The Ladybird (4330 48thStreet NW) Transportation Presentation Gorove/Slade Associates 1 November 9, 2016
Site Location The Ladybird (4330 48th Street NW) - Transportation 2
Local Transit Facilities The Ladybird (4330 48th Street NW) - Transportation 3
Project Transportation Characteristics Proximity to transit and alternative travel modes: o Nearby Tenleytown-AU Metrorail Station (0.8 miles away) o 2 Nearby Metrobus routes o Site has Walkscore of 77 Very Walkable and Bikescore of 65 Bikeable Census Data o 46% drive to work o 27% take transit to work o 5% cycle to work o 8% walk to work o 14% other (work from home/retired/other) Implementation of on-site pedestrian, bicycle, & loading facilities The Ladybird (4330 48th Street NW) - Transportation 4
Site Plan The Ladybird (4330 48th Street NW) - Transportation 5
Potential Grocery Market Area The Ladybird (4330 48th Street NW) - Transportation 6
Parking - Direction of Approach The Ladybird (4330 48th Street NW) - Transportation 7
Project Traffic Generation Residential: o AM Peak Hour: 12 inbound/ 46 outbound o PM Peak Hour: 47 inbound/ 26 outbound Grocery (Portion of trips intercepted from Massachusetts Avenue): o AM Peak Hour: 82 inbound/ 51 outbound o PM Peak Hour: 177 inbound/ 170 outbound The Ladybird (4330 48th Street NW) - Transportation 8
Potential Traffic Mitigation Strategies Signal timing adjustments Physical traffic signal modifications Mid-Block Massachusetts Avenue Crossing & HAWK Signal Pedestrian improvements & upgrades (mid-block crossing & signal) Loading Management Plan Construction Traffic Management Plan Transportation Demand Management Plan o Residential elements o Grocery employee elements The Ladybird (4330 48th Street NW) - Transportation 9
END The Ladybird (4330 48th Street NW) - Transportation 10
Trip Generation Trip Gen Summary for Residential AM Peak Hour PM Peak Hour Mode In Out Total 58 veh/hr 33 ppl/hr 20 ppl/hr 13 ppl/hr In Out Total 73 veh/hr 41 ppl/hr 24 ppl/hr 16 ppl/hr Auto Transit Bike Walk 12 veh/hr 7 ppl/hr 4 ppl/hr 3 ppl/hr 46 veh/hr 26 ppl/hr 16 ppl/hr 10 ppl/hr 47 veh/hr 27 ppl/hr 16 ppl/hr 11 ppl/hr 26 veh/hr 14 ppl/hr 8 ppl/hr 5 ppl/hr Trip Gen Summary for Grocer AM Peak Hour PM Peak Hour Mode In Out Total In Out Total Auto Transit Bike Walk 82 veh/hr 23 ppl/hr 12 ppl/hr 46 ppl/hr 51 veh/hr 15 ppl/hr 7 ppl/hr 29 ppl/hr 133 veh/hr 38 ppl/hr 19 ppl/hr 75 ppl/hr 177 veh/hr 170 veh/hr 50 ppl/hr 25 ppl/hr 100 ppl/hr 347 veh/hr 98 ppl/hr 49 ppl/hr 197 ppl/hr 48 ppl/hr 24 ppl/hr 97 ppl/hr The Ladybird (4330 48th Street NW) - Transportation 11
Truck Turning Diagrams WB-30 Inbound The Ladybird (4330 48th Street NW) - Transportation 12
Truck Turning Diagrams WB-30 Outbound The Ladybird (4330 48th Street NW) - Transportation 13
Truck Turning Diagrams WB-50 Inbound The Ladybird (4330 48th Street NW) - Transportation 14
Truck Turning Diagrams WB-50 Inbound The Ladybird (4330 48th Street NW) - Transportation 15
Truck Turning Diagrams WB-50 Outbound The Ladybird (4330 48th Street NW) - Transportation 16
Truck Turning Diagrams WB-50 Outbound The Ladybird (4330 48th Street NW) - Transportation 17
