Dynamic Programming in the Context of Knapsack and Edit Distance Problems
CMPT 706 - Algorithms for Big Data
Dynamic Programming
March 26, 2020
Dynamic Programming
1-1
The Knapsack problem
Approximation Algorithms
1-2
The Knapsack problem
Dynamic Programming
1-3
Input
: A set of n objects each having values {vi
}
i=1…n
and weight {wi
}
i=1…n
A weight limit W. - all w
i
’s and W are positive integers.
Output
: Select objects of total weight at most W such that the sum of
values is maximized.
Idea
: Suppose we decided on all objects except for the last one.
Should we add the last object?
Two cases:
1.
Take a solution that does not involve the last object.
2.
If there is room for the last object, i.e., total weight is less than W-w
n
,
then we can add it to the solution– this adds value v
n
.
The Knapsack problem
Dynamic Programming
1-4
Input
: A set of n objects each having values {vi
}
i=1…n
and weight {wi
}
i=1…n
A weight limit W - all w
i
’s and W are positive integers
Output
: Select objects of total weight at most W such that the sum of
values is maximized.
Algorithm
:
1.
Create a matrix of dimensions n x W
M[ i, w ] will have the optimal value up to weight w using items 1…i
2.
For w = 1…W
Set M[ 0 , w ] = 0 // no items used
3.
For i=1…n
For each w = 1…
W
Set M[ i , w ] = max ( M[i-1, w], M[i-1, w - w
i
] + v
i
)
4.
Return M[n ,W]
What is the runtime of the algorithm?
n*W iterations
O(1) steps in each iteration
Total runtime is O(n W)
The Knapsack problem
Dynamic Programming
1-5
Example
:
Let the values be 1,3,4,2, the weights 1,1,3,2, and W = 5
The Edit Distance Problem
Approximation Algorithms
1-6
The Edit Distance Problem
Dynamic Programming
1-7
Input
: Two strings X and Y
Goal
: find smallest number of
edit operations
required to convert X to Y.
Examples
:
One mismatch
X = G T A G C G G C G
Y = G T A A C G G C G
X = G T A G C G C G
Y = G T A
G C G
G C G
Gap in X /
Insertion in Y
X = G T A G C
–
G C G
Y = G T A G C
G
G C G
X = G T A
G
C G G C G
Y = G T A
A
C G G C G
X = G T A G C G C G
Y = G T
G C G
C G
Gap in Y /
Insertion in X
X = G T
A
G C G C G
Y = G T
–
G C G C G
The Edit Distance Problem
Dynamic Programming
1-8
Input
: Two strings X and Y
Goal
: Find an optimal alignment of X and Y, i.e. smallest number of
edit
operations
required to convert X to Y.
Another example
:
Optimal alignment
X =
G C G T A T G A G G C T A A C G C
Y =
G C T A T G C G G C T A T A C G C
X = G C
G
T A T G
A
G G C T A
–
A C G C
Y = G C
–
T A T G
C
G G C T A
T
A C G C
The Hamming Distance
Dynamic Programming
1-9
A related (simpler) notion
: Two strings X and Y of the same length
Goal
: smallest number of
mismatches
between X to Y.
Examples
:
X = G T A
G
C G G C G G A
C
Y = G T A
A
C G G C G G A
T
X = S T R
O
N G
E R
Y = S T R
E
N G
T H
The Edit Distance Problem
Claim
: For two strings X, Y of equal length
EditDist(X, Y) <= HammingDist(X, Y)
Proof
: can use substitution only.
What about the other direction? Is there any non-trivial relation?
Example
:
X = ababababababababab
Y = bababababababababa
Q
: What is the edit distance between X and Y?
A
: 2 - we can remove a from the beginning of X and add a to the end.
Q
: What is the Hamming distance between X and Y? - n
The Edit Distance Problem
Dynamic Programming
1-11
Input
: Two strings X and Y
Goal
: Find an optimal alignment of X and Y, i.e. smallest number of
edit
operations
required to convert X to Y.
Operations are
:
•
R – replace
•
I – insert into X
•
D – delete from X
X = G C
G
T A T G
A
G G C T A
–
A C G C
Y = G C
–
T A T G
C
G G C T A
T
A C G C
The Edit Distance Problem
Dynamic Programming
1-12
Input
: Two strings X of length n, and Y of length m
Goal
: Find an optimal alignment of X and Y, i.e. smallest number of
edit
operations
required to convert X to Y.
