); bool operator!=(const char c); static Token emptyChar(); bool isEmptyChar(); bool isWordBreak(); static void appendToString( const Token *token, string *s); static void appendToString( const Token *token, size_t size, string *s); }; void clear(); size_t size(); void quote(size_t first, size_t length); void replace(size_t first, size_t count, char *s); void truncate(size_t size); }; CS 190 Lecture Notes: Clash Review (2020) Slide 19

20. Parsing class Parser { public: static Token *parse(Token *input, int flags, Context *context, TokenVector *output); static const int END_ON_WORDS = 1; static const int END_ON_DOUBLE_QUOTE = 2; static const int END_ON_SINGLE_QUOTE = 4; static const int END_ON_BACK_QUOTE = 8; static const int SUBST_VARIABLES = 0x20; static const int COPY_VARIABLES = 0x40; static const int SUBST_COMMANDS = 0x80; static const int COPY_COMMANDS = 0x100; static const int SUBST_BACKSLASHES = 0x200; static const int COPY_BACKSLASHES = 0x400; static const int SUBST_QUOTE_BACKSLASHES = 0x800; static const int COPY_QUOTE_BACKSLASHES = 0x1000; static const int SUBST_DOUBLE_QUOTES = 0x2000; static const int COPY_DOUBLE_QUOTES = 0x4000; static const int SUBST_SINGLE_QUOTES = 0x8000; static const int COPY_SINGLE_QUOTES = 0x10000; static const int SKIP_LEADING_SEPARATORS = 0x20000; static const int COPY_WORD = COPY_VARIABLES | COPY_COMMANDS | COPY_BACKSLASHES | COPY_DOUBLE_QUOTES | COPY_SINGLE_QUOTES | END_ON_WORDS; CS 190 Lecture Notes: Clash Review (2020) Slide 20

21. Parsing, contd Token *Parser::parse(Token *input, int flags, Context *context, TokenVector *output) { for ( ; ; input++) { if (input->quoted) { output->append(*input); continue; } switch (input->c) { ... case '"': if (flags & SUBST_DOUBLE_QUOTES) { ... parse(input+1, SUBST_VARIABLES | SUBST_COMMANDS | SUBST_QUOTE_BACKSLASHES | END_ON_DOUBLE_QUOTE, context, output); ... } else if (flags & COPY_DOUBLE_QUOTES) { ... parse(input+1, COPY_VARIABLES | COPY_COMMANDS | COPY_QUOTE_BACKSLASHES | END_ON_DOUBLE_QUOTE, context, output); ... } else if (flags & END_ON_DOUBLE_QUOTE) { goto done; } CS 190 Lecture Notes: Clash Review (2020) Slide 21
