Eraser: A Dynamic Data Race Detector for Multithreaded Programs

Eraser: A dynamic Data Race Detector for

Multithreaded Programs

Stefan Savage, Michael Burrows,

Greg Nelson, Patrick Sobalvarro, Thomas Anderson

Presenter:  Chao Kong

EECS 582 – W16

1

Outline

•

Introduction

•

Previous works

•

The Lockset Algorithm

•

Eraser implementation

•

Case Studies

EECS 582 – W16

2

Introduction

•

Multithreading is prevalent.

•

Microsoft Word and Netscape Navigator

•

Multithreaded programs easily produce timing-dependent data races

caused by simple synchronization errors.

EECS 582 – W16

3

Data Race

•

A data race occurs when multiple

concurrent threads access a shared variable :

•

At least one access is a write

•

No explicit mechanism to

prevent simultaneous accesses

EECS 582 – W16

4

Thread 1

Thread 2

Previous works

•

Monitors:

•

Avoid data races of shared variables which are static globals

•

Sun’s

lock_lint

 and Extended Static Checker for Modula-3

•

Work in dynamically allocated shared data

•

Problematical: requires statically reasoning about the program’s semantics

•

Happens-before

EECS 582 – W16

5

Happens-before

•

Happens-before

 relation

•

Within single thread

•

Between threads

•

Accessing variables not ordered

by happens-before relation

leads to potential data race

EECS 582 – W16

6

Thread 1

Thread 2

y := y+1;

Lock(mu);

v := v+1;

Unlock(mu);

Flaws of

Happens-before

•

Difficult to implement

•

Requires per-thread information

•

Dependent on the interleaving

produced by the scheduler

EECS 582 – W16

7

Lock(mu);

v := v+1;

Unlock(mu);

y := y+1;

Thread 1

Thread 2

y := y+1;

Lock(mu);

v := v+1;

Unlock(mu);

Flaws of

Happens-before

•

Difficult to implement

•

Requires per-thread information

•

Dependent on the interleaving

produced by the scheduler

EECS 582 – W16

8

Thread 1

Lock(mu);

v := v+1;

Unlock(mu);

y := y+1;

Thread 2

Lockset Algorithm

•

Locking discipline

•

Every shared variable is protected by some locks

•

Infer protection relation

•

Infer which locks protect which variable from execution history.

EECS 582 – W16

9

Lockset Algorithm Example

EECS 582 – W16

10

Limitations

•

Initialization

•

shared variables are frequently initialized without holding a lock

•

Read-shared Data

•

Some shared variables are written during initialization only and are read-only

thereafter

•

Read-Write Locks

•

Read-write locks allow multiple readers to access a shared variable, but allow only

a single writer to do so.

EECS 582 – W16

11

Read-Write Locks

EECS 582 – W16

12

Lock(mu1);

v := v+1;

Lock(mu2);

w=v;

Unlock(mu2);

Unlock(mu1);

Lock(mu2);

w := v;

Unlock(mu2);

Locks-held

C(v)

{mu1,mu2}

{}

{mu1,mu2}

{mu1,mu2}

{mu2}

{mu2}

{}

Refinement-I

•

Initialization



Don’t start until

see a second thread

•

Read-shared Data



Report only after

it becomes write shared

EECS 582 – W16

13

Refinement-II

EECS 582 – W16

14

•

Reader-writer locking



Change algorithm to reflect lock type

Page 22

Read-Write Locks

EECS 582 – W16

15

Lock(mu1);

v := v+1;

Lock(mu2);

w=v;

Unlock(mu2);

Unlock(mu1);

Lock(mu2);

w := v;

Unlock(mu2);

Locks-held

C(v)

{mu1,mu2}

{}

{mu1}

{mu1}

{mu2}

{}

{}

Implementation

•

Binary rewriting used



Add instrumentation to call Eraser runtime



Calls to storage allocator initializes C(v)



Each Acquire and Release call updates locks-held(t)



Each load and store updates C(v)

•

Storage explosion handled by table lookup and use of indexes to

represent set



Shadow word holds index number

EECS 582 – W16

16

Shadow Memory and Lockset Indexes

EECS 582 – W16

17

Performance

•

Slowdown by factor of 10 to 30x

•

overhead of making a procedure call at every load and store instruction

•

change thread order

•

affect the behavior of time-sensitive applications

EECS 582 – W16

18

Common false alarms - Annotations

•

Memory reuse

•

Private locks

•

Benign race

EECS 582 – W16

19



EraserReuse(address,size)

•

Resets shadow word to virgin state



Lock annotations

•

EraserReadLock/Unlock(lock)

•

EraserWriteLock/Unlock(lock)



EraserlgnoreOn()

      EraserlgnoreOff()

Races inside OS

•

Using interrupt system to provide mutual exclusion – this implicitly

locks everything affected (by interrupt level specified)

•

Explicitly associate a lock with interrupt level – disabling interrupt is like acquiring

that lock

•

Signal and wait kind of synchronization

•

V to signal for P which waits -- semaphore not “held” by thread.

EECS 582 – W16

20

A Race for optimization in AltaVista

EECS 582 – W16

21

Data Race in Vesta

EECS 582 – W16

22

Conclusion

•

The paper describes a new tool, called Eraser, for dynamically

detecting data races in lock-based multithreaded programs.

•

The paper evaluates the performance and overhead of Eraser

•

The paper tells the experience of detecting data race by several case

studies.

