Heavy Ion Physics at RHIC: RUN14-16 Overview
Heavy Ion Physics in RUN14-16
Japan Korea PHENIX meeting
Nov. 27, 2014
Y. Akiba
RHIC Runs (2014-2016)
•
RUN14 (completed)
–
Au+Au at 14.6 GeV
(complete Beam Energy Scan)
–
Au+Au at 200 GeV
(Main part of the run)
–
He
3
+Au at 200 GeV
(QGP in small system)
•
RUN15
(Jan – June 2015)
–
p+p at 200 GeV
(transverse spin)
–
p+Au at 200 GeV
–
p+Al at 200 GeV
•
RUN16
–
Au+Au at 200GeV
10 weeks
–
To Be Determined
510GeV pp or 62 GeV AuAu
Heavy Quark Campaign in RUN14-16
•
Main purpose of RHIC run in 2014-16 is to measure heavy
quarks (charm and bottom)
•
PHENIX has silicon vertex tracker VTX and FVTX. Charm and
botton decays are identified by precision vertex
measurement by these detectors.
–
STAR also has HFT (Heavy Flavor tracker) from RUN14
•
RHIC runs with VTX
RUN11
Au+Au @200 GeV
(1
st
run with VTX)
RUN12
p+p @200/510 GeV
(1
st
run with FVTX)
Cu+Au @ 200 GeV
RUN14
1
st
Main Heavy Flavor run.
Au+Au@200 GeV; ~20 times of RUN11 data
RUN15
p+p: baseline
p+A: Cold nuclear Matter effects
RUN16
2
nd
Main Heavy Flavor run
Heavy Quark
(charm, bottom)
•
Protons and neutrons are made of u and d quarks
(+gluons, etc)
•
u, d, s quarks are light and can be made in later stage of nuclear reaction
•
c, b
quarks are heavy (m
c
, m
b
>
QCD
)
They can only be produced at hard collisions at the initial stage
Their production rate can be calculated by pQCD
Very useful probe for both of Quark Gluon Plasma and nucleon structure
Quarks
~2MeV
~5MeV
~1.3GeV
~0.1GeV
約
4.2GeV
~170 GeV
(mass of proton ~ 0.94 GeV)
Probing Quark Gluon Plasma with heavy quarks
R
AA
of
b,c
e
v
2
of
b,c
e
Strong suppression of electron from heavy
flavor decay is observed
Large energy loss of heavy quark in QGP
Large elliptic flow strength v2 of single
electrons from heavy flavor decay is observed
Heavy quark flows in QGP medium
In these previous measurements, b
e and c
e were not separated
Measure b
e and c
e separately
PHENIX measured heavy quark production in Au+Au collisions via
single electrons from heavy flavor decays
PRL98, 172301
BEAM VIEW
SIDE VIEW
VTX Barrel
beam
6
RUN14: heavy Quark run
•
2.3/nb
or 14.3 Billion Au+Au events
recorded
within |z|<10cm
(good VTX acceptance)
•
Total # of events recorded > 17 Billon
•
DCA resolution 80
m for pT>1 GeV achieved in RUN14. Will be
improved by further refinement of alignment/calibraiton
recorded luminosity in VTX
acceptance
DCA resolution in RUN14 data
VTX analysis status
•
We are finalizing the data analysis of RUN11 Au+Au, the first
run of VTX
–
About 2B Au+Au events within VTX acceptance
•
All tools for event analysis have been developed
–
Calibration
–
Alignment
–
DC-VTX track reconstruction
–
Decomposition of DCA (Distance to Closest Approach) distribution to
separate b
e and c
e
•
Paper of the final result early in the next year
•
All analysis tools are available for RUN12 and RUN14 data
analysis
RUN12: Cu+Au@200 GeV
2.9/nb (36/pb N+N)
RUN14: > 17 B events with ~2 times of effective acceptance
Effectivey, ~20 times of RUN11 data
RUN11 DCA resolution
•
DCA resolution better than
–
80 micron for pT> 1GeV/c
–
60 micron for pT > 3GeV/c
D
0
c
= 123 micron
B
0
c
= 455 micron
RUN11 DCA distributions
•
DCA distributions are well reproduced by sum of
b->e, c
e and background componets
We can measure b
e and c
e separately
Run11 DCA distribution
•
0.015<|DCA|<0.06
is dominantly
c
e
and
b
e
with small
background
•
c
e
and
b
e
yield can be
extracted from the
DCA distribution
•
Very sophisticated
fitting/decompositi
on code of DCA &
pT distribution has
been developed
Analysis Topics from RUN14 data
•
R
AA
of b
e and c
e
•
v
2
and v
3
of b
e and c
e
•
Direct reconstruction of charmed hadrons
–
D
0
K
and other modes
–
D
+
K
and other modes
–
D
s
KK
, KK
0
and other modes
–
D* -> D
–
c
-> pK
0
, pK
and other modes
•
B
J/Psi + X
Analysis topics in RUN14 (cont.)
•
v
2
and v
3
of charged hadrons in wide pT and eta
range
•
High pt charged hadron pT distribution
•
Correlation of central arm track and VTX standalone
tracks
–
Hadron – hadron correlation
–
e (HF) – hadron correlation
–
photon/pi0 – hadorn correlation
•
Dark Photon search
•
Thermal direct photon (pT<3 GeV/c) measurement
via internal and external conversion
•
Thermal di-electron pair (1<Mee<3 GeV) from QGP
•
B can be measured as
displaced J/Psi (B
J/Psi)
•
Expected yield: ~500
displaced J/Psi in RUN14
data
B
J/Psi measurement
High pT hadrons and
correlations
•
With VTX, high pT background is
strongly suppressed; pT range
extended beyond 20 GeV/c
•
Various correlation between high
pT tracks in DC and VTX standalone
tracks
RUN11 data
•
G-2 band is basically
excluded by the present data
•
Long lived dark photon with
small mixing and small mass
can be searched in RUN14
data
•
1<mee<3 GeV is the window to
detect thermal di-electrons from
QGP
•
Charm background is suppressed by
DCA measurement
•
This measurement is possible in high
statistics data of RUN14
RUN15
RHIC plan for RUN15
•
9 weeks of polarized p+p at 200 GeV
–
Transverse spin measurement
–
Baseline of charm/bottom production
–
Photon/pi0 vias new MPC-EX at forward rapidity
•
5 weeks of p+Au at 200 GeV
–
Flow (v2, v3) in p+Au
QGP in small system
–
Cold Nuclear Matter effects in c/b production
•
2 weeks of p+Al at 200 GeV
Analysis Topics in RUN15
•
A
N
of charm production
•
c
e and b
e in p+p (baseline for Au+Au)
•
c
e and b
e in p+A (CNM effects)
•
D-meson measurements in p+p
•
D meason measurements in p+Au, p+Al
•
Flow in p+Au/p+Al
•
Photon/pi0 measurement at forward rapidity
with MPC-EX
•
Transverse spin with MPC-EX
Summary
•
RUN14-RUN16 is “heavy flavor campaign” of RHIC
–
Au+Au in RUN14 and RUN16
–
p+p/p+A in RUN15
•
Good progress in VTX analysis
–
RUN11 results will be finalized soon
–
Ready to analyze large dataset in RUN14
•
RUN14 is a big success. Large (>17B) Au+Au
events are recorded
–
DST production will start soon
–
Many analysis topics
