Remedial Alternatives for Landfill Site Management

Project 3

Hints

Landfill Site

Remedial Alternatives

•

Alternative A - Do Nothing

•

Alternative B - Impermeable Cap

•

Alternative C - Cap and Confining Wall

•

Alternative D - Cap, Slurry Wall and Drain

•

Alternatives E, F and G – Your Alternatives

Part A

•

Create the

“

working directory

”

–

C:\temp\Proj3a

•

Download the Vista1.gwv.zip file (from class webpage)

•

Un-Zip the file to get the file Vista1.gwv

•

Place the file in the working directory

•

Open the model Vista1

•

Run the model (steady state)

Part a

Part B

•

Create a new

“

working directory

”

–

C:\temp\Proj3b

–

Keep a separate working directory for each part, so you can back up if

you make a mistake

•

Save (or copy) the file Vista1.gwv from

–

C:\temp\Proj3a

•

to

–

C:\temp\Proj3b

•

Select

–

MODELS – PATHS TO MODELS

•

Set working directory to:

C:\temp\Proj3b

Part b - Transient Model Setup

•

In Part B: Convert the

model to a transient

model with 1 stress

period

Stress period Types

•

Select: Stress Period Types



 Set all to transient

•

Set up the Stress periods

–

Stress period length = 972,000,000 seconds (= 30.82 years)

–

20 time steps

–

Time step multiplier of 1.5

Specific Yield

•

Set specific yield = 0.28

Part b - Initial Heads

•

Select: Model



 MODFLOW



Package Options



 Initial

Heads tab

•

Select: Initial Head Location:

–

Read Heads Directly from Binary

Head Save File

–

Browse

•

Select: *.hds file from Part A

•

MAKE SURE THE Part A HDS

FILE IS IN A DIFFERENT FOLDER

FROM THE PART B FILES!

Part B

–

 Impermeable Cap

•

Set recharge over cap area to 0

Recharge

Part C

–

 Confining Wall

•

Use a “Wall” BC

–

 set K ~0

Confining Wall

Wall

Part d - Drains

Part d - Drains

Landfill

Wall

Drain

Slide Note

Embed Share

Download

In this project, you will explore various remedial alternatives for managing a landfill site, including options like impermeable caps, confining walls, and more. Step-by-step instructions are provided for setting up models and conducting analyses to assess the effectiveness of different approaches. Dive into environmental engineering solutions for sustainable waste management practices.

mcclenny_p Follow

Uploaded on Feb 24, 2025 | 0 Views

Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

E N D

Presentation Transcript

Project 3 Hints

Landfill Site Landfill

Remedial Alternatives Alternative A - Do Nothing Alternative B - Impermeable Cap Alternative C - Cap and Confining Wall Alternative D - Cap, Slurry Wall and Drain Alternatives E, F and G Your Alternatives

Part A Create the working directory C:\temp\Proj3a Download the Vista1.gwv.zip file (from class webpage) Un-Zip the file to get the file Vista1.gwv Place the file in the working directory Open the model Vista1 Run the model (steady state)

Part a

Part B Create a new working directory C:\temp\Proj3b Keep a separate working directory for each part, so you can back up if you make a mistake Save (or copy) the file Vista1.gwv from C:\temp\Proj3a to C:\temp\Proj3b Select MODELS PATHS TO MODELS Set working directory to: C:\temp\Proj3b

Part b - Transient Model Setup In Part B: Convert the model to a transient model with 1 stress period

Stress period Types Select: Stress Period Types Set all to transient Set up the Stress periods Stress period length = 972,000,000 seconds (= 30.82 years) 20 time steps Time step multiplier of 1.5

Specific Yield Set specific yield = 0.28

Part b - Initial Heads Select: Model MODFLOW Package Options Initial Heads tab Select: Initial Head Location: Read Heads Directly from Binary Head Save File Browse Select: *.hds file from Part A MAKE SURE THE Part A HDS FILE IS IN A DIFFERENT FOLDER FROM THE PART B FILES!
