Is RRTMGP Suited for GPU?

Is RRTMGP suited for GPU?

Expectations

1.

Embarrassing parallel

–

Columns can be split up and computed in parallel

2.

Memory intensive computations

–

Memory is faster on GPU than CPU

Answer to the title:

Yes

Context

Speed-up GPU vs CPU

•

The expected speed up will be defined much

by the memory performance.

–

GDDR is faster than DDR. This advantage is

expected to further grow in future GPU

generations.

–

Memory bandwidth speed is approximately 1.5 - 2

times faster on GPU.

–

Drawback: GDDR is typically smaller than DDR

Computations in RRTMGP

•

Multiple components to parallelize

–

Gas optics, flux solver, etc.

–

Multiple sub-components, each with its own logic

•

Computations are relatively lightweight

–

Terms and factors from multiple sources, often arrays,

are combined using basic arithmetic.

•

Static data can be parked on GPU memory

–

e.g. k-coefficients

Scale

Dimensions Approx.

40.000+ Columns

100 Layers

250 Pseudo-spectral

10 other

Memory Access Patterns

•

Memory access is mostly sequential.

–

There are local interpolations that interfere with a

perfect sequential memory access. These

disruptions are at a local scale only.

•

Indexing on arrays change for components.

–

Gas optics

(pseudo-spectral, layer, column)

–

Flux solver

(column, layer, pseudo-spectral)

Lessons learned

Overview

•

Compilers struggle with newer FORTRAN,

OpenACC, and libraries.

–

FORTRAN 2003

–

NetCDF library for I/O

•

For OpenACC we tested:

–

PGI and Cray

•

Without OpenACC we tested:

–

Intel, PGI, GNU, Cray, and NAG

Success: Cray and OpenACC

•

We got gas optics to work to the extend that it compiled

and computed the correct answers to 15 digit precision on

GPU.

•

With $ACC PARALLEL; $ACC KERNEL crashes

–

Error messages could be better

•

Issues

–

Member variables and OpenACC are not workable

–

Function calls within parallel regions are not supported by

compiler

–

Optional arguments and OpenACC are not workable

–

Defining dynamic dimensions of variables in member functions

PGI and NetCDF

•

Failure: PGI and NetCDF do not play nice

–

ERROR: Segmentation fault

–

pgi/15.3 netcdf/4.3.3.1 on Janus @

rc.colorado.edu

•

This prevented us from testing OpenACC and PGI.

–

The PGI compiler is one of the prime choices for

OpenACC.

Q: What is the standard NetCDF library for Python?

–

netCDF4, scipy.io.netcdf, or Scientific.IO.NetCDF

Intel

•

Does not support OpenACC for practical

purpose.

•

A few hick-ups with FORTAN 2003 standard,

but overall “thumbs up”.

•

Side note: The compiler is sometimes too

lenient in the syntax it accepts

•

intel/15.0.2 netcdf/4.3.3.1

GNU

•

Does not support OpenACC for practical

purpose.

•

A few hick-ups with FORTAN 2003 standard,

but overall “thumbs up”.

•

Does not support some FORTAN 2003 implicit

memory allocations

•

Expected to be slower than other compilers

•

gnu/4.9.2 netcdf/4.3.3.1

Extra slides

Parallelism in RRTMGP

•

Columns

•

Layers

•

Pseudo-spectral (gpts)

•

other

Strategies for OpenACC Parallelism

Solver

Gas Optics

OpenACC – example gas optics

Future Outlook

•

C++ implementation, Hackathon, etc.

–

http://www.openacc.org/content/openacc-

hackathon-tu-dresdenforschungzentrum-julich
