Transistors as Digital Switches: Intro to Logic Gates http://www.thestar.com/content/dam/thestar/entertainment/stargazing/2013/03/06/sesame_streets_count_counts_1_billion_youtube_hits/the_count.jpg Circuits that really count
My sounds laid down by the (digital) underground
Binary/Digital Representation Digital 1 = high = +Vcc Digital 0 = low = 0 V
NAND gate +Vcc
Design an OR gate A B Y 0 0 0 1 0 1 0 1 1 1 1 1
And now, your joke of the day There are only 10 types of people in the world. Those who understand binary, and those who don t.
TI 74xx series digital logic gates (old school) From the data sheet - - - - http://www.ti.com/lit/ds/symlink/sn74ls00.pdf
Digital combos Green LED illuminates when proper code is entered. Ready, set crack the code!