EECS 582 – W16

23

Questions

•

Thank you !!!

EECS 582 – W16

24

Eraser is a dynamic data race detector designed for multithreaded programs to identify timing-dependent data races caused by synchronization errors. The tool helps in detecting when multiple concurrent threads access shared variables without explicit mechanisms to prevent simultaneous accesses. It discusses the importance of multithreading, data races, happens-before relations, previous works like monitors, and introduces the Lockset Algorithm for ensuring proper locking discipline. This technology is presented in a structured manner with case studies to illustrate its effectiveness in detecting data race issues.

• Data Race Detector
• Multithreaded Programs
• Synchronization Errors
• Lockset Algorithm
• Happens-Before Relations

---

---

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

Presentation Transcript

---

1. Eraser: A dynamic Data Race Detector for Multithreaded Programs Stefan Savage, Michael Burrows, Greg Nelson, Patrick Sobalvarro, Thomas Anderson Presenter: Chao Kong EECS 582 W16 1

2. Outline Introduction Previous works The Lockset Algorithm Eraser implementation Case Studies EECS 582 W16 2

3. Introduction Multithreading is prevalent. Microsoft Word and Netscape Navigator Multithreaded programs easily produce timing-dependent data races caused by simple synchronization errors. EECS 582 W16 3

4. Data Race Thread 1 Thread 2 A data race occurs when multiple concurrent threads access a shared variable : At least one access is a write No explicit mechanism to prevent simultaneous accesses EECS 582 W16 4

5. Previous works Monitors: Avoid data races of shared variables which are static globals Sun s lock_lint and Extended Static Checker for Modula-3 Work in dynamically allocated shared data Problematical: requires statically reasoning about the program s semantics Happens-before EECS 582 W16 5

6. Thread 1 Happens-before Happens-before relation Within single thread Between threads Accessing variables not ordered by happens-before relation leads to potential data race Thread 2 EECS 582 W16 6

7. Thread 1 Flaws of Happens-before y := y+1; Lock(mu); v := v+1; Difficult to implement Requires per-thread information Thread 2 Unlock(mu); Lock(mu); Dependent on the interleaving produced by the scheduler v := v+1; Unlock(mu); y := y+1; EECS 582 W16 7

8. Thread 2 Flaws of Happens-before Lock(mu); v := v+1; Unlock(mu); Difficult to implement Requires per-thread information Thread 1 y := y+1; y := y+1; Dependent on the interleaving produced by the scheduler Lock(mu); v := v+1; Unlock(mu); EECS 582 W16 8

9. Lockset Algorithm Locking discipline Every shared variable is protected by some locks Infer protection relation Infer which locks protect which variable from execution history. EECS 582 W16 9

10. Lockset Algorithm Example EECS 582 W16 10

11. Limitations Initialization shared variables are frequently initialized without holding a lock Read-shared Data Some shared variables are written during initialization only and are read-only thereafter Read-Write Locks Read-write locks allow multiple readers to access a shared variable, but allow only a single writer to do so. EECS 582 W16 11

12. Locks-held C(v) Read-Write Locks {} {mu1,mu2} Lock(mu1); v := v+1; {mu1,mu2} Lock(mu2); {mu1,mu2} w=v; Unlock(mu2); Unlock(mu1); {} Lock(mu2); {mu2} w := v; {mu2} Unlock(mu2); EECS 582 W16 12

13. Refinement-I Initialization Don t start until see a second thread Read-shared Data Report only after it becomes write shared EECS 582 W16 13

14. Refinement-II Reader-writer locking Change algorithm to reflect lock type Page 22 EECS 582 W16 14

15. Locks-held C(v) Read-Write Locks {} {mu1,mu2} Lock(mu1); v := v+1; {mu1} Lock(mu2); {mu1} w=v; Unlock(mu2); Unlock(mu1); {} Lock(mu2); {mu2} w := v; {} Unlock(mu2); EECS 582 W16 15

16. Implementation Binary rewriting used Add instrumentation to call Eraser runtime Calls to storage allocator initializes C(v) Each Acquire and Release call updates locks-held(t) Each load and store updates C(v) Storage explosion handled by table lookup and use of indexes to represent set Shadow word holds index number EECS 582 W16 16

17. Shadow Memory and Lockset Indexes EECS 582 W16 17

18. Performance Slowdown by factor of 10 to 30x overhead of making a procedure call at every load and store instruction change thread order affect the behavior of time-sensitive applications EECS 582 W16 18

19. Common false alarms - Annotations Memory reuse EraserReuse(address,size) Resets shadow word to virgin state Lock annotations EraserReadLock/Unlock(lock) EraserWriteLock/Unlock(lock) Private locks EraserlgnoreOn() EraserlgnoreOff() Benign race EECS 582 W16 19

20. Races inside OS Using interrupt system to provide mutual exclusion this implicitly locks everything affected (by interrupt level specified) Explicitly associate a lock with interrupt level disabling interrupt is like acquiring that lock Signal and wait kind of synchronization V to signal for P which waits -- semaphore not held by thread. EECS 582 W16 20

21. A Race for optimization in AltaVista EECS 582 W16 21

22. Data Race in Vesta EECS 582 W16 22

23. Conclusion The paper describes a new tool, called Eraser, for dynamically detecting data races in lock-based multithreaded programs. The paper evaluates the performance and overhead of Eraser The paper tells the experience of detecting data race by several case studies. EECS 582 W16 23

24. Questions Thank you !!! EECS 582 W16 24