Algorithm
:
Let’s consider the substrings X[1…i] and Y[1…j].
Suppose that (by recursion) we can solve the shorter subproblems.
We have 4 options to handle the last symbols
•
if X[i] = Y[j]
use the optimal alignment for X[1…i-1] and Y[1…j-1]
•
Otherwise
•
Set X[i] to be Y[j]
•
Delete X[i] from X
•
Append Y[j] to X
The Edit Distance Problem
Dynamic Programming
1-13
Input
: Two strings: X of length n and Y of length m
Goal
: Find an optimal alignment of X and Y, i.e. smallest number of
edit
operations
required to convert X to Y.
Idea
:
Define a matrix D[0…n,0….m]
1.
Set D[i,0] = i for all i=0…n
2.
Set D[0,j] = j for all j=0…m
3.
For i,j both non-zeros define
(
D[ i-1 , j ] + 1
// Delete X[i]
D[i,j] = min (
D[ i, j-1 ] + 1
// Insert Y[j] after X[i]
(
D[ i-1 , j-1 ] + 1
(X[i]
≠
Y[j])
// Match or Mismatch
| 1 if X[i]
≠
Y[j]
Here 1
(X[i]
≠
Y[j])
=
<
| 0 if X[i]
=
Y[j]
The Edit Distance Problem
Dynamic Programming
1-14
Input
: Two strings: X of length n and Y of length m
Goal
: Find an optimal alignment of X and Y, i.e. smallest number of
edit operations
required to convert X to Y.
Example
: [doing online]
X = BLOCK Y = BOOK: A solution: (1) remove L and (2) replace C with O.
The Edit Distance Problem
Dynamic Programming
1-15
Input
: Two strings: X of length n and Y of length m
Goal
: Find an optimal alignment of X and Y, i.e. smallest number of
edit
operations
required to convert X to Y.
Dist(X,Y)
: |X| = n, |Y| = m
1.
If n = 0, return m
2.
If m = 0, return n
3.
Otherwise
compute d
1
= Dist( X[1…n-1] , Y[1…m] ) + 1
compute d
2
= Dist( X[1…n] , Y[1…m-1] ) + 1
compute d
3
= Dist( X[1…n-1] , Y[1…m-1] ) + 1
(X[i]
≠
Y[j])
return min(d
1
, d
2
, d
3
)
What is the runtime of the algorithm?
Let’s say m=n
Then T(n) >= 3T(n-1)
T(n) = 3T(n-1)
=3
2
*T(n-2)
=3
3
*T(n-3)…
=3
10
*T(n-10)…
=3
n-1
*T(1) = O(3
n
)
The Edit Distance Problem
Dynamic Programming
1-16
Input
: Two strings: X of length n and Y of length m
Goal
: Find the edit distance between X and Y
Dynamix programming approach
: |X| = n, |Y| = m
Define a matrix D[0…n,0….m]
1.
Set D[i,0] = i for all i=0…n
2.
Set D[0,j] = j for all j=0…m
3.
For i=1…n and for j=1…m
D[i,j] = min(
D[ i-1 , j ] + 1
// Delete X[i]
D[ i, j-1 ] + 1
// Insert Y[j] after X[i]
D[ i-1 , j-1 ] + 1
(X[i]
≠
Y[j])
// Match or Mismatch
4.
Return D[n,m]
What is the runtime?
n*m iterations in step 2
O(1) steps in each iteration
Q
: How do you find the optimal sequence
of operations that turns X into Y
The Edit Distance Problem
Dynamic Programming
1-17
An alternative view
: We can think about the matrix and a shortest path
problem on the weighted grid graph from D[0,0] to D[n,m].
On horizontal/vertical edges the weight is 1.
On the diagonal edges the weight is either 0 (if match) or 1 (if mismatch)
The Edit Distance Problem
Dynamic Programming
1-18
Weighted variant
: We can also consider the problem where different
operations have different costs.
For example, mismatch-cost(A, E) < mismatch-cost(B, Q)
Inserting/deleting a letter more than mismatch
Homework
: solve the weighted variant of EditDistance.
Reading for next time
Exercises from the Book:
6.7, 6.8, 6.11
Huffman Code
1-19
