Riemann Sums
www.mastermathmentor.com
A Riemann sum (named after German mathematician Bernhard Riemann) is an
approximation of the region between a function
f
(
x
) and the
x
-axis. The Riemann
sum is calculated by dividing the region into rectangles of equal width and then
adding the areas of these rectangles. Riemann sums come in three varieties:
Left
Riemann Sums,
Right
Riemann Sums, and
Midpoint
Riemann Sums.
The area under the
curve is approximated
with 4 left Riemann
sums. For this function,
this will underestimate
the true area.
The area under the
curve is approximated
with 4 right Riemann
sums. For this function,
this will overestimate
the true area.
The area under the curve is
approximated with 4
midpoint Riemann sums. For
this function, this will come
close to the true area.
The Trapezoidal Rule
www.mastermathmentor.com
Recall that the area of a trapezoid = ½ base (
h
1
+
h
2
).
Approximating An Irregular Area
www.mastermathmentor.com
A golf green is 60 feet across at its widest point. The green is
divided into 6 sections of equal width having measurements in feet
as shown below. Use left, right, and midpoint Riemann sums as well
as trapezoids to approximate the area of the green.
Interpreting Area
www.mastermathmentor.com
When the
x
-axis is measured in time and the
y
-axis is measured
as a velocity, the Riemann sum will be measured in the product
of time and velocity which is distance. Thus area under a curve
has an important real-life interpretation.
A bicyclist has his speed monitored over
a hilly section of a course. The table
gives his speed at 5 minute intervals in
miles per hour. Use the trapezoidal rule
to approximate the distance he travels
over 40-minutes and his average speed.
5 minutes is a
fairly large
increment. If you
use smaller time
increments. You
gain accuracy
but increase the
number of
calculations.
www.mastermathmentor.com
Purchase the full version - 18 slides
Content: Riemann Sums
www.mastermathmentor.com
Only $10.95 for the full presentation of 18 content slides.
(download version)
You receive:
• A narrated version (59 megs)
• An un-narrated version (4 megs)
• A PDF of the narration used if you want to provide the commentary
Note: Downloading the full presentation may require high-speed internet.
Powerpoint slides to help teach in the classroom
Or purchase the entire set of MasterMathMentor.com AB
Calculus On the Wall
Powerpoint presentations - Only
$119.95 -
sent to you on a 2-gig flash drive.
Topics cover:
• Limits
• Derivative Definition
• Differentiation
• Motion
• Related Rates
• Function Analysis
• Optimization
• Antiderivatives
• Riemann Sums
• Definite Integrals • Area/Motion Revisited
• Volume
• Inverses/Transcendentals
• Differential Equations
Explore the concepts of Riemann sums, different types of approximations like left, right, and midpoint sums, trapezoidal rule, and interpreting area in real-life scenarios with examples. Learn how to apply these methods to approximate irregular areas and calculate distances and average speeds. Dive into the world of calculus with practical applications and visual aids.
Download Presentation
Please find below an Image/Link to download the presentation.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author.If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.
You are allowed to download the files provided on this website for personal or commercial use, subject to the condition that they are used lawfully. All files are the property of their respective owners.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author.
E N D
Presentation Transcript
mastermathmentor.com presents CALCULUS ON THE WALL Helping students learn and teachers teach 9. Riemann Sums (sample version) Created by: Stu Schwartz Un-narrated Version Edited by: Jake Weinberg Graphics: Apple Grapher: Version 2.3 Math Type: Version 6.7 Intaglio: 2.9.5a Fathom: Version 2.11
Riemann Sums A Riemann sum (named after German mathematician Bernhard Riemann) is an approximation of the region between a function f(x) and the x-axis. The Riemann sum is calculated by dividing the region into rectangles of equal width and then adding the areas of these rectangles. Riemann sums come in three varieties: Left Riemann Sums, Right Riemann Sums, and Midpoint Riemann Sums. The area under the curve is approximated with 4 left Riemann sums. For this function, this will underestimate the true area. The area under the curve is approximated with 4 right Riemann sums. For this function, this will overestimate the true area. The area under the curve is approximated with 4 midpoint Riemann sums. For this function, this will come close to the true area. www.mastermathmentor.com
The Trapezoidal Rule Recall that the area of a trapezoid = base (h1 + h2). h2 h1 base A 1 +1 2 ( ) f 0 ( )+ f 2 ( ) 2 ( ) f 2 ( )+ f 4 ( ) 2 2 A 1 2 ( ) f 0 ( )+2f 2 ( )+ f 4 ( ) A 1+2 5 ( )+17 A 28 2 A 1 21 ( ) f 0 ( )+2f 1 ( )+2f 2 ( )+2f 3 ( )+ f 4 ( ) A 1 2 A 26 1+2 2 ( )+2 5 ( )+2 10 ( )+17 www.mastermathmentor.com
Approximating An Irregular Area A golf green is 60 feet across at its widest point. The green is divided into 6 sections of equal width having measurements in feet as shown below. Use left, right, and midpoint Riemann sums as well as trapezoids to approximate the area of the green. base = 60 =10 6 Left: A 10 4+16+ 32+ 47+ 42+ 38 ( ( )=1,790 ft2 )=1,830 ft2 Right: A 10 16+32+47+42+38+8 Trapezoids: A 10 [ ]=1,810 ft2 4+ 32+64+94+84+76+8 2 OR A 1790+1830 =1,810 ft2 2 ( )= 2,020 ft2 Midpoint: A 20 16+47+38 www.mastermathmentor.com
Interpreting Area When the x-axis is measured in time and the y-axis is measured as a velocity, the Riemann sum will be measured in the product of time and velocity which is distance. Thus area under a curve has an important real-life interpretation. A bicyclist has his speed monitored over a hilly section of a course. The table gives his speed at 5 minute intervals in miles per hour. Use the trapezoidal rule to approximate the distance he travels over 40-minutes and his average speed. min mph 0 10 5 16 10 18 15 9 20 12 5 minutes is a fairly large increment. If you use smaller time increments. You gain accuracy but increase the number of calculations. 25 7 Units should be consistent. Time will be measured in hours. Base = 5 12 Distance 1 2 12 Distance 8.917 miles Average speed distance time 30 14 60=1 35 20 40 12 10+ 32+ 36+18+24+14+28+ 40+12 1 [ ] =8.917 miles 2 3 hours =13.375 mph www.mastermathmentor.com
