Cloud Droplet Concentration in Marine Stratocumulus Clouds
Control of Cloud Droplet Concentration
Control of Cloud Droplet Concentration
in Marine Stratocumulus Clouds
in Marine Stratocumulus Clouds
“Background” cloud droplet concentration
critical for determining aerosol indirect effects
Low N
d
background
strong Twomey effect
High N
d
background
weaker Twomey effect
LAND
OCEAN
Extreme coupling between drizzle and CCN
•
Southeast Pacific
•
Drizzle causes cloud
morphology
transitions
•
Depletes aerosols
MODIS-estimated mean cloud droplet
concentration
N
d
•
Use method of Boers and Mitchell (1996), applied by Bennartz (2007)
•
Screen to remove heterogeneous clouds by insisting on CF
liq
>0.6 in daily L3
Cloud droplet concentrations in marine
stratiform low cloud over ocean
Latham et al.,
Phil. Trans. Roy. Soc.
(2011)
The view from
MODIS
•
Observed
CCN/droplet
concentration occurs in
Baker and Charlson (B&C)
“drizzlepause” region
where CCN loss rates
from drizzle are maximal,
does not occur
where
CCN concentrations are
stable (point A)
•
Clouds in B&C too thick
generate drizzle too
readily
•
Drizzle parameterization
too “thresholdy” (precip
suddenly cuts off when
Baker and Charlson,
Nature
(1990)
observations
10 100 1000
CCN concentration [cm
-3
]
CCN loss rate [cm
-3
day
-1
]
200
100
0
-100
-200
-300
-400
-500
Prevalence of drizzle from low clouds
Leon et al.,
J. Geophys. Res.
(2008)
Drizzle occurrence = fraction of low clouds (1-4 km tops)
for which Z
max
> -15 dBZ
DAY NIGHT
Simple CCN budget in the MBL
Model accounts for:
•
Entrainment
•
Surface production (sea-salt)
•
Coalescence scavenging
•
Dry deposition
Model does not account for:
•
New particle formation – significance still too uncertain to
include
•
Advection – more later
Production terms in CCN budget
FT Aerosol concentration
MBL depth
Entrainment rate
Wind speed at 10 m
Sea-salt
parameterization-dependent
constant
Loss terms in CCN budget: (1) Coalescence
scavenging
Precip. rate at cloud base
MBL depth
Constant
cloud thickness
Comparison against results from
stochastic collection equation (SCE)
applied to observed size distribution
Loss terms in CCN budget: (2) Dry deposition
Deposition velocity
w
dep
= 0.002 to 0.03 cm s
-1
(Georgi 1988)
K
= 2.25 m
2
kg
-1
(Wood 2006)
For
P
CB
= > 0.1 mm day
-1
and
h
= 300 m
= 3 to 30
For precip rates > 0.1 mm day
-1
, coalescence scavenging dominates
Steady state (equilibrium) CCN concentration
Observable constraints from A-Train
MODIS-estimated cloud droplet concentration
N
d
,
VOCALS Regional Experiment
•
Use method of Boers and
Mitchell (1996)
•
Applied to MODIS data by
Bennartz (2007)
Data from Oct-Nov 2008
Free tropospheric CCN source
S = 0.9%
S = 0.25%
Continentally-
influenced FT
Remote “background” FT
Weber and McMurry (FT, Hawaii)
S=0.9%
0.5
0.25
0.1
Precipitation over the VOCALS region
•
CloudSat
Attenuation and Z-R
methods
•
VOCALS
Wyoming Cloud
Radar and in-situ
cloud probes
Very little drizzle
near coast
Significant drizzle
at 85
o
W
WCR data courtesy Dave Leon
Predicted and observed N
d
, VOCALS
•
Model increase in
N
d
toward coast is related to
reduced drizzle
and
explains the majority of
the observed increase
•
Very close to the coast
(<5
o
) an
additional CCN
source is required
•
Even at the heart of the
Sc sheet (80
o
W)
coalescence scavenging
halves the
N
d
•
Results insensitive to
sea-salt flux
parameterization
Predicted and
observed
N
d
•
Monthly climatological
means
(2000-2009 for
MODIS, 2006-2009 for
CloudSat)
•
Derive mean for locations
where there are >3 months
for which there is:
(1) positive large scale div.
(2) mean cloud top height
<4 km
(3) MODIS liquid cloud
fraction > 0.4
•
Use 2C-PRECIP-COLUMN
and Z-R where 2C-PRECIP-
COLUMN missing
Predicted and observed
N
d
- histograms
Minimum values
imposed in GCMs
Mean precipitation rate (2C-PRECIP-COLUMN)
Reduction of
N
d
from precipitation sink
•
Precipitation from midlatitude low clouds reduces
N
d
by a factor of 5
•
In coastal subtropical Sc regions, precip sink is weak
Sea-salt source strength compared with
entrainment from FT
Precipitation
closure
from Brenguier and Wood (2009)
•
Precipitation rate dependent
upon:
•
cloud
macrophysical
properties (e.g. thickness,
LWP);
•
microphysical
properties
(e.g. droplet conc., CCN)
precipitation rate at cloud base [mm/day]
Conclusions
•
Simple CCN budget model, constrained with precipitation rate
estimates from CloudSat predicts MODIS-observed cloud droplet
concentrations in regions of persistent low level clouds with
some skill.
•
Entrainment of constant “self-preserving” aerosols from FT (and
sea-salt in regions of stronger mean winds) can provide sufficient
CCN to supply MBL. No need for internal MBL source (e.g. from
DMS).
•
Significant fraction of the variability in
N
d
across regions of
extensive low clouds is likely related to drizzle sinks rather than
source variability => implications for aerosol indirect effects
•
Range of observed and
modeled CCN/droplet
concentration in Baker
and Charlson
“drizzlepause” region
where loss rates from
drizzle are maximal
•
Baker and Charlson
source rates
Baker and Charlson,
Nature
(1990)
•
Timescales to relax for N
Entrainment:
Surface:
sfc
Precip:
z
i
/(
hKP
CB
) = 8x10^5/(3*2.25) = 1 day for
P
CB
=1 mm day
-1
dep
z
i
/
w
dep
- typically 30 days
Can dry deposition compete with coalescence
scavenging?
w
dep
= 0.002 to 0.03 cm s
-1
(Georgi 1988)
K
= 2.25 m
2
kg
-1
(Wood 2006)
For
P
CB
= > 0.1 mm day
-1
and
h
= 300 m
= 3 to 30
For precip rates > 0.1 mm day
-1
,
coalescence scavenging dominates
•
Examine MODIS Nd imagery – fingerprinting
of entrainment sources vs MBL sources.
Analysis of cloud droplet concentration's impact on aerosol indirect effects and cloud morphology transitions in marine stratocumulus clouds. Observations on drizzle-CCN coupling, MODIS estimation of cloud droplet concentration, and prevalence of drizzle in low clouds. Insights on CCN budget in the Marine Boundary Layer (MBL) model are also discussed.
