Brake Boosters in Automobile Vehicles


BRAKE
 BOOSTER

INTRODUCTION

In Automobile Vehicles, Brake Boosters are used only on
power brakes, not Manual Brakes.
The Booster’s Function is to give more Braking Power
with minimum pressure on the Brake pedal.
If the Booster is not working properly ,you will still have
Brakes, but the Brake pedal will be very hard to Push.
The Brake Booster is located between the Brake pedal
and the Master cylinder .
The basic principle of the Brake Booster is pressure
differential.

Construction

The Brake Booster is made
     of Five Parts:
    - Body
    - Booster piston
    - Booster Return spring
    - Reaction valve
    - Control valve

 The Body has Two Chambers   —The variable pressure
chamber  and the constant pressure chamber  separated
by a diaphragm.

WORKING

As the driver steps on the brake pedal, atmospheric air is introduced
in the variable pressure chamber, producing a pressure differential
between the variable and the constant pressure chamber.
The force generated by the pressure differential on the plate is
transmitted to the push rod via the booster piston which pushes the
piston of the brake master cylinder.
When the pedal is depressed, All components return to its original
positions through the return springs.



TYPES

 The booster's size and whether it has a single
or more than one diaphragm depend on the
year, make and model of the vehicle.
 When ordering a new booster, tell the auto
parts store or dealer the year, make and model
of your vehicle, and they will give you the
correct one.

Thank you.
