New Lebanese Standards for Lifts
undefined
NL EN 81standards
Habib Srour
9 new Lebanese standards related to lifts
were released during the year 2015
This presentation is intended to provide
awareness and gives brief on the scope and
contents of those standards
0- Introduction
1- Scope
2- Normative references
3- Terms and definitions
4- List of significant hazards
5- Safety Requirements
6- Verification
7- Information for use
Annexes: Informative, Normative
EC Type Examination Certificate for the lift as
a set
Reference to Other Standards
Languages of the information
Goods & Passenger Lifts
Replaces EN 81-1 and EN
81-2
EN 81-20 defines the
technical requirements for
elevator construction
EN 81-50 provides the
framework for design and
testing of elevator
components
5.2- Well, machinery
spaces and pulley
rooms *
5.3- Landing doors
and car doors
5.4- Car,
counterweight and
balancing weight
5.5- Suspension means,
compensation means
and related protection
means
5.6- Precautions against
free fall, excessive
speed, unintended car
movement and creeping
of the car
5.7- Guide rails
5.8- Buffers
5.9- Lift machinery and
associated equipment
5.10- Electric
installations and
appliances
5.11- Protection
against electric faults;
failure analysis; electric
safety devices
5.12- Controls - Final
limit switches -
Priorities
0.035 * V
2
Needed Headroom
Clearances
Signs on car top for
Refuge: (one or more)
0.035 * V
2
Needed pit clearances
Signs in pit for Refuge
(one or more)
Screen
between two
lifts is
measured
from handrail
Example: Fixed
Example movable
This standard specifies the design rules,
calculations, examinations and tests of
Lift Components
.
5.2- Door locking
5.3- Safety gear
5.4- Overspeed
governors
5.5- Buffers
5.6- Safety circuits
containing electronic
components
5.7- Car ascending
overspeed protection
means
5.8- Unintended car
movement protection
means
5.9- Rupture valve/one-
way restrictor
New Lifts in Existing Building
This Standard covers:
◦
installation of complete
new lift(s) in an existing
building; or
◦
The replacement of
existing lift(s) by new
ones.
This Standard does not
cover:
◦
Replacement or
modifications of some
parts to a lift already
installed.
5.1- Perforate wall of
the lift well
5.2- Clearances
between car,
counterweight or
balancing weight
5.3
-
Counterweight or
balancing weight in a
separate well
5.4
-
Pulleys in the well
5.5
-
Reduced top
clearances
5.6
-
Car roof
balustrade
5.7
-
Reduced bottom
clearances
5.8
-
Apron
5.14
-
Height of
landing doors
5.9
-
Height of machine
room
5.10- Height of machine
room doors
5.11
-
Dimensions of trap
doors for machine room
5.12
-
Height of pulley
rooms
5.13
-
Dimensions of trap
doors for pulley room
Requirements
Sign
Requirements
Sign
Mechanisms for reduced
headroom and pit
Accessibility for persons with
impaired mobility
Accessibility to lifts for persons including
persons with disability
19-Sep-24
29
Entrance clear
opening to be at least
800 mm
The door time is to
be adjustable
(normally between 2
s and 20 s).
Door close
button in
the car.
19-Sep-24
30
19-Sep-24
31
On one side wall of the
car a handrail shall be
installed on a height of
900mm
In case a user of a
wheelchair cannot turn
it around, a mirror
shall be provided.
19-Sep-24
32
The car control panel
location on the wall:
◦
with centre opening doors, on
the right hand side when
entering the car;
◦
with side opening doors, on the
closing jamb side
Distance between centreline
of buttons and corner:
◦
400mm for car; and
◦
500 mm for landing.
19-Sep-24
33
Control devices – Requirements (2)
19-Sep-24
34
19-Sep-24
35
Stairlifts & Inclined Lifting
Platform
Stairlifts and inclined lifting platforms
intended for persons with impaired mobility
19-Sep-24
37
Safety requirements for
construction, manufacturing,
installation, maintenance and
dismantling of:
◦
electrically operated stairlifts:
e.g.
Chair; Standing platform; and
wheelchair platform
◦
affixed to a building structure,
◦
moving in an inclined plane; and
◦
intended for use by persons with
impaired mobility
Rated speed: 0.15m/s max
Rated load:
◦
Minimum 115kg for person users and
◦
Minimum 250kg/m
2
for wheel chair users
Standing Passenger
Seated Passenger
19-Sep-24
42
Vertical lifting platforms intended for use by
persons
with impaired mobility
Safety requirements for
construction,
manufacturing,
installation, maintenance
and dismantling of:
◦
electrically powered
vertical lifting platforms
◦
affixed to a building
structure
◦
intended for use by
persons with impaired
mobility
travelling vertically between
predefined levels along a
guided path whose
inclination to the vertical
does not exceed 15°;
intended for use by persons
with or without a wheelchair;
with enclosed liftways;
with a speed not greater than
0,15 m/s;
with platforms where the
carrier is not completely
enclosed.
Rated speed: 0.15 m/s max
Rated load: 250kg/m
2
Maximum rated load:
500kg
Overload required
Dimension: clear loading
area of 2m
2
max
If travel is 3m or less
Min door height 1100 mm
If travel is more than 3m
Min door height 2000 mm
Accessibility Improvement of
Existing Lift
This European Standard provides rules on
how to apply EN 81-70 to existing lifts to
improve their accessibility for persons
including persons with disability.
Accessible Only Goods Lifts
This European
Standard covers:
◦
accessible
goods only
lifts;
◦
With rated speed not
exceeding 1m/s
◦
With rated load
exceeding 300 kg; and
◦
Not intended to move
persons.
Type A, where the
intended use is bound
to the following two
simultaneous
conditions:
◦
Maximum rated speed:
0,30 m/s;
◦
Maximum travelling
height: 12 m;
Type B, where one of
the conditions
mentioned above is
not fulfilled.
Automatic power operated doors shall not be
used.
Type A could be platform and not necessary
enclosed cabin
Inclined Lifts
Safety rules for the
construction and installation of
permanently installed new
electric lifts,
with traction or positive drive,
serving defined landings levels,
having a vehicle designed to
convey passengers or
passengers and loads,
suspended by ropes or chains
and travelling in a vertical plan
along guide rails that are
inclined at an angle of between
15° and 75° in relation to the
horizontal.
Inclination: a variation in
inclination is permitted
for the travel path;
travel path: confined
within the vertical plane;
Maximum capacity of
the car: 7500 kg (100
passengers);
maximum rated speed
(
v
): 4 m/s.
Same principle of part 20 with the differences
due to inclination, such as:
◦
Formula, for the clear distance needed in the
headroom: 0.035V
2
Sin∝
