ENERGY BASICS
MR. CONKEY PHYSICAL SCIENCE/PROJECT RECHARGE UNIT 1
LESSON 1: SIMPLE CIRCUITS
ESSENTIAL QUESTIONS
•
What is electricity?
•
What evidence do we have that electricity exists if we cannot see it?
•
What makes a circuit?
ACTIVITY 1: INQUIRY PAPERCLIP CIRCUIT
CHALLENGE
•
How can you get the lightbulb to light using four different methods with only a
battery, paperclip, and a lightbulb?
•
Draw diagrams with labels of each of the different methods you come up
with.
•
Did you figure it out? Show me!
ELECTRICITY
•
Electricity
is a result of
charged
subatomic particles
•
Electrons =
negatively
charged
particles
•
Orbit
the nucleus of atoms
•
Protons =
positively
charged
particles
•
One of the
major
building blocks of
an atoms
nucleus
UNBALANCED CHARGES
•
An atoms charges are usually
balanced
(equal #s of
protons
&
electrons
)
•
Energy
is available when charges
are
not
balanced
•
One form of
potential
energy is
static
electricity
•
Charges are
separated
and are not
moving
to regain
balance
ELECTRIC CURRENT
•
Electric current – the movement of
electrons (eˉ)
from a place of an
electric
excess
to one of an electric
deficit
•
In the previous activity the
D-cell
battery
was the
source
of electric
current
•
Inside the battery: chemical reaction
causes eˉ s to move from one
terminal
(end) to the other; when the chemical
reaction
stops
the battery is “dead”
Borrowed from Project Recharge (Envirolution)
ACTIVITY 2 : LIGHTING THE BULB WITH WIRES
•
How will you change your set up in order to light the bulb with two wires
instead of a paperclip?
•
Is there more than one way to achieve this?
•
When you have successfully completed the activity, draw a diagram of your
set up and label it!
ACTIVITY 2 : POST QUESTIONS
•
Where did you connect the wires to the battery?
•
Where did you connect the wires to the light bulb?
•
What happens when you touch the wire to the glass part of the bulb and
why?
ELECTRICITY RECEIVER
•
Anything that uses
electricity
to do
something is an
electricity receiver
•
The lightbulb produces light when
it
receives
electricity as eˉ s flow
through the
whole
circuit
CIRCUITS AND CIRCUIT TYPES
•
Circuit – the
pathway
through
which the electricity
flows
from
the
D-cell
to the
light
and back
•
The circuit must form a
complete
circle
from one end
of the
D-cell
to the other in
order for
electricity
to flow
•
The
individual
parts of the circuit
are called
components
•
Current
flows from the
negative
end of the battery through the
circuit, and then to the
positive
end.
SCHEMATIC DRAWINGS OF CIRCUITS
•
Schematic diagrams –
drawings
used by
electricians/electrical
engineers
to record their
circuits
•
They use symbols that are easy to
draw for the components
•
Check these out!
ACTIVITY 2 EXTENSION: LIGHTING THE BULB (YES,
AGAIN)
•
Can you light a bulb with just one wire and battery?
•
You did it? Great! Show us…
BULBS
•
Filament – the
part
of
the bulb that makes it
light
•
When
electricity
flows through it, it
gets so
hot
that it
gives off
light
ACTIVITY 3: CLOSING AND OPENING CIRCUITS
WITH SWITCHES
CIRCUITS AND SWITCHES
•
What does a switch do to a circuit?
•
You will need one switch
•
Once you have succeeded, summarize how a switch works
CLOSED AND OPEN CIRCUITS
•
Closed circuit – a
circuit
where the
electricity flows
freely
and the
lightbulb
lights
(when the switch
handle is
touching
the clip)
•
Open circuit – a circuit where the
electricity
cannot
flow and the
lightbulb does
not
light (when the
handle is
not
touching the clip)
SIMPLE CIRCUITS QUIZ QUESTIONS (ANSWER ON A
SEPARATE SHEET OF PAPER)
•
What components are needed to make a complete circuit?
•
How many wires connect to the battery, and where do they connect to make a
complete circuit?
•
How many wires connect to the bulb, and where do they connect to make a
complete circuit?
•
How did you get the bulb to light with only one wire?
•
How can you get electricity from a source to a receiver?
•
What does a switch do in a circuit?
•
How do people use schematic drawings?
