1. Association Analysis (An Example) Yuzhen Ye Luddy School of Informatics, Computing and Engineering Spring 2020

2. From transaction data to association rules Itemset Definition A collection of one or more items; e.g., {A, B} Support count/support Frequency/fraction of occurrence of an itemset; e.g. Support count for {A, B} is 3, and the support is 1/2 Frequent itemset An itemset whose support is greater than or equal to a specified threshold; e.g., if the threshold is set at 3 (count), then {A, B} is a frequent itemset, but {A, B, C} is not. Association rule Definition An implication expression of the form X Y, where X and Y are itemsets; e.g., {A, B} {C} Support Fraction of transactions that contain both X and Y, P(X, Y) Confidence Measures how often items in Y appear in transactions that contain X, P(Y|X) Association rule mining: Given a set of transactions T, find all rules X Y having support minsup threshold confidence minconf threshold Unique items: A (apple), B (beer), C (coke), D (diaper), E (egg) TID Items 1 {A, B} 2 {A, B, C, D, E} 3 {A, B, E} 4 {B, D, E} 5 {A, C, E} 6 {B, C, D, E}

3. Frequent itemset identification: Apriori algorithm Apriori principle: If an itemset is frequent, then all of its subsets must also be frequent Support-based pruning: If an itemset is infrequent, then all of its supersets must also be infrequent so can be pruned null A B C D E CE DE CD AD AE BC BD BE AC AB Candidate generation: Fk-1 x F1 method, e.g., {B} + {A,E} {A, B, E} Fk-1 x Fk-1 method: Merge two frequent (k-1)- itemsets if their first (k-2) items are identical; e.g., {A,B}+{A,E} {A, B, E} Alternate Fk-1x Fk-1 Method CDE ABC ABD ABE ACD ACE ADE BCD BCE BDE ABCE BCDE ABCD ABDE ACDE TID Items 1 {A, B} 2 {A, B, C, D, E} 3 {A, B, E} 4 {B, E} 5 {A, B, C, E} 6 {B, C, D, E} ABCDE Support threshold = 3 A frequent itemset D Infrequent itemset (all of {D} s supersets are infrequent) BC Infrequent itemset

4. Support counting using a hash tree Hash Function transaction 1 2 3 5 6 1 + 2 3 5 6 2 + 3 5 6 1,4,7 3,6,9 1 2 + 3 5 6 2,5,8 3 + 5 6 1 3 + 5 6 2 3 4 5 6 7 1 5 + 6 1 4 5 1 3 6 3 4 5 3 5 6 3 5 7 6 8 9 3 6 7 3 6 8 1 2 4 4 5 7 1 5 9 1 2 5 4 5 8 Match transaction against 11 out of 15 candidates

5. Rule generation from frequent itemset E.g., generate all the association rules for itemset {A, B, E} TID Items {A,B,E} {} 1 {A, B} 2 {A, B, C, D, E} 3 {A, B, E} {B,E} {A} {A,E} {B} {A,B} {E} 4 {B, E} Rules pruned 5 {A, B, C, E} 6 {B, C, D, E} {B} {A,E} {E} {A,B} {A} {B,E} Minimum support = 0.5 (count: 3) Minimum confidence = 0.8 confidence({B,E} {A}) = support({A,B,E})/support({B,E}) = 3/5 confidence({A,E} {B}) = support({A,B,E})/support({A,E}) = 3/5 confidence({A,B} {E}) = support({A,B,E})/support({A,B}) = 4/5 (no need to scan the transactions again to compute confidence scores)

6. Compact representation of frequent itemsets An itemset X is maximal frequent if it is frequent and none of its immediate supersets is frequent An itemset X is closed if none of its immediate supersets has the same support as the itemset X. Minimum support = 0.5 (count=3) null 4 A B C D E CE DE CD AD AE BC BD BE AC AB 3 4 3 CDE 3 ABC ABD ABE ACD ACE ADE BCD BCE BDE Frequent Itemsets TID Items Closed Frequent Itemsets ABCE BCDE ABCD ABDE ACDE 1 {A, B} 2 {A, B, C, D, E} Maximal Frequent Itemsets ABCDE 3 {A, B, E} 4 {B, E} 5 {A, B, C, E} AB AE Not closed Closed but not maximal 6 {B, C, D, E} BE CE ? Maximal ? BCE ? ABE
