Data Lakes
The Non-CERN Perspective?
Towards terascale-
in-the-cloud?
J Jensen, STFC(?)
10 Apr 2018
Exercise
•
Analyse data in the cloud?
–
Towards the 100 GB – 1TB range
•
Old database paradigm:
–
“Just drop it in”
•
Mostly using my own Azure
account, and spare time
–
And work done during phone meetings
:-)
–
Split personality (= work/personal) in
portals works well
Traditional Data Workflow
Find
data
EDA
Analysis
Hypo-
thesis
testing
results
Publish
"Traditional" analysis
•
R, Mathematica, Matlab, Excel, Jupyter
notebooks
–
Locally, or in cloud
•
ALL DATA IS LOADED INTO MEMORY
•
If your data is too big, sample, and analyse
the sample
–
Centuries of good (and bad) practice
Limits of In-Memory
Processing
•
STFC’s cloud
–
Default: 8 GB max per machine, 20 GB/person
–
Typ. 90 GB, ~300 GB if you ask v. nicely
•
Azure
–
432 GB in some regions
–
256 GB in Northern Europe
•
Alibaba cloud
–
"Up to 768 GB"
Suppose you want to analyse
all
your data... (or just a
large dataset)
•
Hadoop
–
Requires a degree in Astrology
–
Made easier with Pig, Hive, etc.
•
Load it into a database
•
Data Lake Analytics?!
What's a Data Lake?
•
… Hadoop (Wikipedia)
•
Linked data centres with HSM (CERN)
•
A sort of sophisticated row-based database
(Microsoft)
•
"Fake News!" (some bloke on the Internet)
–
(See Sam’s post to storage group)
Getting Started (Azure)
•
Analysis language: hybrid SQL and C# - U-SQL
•
Assumes data is row-based
–
And text (CSV, TSV, …) … !!
–
However, it understands .gz and transparently
uncompresses
•
Auto-parallelisation
–
You decide # parallel tasks
–
Max 250 but it can be increased of course
@timestring = EXTRACT AccIndex string,
longitude float, latitude float, severity int?,
Date string, Time string,
SpeedLimit int?, light int?, weather int?
FROM "/data/acc-restricted.csv.gz" USING Extractors.Csv(nullEscape:"-1",
rowDelimiter: "\n",
encoding: Encoding.[ASCII],
skipFirstNRows: 1);
@dates = SELECT DateTime.ParseExact( Date + Time, "dd/MM/yyyyHH:mm",
System.Globalization.CultureInfo.InvariantCulture )
AS date FROM @timestring ;
@hours = SELECT date.ToString( "HH", DateTimeFormatInfo.InvariantInfo )
AS hour FROM @dates;
@table = SELECT hour, COUNT(hour) AS HourCount FROM @hours GROUP BY hour;
OUTPUT @table TO "/output/table.csv" USING Outputters.Csv();
Simple example U-SQL (one of my earlier experiments)
Import: column name and
type (MUST import ALL!!)
Listy type
(rows)
Case
sensitive
Partial types!?
Nullable
From default
lake store
Doesn’t
understand
headers
Use .NET
(in C#)
To default
lake store
Getting Started (Azure)
•
Developing - Azure portal or Visual Studio
–
VS lets you run stuff locally, and gives syntax
highlighting – portal doesn't
–
VS lets you save stuff!
–
Portal saves your job
when it is (attempted) run
•
Keep reusing old jobs – works well for linear and incremental
development, but takes a bit getting used to
•
Safe to discard edits and back up to job list
–
Need to
submit job
to find out whether it is correct
and works
Getting Started (Azure)
Getting Started (Azure)
Data – it should be obvious,
but...
•
Put your analytics where your data is
–
Same cloud region
•
Don't run your analysis on the full dataset
–
Create a (representative) sample
–
Analyse it in a tool you know well (R, Excel,…)
–
Debug your script; when it finally runs, compare the
outputs
–
Debug runs with lowest number of parallel jobs
–
(Optionally) Develop/build locally, then run in cloud
Updated workflow
Tidy
data
Scale to
larger
data
Compare
Develop
/test
Download
results
Delete
cloud
Data – sampling
•
Your samples should contain all the weirdness
of your full data
–
This is tricky for sparse datasets (make sure all
your weirdness is present in the sample)
–
Easy to sample CSV and TSV (… awk, head)
0
1
3
0
1
1
1.
1
0
1
1
-
1
0
2
1
1
2
3
1
Data – the rules of the
game
•
Assume we cannot egress cloud generated
data
–
Until we have the final results
–
Download/reupload editing not feasible
–
However, data from outside the cloud can re-
ingest
•
Thus, edit cloud-generated data in the cloud?
Editing in the Cloud
ADLA
ADLS
Blob
store
VM
Editing in the Cloud
ADLA
ADLS
Blob
store
VM
Fuse mounted
blob store
“Data
Factory”
Azure AD
authenticator
Azure
AD
Editing in the Cloud
ADLA
ADLS
Blob
store
VM
Fuse mounted
blob store
“Data
Factory”
Azure AD
authenticator
Azure
AD
Editing in the Cloud –
Resource Groups
ADLA
ADLS
Blob
store
VM
“Data
Factory”
RG1
RG2
Data Factory
•
Like a data workflow orchestrator
–
Insists on understanding the file as it
passes through(!?)
–
Understands CSV but not gzipped CSV(!)
–
Had trouble with the ADLS permissions
•
Not fw
•
Not at-rest encryption
•
Caveat: you can attach (expensive!)
things that do not delete with the
resource that contains the factory!
Big data analysis workflow
•
"Workflow" in Azure-ese is "Data Factory"
–
Not currently available in Northern Europe
–
Can move stuff from A to B in Northern Europe
even if it sits in Western Europe
–
Can also move from 3rd party (e.g. desktop, S3
endpoint, etc.)
Down The Rabbit Hole
•
Build Workflows, automate
–
Do create subdirs/containers
(e.g. input, output)
•
The rabbit holes:... can spend
a lot of time debugging or
investigating
–
E.g. at-rest encryption, access
perms, Azure AD
–
Feels like spending time on
“unrelated” tasks
–
Sometimes it's best to start over
with your lessons learnt
–
Eventually need to get to the
“science bit”
Giant Steps
Services that “understand” science data?
•
Lots of science domains with not much in common
•
Except of course everybody uses HDF5 except HEP
•
Deploy VMs/containers in the cloud
•
Interfaces to science data
•
Science apps in market place
•
ROOT is in Debian (and so is Globus…)
Data Scientist
•
As before need platform expertise
–
Only more so (terascale = extra complexity)
–
Azure docs pretty good – tuts, refs.
•
In addition to viz., stats, maths, CS, domain,
comms. [Schutt & O’Neil]
Danger!
•
The infrastructure scales
•
But the maths doesn't (necessarily)
var(X)=(X-
X
)
²
/N
var(X)=(ΣX
²
-
X
²
)/N
ΣX
²
...
Science Data
•
CSV and TSV are, of course, rather non-
optimal for science
–
Lots of impl. variations
–
No consistent NULL
–
Escape characters
–
Larger than binary encodings
–
Variable records size
•
Need an Extractor for HDF5?
Conclusion
•
Need platform expertise
•
The proof is very much in the pudding
