2. Roadmap for the DNS Load Balancing Service at CERN Kristian Kouros on behalf of the DNS Load Balancing Team HEPiX Autumn 2020 Workshop

3. Topics 1 INTRO 2 IMPLEMENTATION 3 UPGRADES 1/21

4. Intro

5. T here is nothing certain, but the uncertain. -P roverb- 2/21

6. DNS LB 101 Node (1) 1 Alias represented by 1 1 Node (3) (2) Enquirer(s) DNS Service 3/21

7. DNS LB 101 Node (1) 1 Alias represented by 1 1 Node (3) (2) Enquirer(s) DNS Service 3/21

8. DNS LB 101 N N Nodes (1) 1 Alias represented by N N Nodes (3) (2) Enquirer(s) DNS Service 4/21

9. DNS LB 101 N N Nodes (1) 1 Alias represented by N Round Round- -Robin N Nodes Robin Serving (3) (2) Enquirer(s) DNS Service 4/21

10. DNS LB 101 N N Nodes (1) 1 Alias represented by N Round Round- -Robin N Nodes Robin Serving (3) Agnostic of Node s Wellbeing Agnostic of Node s Wellbeing DoS for 1 in N user DoS for 1 in N user (2) Enquirer(s) DNS Service 4/21

11. DNS LB 101 N N Nodes Arbiter (1) (3) (2) Enquirer(s) DNS Service 5/21

12. Our Implementation

13. System architecture NODES ERMIS LBD NodeN Node1 Node1 Backup Node2 Node1 REST API DB Node1 Primary LBClient snmpd DNS Service Computing Cloud 6/21

14. LBClient NODES NodeN Runs on every node that is behind an alias Node1 Node1 Node2 Node1 Node1 LBClient Metrics: Checks -> tmpfull, nologin , daemon , etc Load -> collectd, lemon, const Summarizes evaluation into an int value Best value: The lowest positive snmpd 7/21

15. LB Daemon LBD Backup Selects best nodes per alias Primary Backup performs same tasks ChecksPrimary s heartbeat: If dead take its place 8/21

16. REST Service Self-manage aliases ERMIS UI & CLI paired with MySQL What users can CRUD : Alias Hostgroup, Visibility, Number of best nodes, Cnames, Nodes Etc. REST API DB 9/21

17. Workflow (1)Periodic SNMP GET @all NODES ERMIS LBD NodeN (0) Define Alias (3)Calculate best nodes Node1 Node1 Backup Node2 NodeN: alias1 = 21 REST API Node1 DB Puppet Node3: alias1 =7 Node2: alias1 = 15 Node1: alias1 = -1 Node1 Primary LBClient (2)Nodes report load for Alias1 (4) Update nodes for Alias1 (6) Usage DNS query Alias1 DNS Service Computin g Cloud IP of Node3 (5) Resolution 10/21

18. Upgrades

19. Lets rewind a bit 1. Stable service for +10 years 2. Each component in different language : LBD Perl LBClient C Ermis Python 3. Sequential processes 4. Number of aliases in increase Example: From 2017 to 2019 ~50% increase 11/21

20. No. of aliases in 2020

21. Upgrade #1: LBD & LBClient production The Issue: Sequential processes were limiting performance and alias capacity The Solution: 1.Reimplement LBD and LBClient in Golang Aliases evaluated in parallel Nodes checked only once 2. Partition aliases & LBD/partition The Result: SNMP Querying time reduced from 5 minutes to less than 1 minute 13/21

22. production Upgade #2 : Node Control The Issue: There was no way to overwrite the nodes that LBD what receiving from PuppetDB. The solution: Introduce a new configuration element in Ermis UI & CLI for the user to define blacklisted and/or whitelisted nodes. 14/21

23. Upgrade #3 : Security production The Issue: Shibboleth SSO No 2FA The Solution: Replace Shibboleth with OpenIDC Protect SSH connections with 2FA 15/21

24. Upgrade #4 : Ermis REST Back-end development The Issue: The Ermis REST API back-end is still in Django/Tastypie, different than the rest of the components High abstraction and undefined data types The Solution: Reimplemented in Golang + Echo Framework + GORM The result: The Pros/Cons of Golang over Python. Performance not evaluated yet. 16/21

25. Upgrade #5: Cloud Native development The Issue: Ermis REST Service, LBD Primary & Backup run on VMs Service availability not ideal The Solution: Deploy in a Kubernetes cluster 17/21

26. development Upgrade #6 : Node Alarms The Issue: Users are not aware if the number of defined nodes per alias is maintained The Solution: Introduce new feature for setting an alarm if number of nodes crosses the threshold 18/21

27. Evaluation: Push vs Pull To do The Issue: LBD, even though in parallelization, it has to Pull data from a lot of nodes. Alternative Scenario: Evaluate if it would be better for the Nodes to Push instead. Feedback or suggestions are welcomed 19/21

28. Summary Overview of CERN s open-source load-balancer for DNS (but not only!) Presentation of the undertaken upgrades to meet the new demands of the service Project : https://github.com/cernops/golbclient https://github.com/cernops/golbd 20/21

29. lb-experts-public@cern.ch kristian.kouros@cern.ch Thank You ! 21/21
