Challenges and Solutions in Mobile App Data Synchronization

Reliable, Consistent, and Efficient
Data Sync for Mobile Apps

Younghwan Go*, Nitin Agrawal,
Akshat Aranya, and Cristian Ungureanu

NEC Labs. America     KAIST*
Increase in Data-centric Mobile Apps

Massive growth in mobile data traffic
[Cisco VNI Mobile 2014]
24.3 Exabytes per month by 2019
190 Exabytes of mobile traffic generated globally by 2018
= 42 trillion images, 4 trillion video clips

2
Difficulty in Building Data-centric Apps

Reliability: transparent failure handling



Consistency: concurrent updates, sync atomicity



Efficiency: minimize traffic/battery usage
3
Look!
My data is
corrupted!
010111001
110110111
Mobile App Study on Reliability

Study mobile app recovery under failures
Network disruption, local app crash, device power loss
Analyze recovery when failed during write/update
Test 15 apps that use tables and objects
Independent or existing sync services (e.g., Dropbox, Parse, Kinvey)
Test process
4
1.
Activate airplane mode
2.
Manually kill app
3.
Pull the battery out
Current Mobile Apps are not Reliable!

Disruption recovery
Loss of data if app/notification closed during disruption
No notification of sync failure
Manual re-sync creates multiple copies of same note
Crash recovery
Partial object created locally without sync
Corrupted object synced and spread to second client
Additional observations
No app correctly recovered from crash at object update
Many apps simply disable object update capability altogether
5
More details of the study can be found in our paper
Goals of Sync as a Service

Reliability
User can always sync to the latest data
User’s update is guaranteed to be synced to server

Consistency
Data can always return to a consistent state even after failures
Inter-dependent structured/unstructured data are synced atomically

Efficiency
Minimum mobile data traffic is generated for sync/recovery
Device’s overall network radio usage is reduced to save battery
6
Outline

Introduction
Mobile app study on reliability
Simba Client Design
Evaluation
Conclusion

7
Simba: Data-sync Service for Mobile Apps

High-level programming abstraction
CRUD-like interface for easy development
Unify tabular and object data

Transparent handling of data syncs and failures
Failure detection & recovery at network disruption and crash
Guarantee atomic sync of tabular and object data

Resource frugality with delay-tolerance and coalescing
Delay sync messages to be clustered
Reduce number of network messages & radio usage
8
Writing a Photo App with Simba

Create a photo album

Register read/write sync

Add a new photo


Retrieve stored photo
9
registerReadSync(“album”,600,0,3G);
// period=10min, pref=3G
registerWriteSync(“album”,300,0,WIFI);
// period=5min, pref=WiFi
createTable(“album”, “name VARCHAR, photo OBJECT”, FULL_SYNC);
objs = writeData(“album”, {“name=Snoopy”}, {“photo”});
objs[0].write(photoBuffer);
// write object data
cursor = readData(“album”, {“photo”}, “name=?”, {“Snoopy”});
mis = cursor.getInputStream().get(0);
// inputstream for object
mis.read(buffer);
// read object data into buffer
Writing a Photo App with Simba
Conflict resolution
10
beginCR(“album”);
rows = getConflictedRows(“album”);
for (row; rows; next row) {

// choice = MINE, THEIRS, OTHERS
    resolveConflict(“album”, row, MINE);
}
endCR(“album”);
Overall Architecture
11
Simba Cloud paper to be presented at EuroSys 2015!
“Simba: Tunable End-to-End Data Consistency for Mobile Apps”
sClient: Simba Content Service

Simba Client API (sClientLib)
Interface to access table
and object data for apps
Upcall alerts for events
(new data, conflict) to apps
SimbaSync
Manage fault-tolerance,
data consistency,
row-level atomicity
N/W Manager
Send/receive sync messages, receive notifications
Simba Client Data Store
12
Simba Client Data Store

We don’t want half-formed data to appear on our phone!
Simba Table (sTable)
Unified table store for tabular and object data
13

Logical sTable

Physical sTable
SQLite
LevelDB

Subdivide object into chunks

Map by object_id
Simba Local States
14

Include additional local states to determine:
Health of data (latest vs. updated)
Sync readiness (object closed after update)
Failure state (sync in progress after network disruption)
Recovery actions (retry, reset, recover corrupted objects, etc.)
Simba local states




Dirty Chunk Table (DCT): updated chunk ids per object

Update in
tab | obj data

End of
obj update

Sync in
progress

Row in
conflict
Handling Network Failures
15
Handling App/Device Failures
16
Evaluation

Evaluation goals
Does Simba provide transparency to apps?
Does Simba perform well for sync and local I/O?
Evaluation setup
sClient
Galaxy Nexus (Android 4.2)
Nexus 7 (Android 4.2)
sCloud
2 Intel Xeon servers: 16-core (2.2GHz), 64GB DRAM, 8 7200RPM 2TB disk
4 VMs on each sCloud: 4 core, 8GB DRAM, one disk
WiFi: 802.11n (WPA)
Cellular: 4G LTE (KT, LGU+, AT&T)
17
App Development with Simba

Simple and easy app development with Simba






Building a photo app with existing sync service (Dropbox)
No inter-operation of table and object
No support for row-level atomicity (only column-level!)
No detection & recovery of torn rows
18
Sync Performance

End-to-end sync latency for “
1
B col” & “
1
B col +
1
KB obj”
Test method
Client 1 updates for sync
 client 2 receives update
Clients (Korea), sCloud (Princeton), Dropbox server (California)




Results
Network latency: small component of total sync latency
Simba performs well compared to Dropbox in all cases
19
Local I/O Performance

Time to write/read/delete one row with
1
MB object






~10% slower than Dropbox for write/read
IPC overhead between Simba-app and sClient
Better than Dropbox for delete
Lazy deletion: marked for delete
 delete after sync completion
20
Conclusions

Building data-centric mobile app should be transparent
Mobile app developers should focus on implementing app core logic
Require service that handles complex network and data management
Simba: reliable, consistent, and efficient data-sync service
Unified sTable and API for managing tabular and object data
Transparent handling of data syncs and failures
Resource frugality with delay-tolerant coalescing of sync messages
Practical for real-world usage
Easy app development/porting with CRUD-like API
Sync performance comparable to existing services
Minimum local I/O overhead
21
Thank you!
Simba source:
https://github.com/SimbaService/Simba
Project homepage:
http://www.nec-labs.com/~nitin/Simba

Related Works

Data sync services
Parse, Kinvey, Bayou, Mobius [MobiSys’12]: support table sync
LBFS [SOSP’01]: support file sync
Do not provide sync service for both tables and objects
Failure tolerance
ViewBox [FAST’14]: guarantee consistency of local data at crash
Works for files in desktop FS
Storage unification
TableFS [ATC’13]: separate storage pools for metadata and files
KVFS [FAST’13]: store file and metadata in a single key-value store
Consider integration without network sync or a unified API
23
Balancing Sync Efficiency & Transparency

In-memory vs. persistent DCT
Sync only updated chunks for each object during sync
In-memory DCT lost after crash: s
end entire object
 inefficient!
Persist DCT to prevent re-syncing entire, potentially large objects
In-place vs. out-of-place update
Recover a torn (corrupted) row with data from the consistent state
Out-of-place: local state + I/O overhead for common-case operation
In-place: retrieve consistent version of row from sCloud
24
