CLASSIFYING ENTITIES INTO AN INCOMPLETE ONTOLOGY Bhavana Dalvi, William W. Cohen, Jamie Callan School of Computer Science, Carnegie Mellon University
Motivation Existing Techniques Semi-supervised Hierarchical Classification: Carlson WSDM 10 Extending knowledge bases: Finding new relations or attributes of existing concepts Mohamed et al. EMNLP 11 Unsupervised ontology discovery: Adams et al. NIPS 10, Blei et al. JACM 10, Reisinger et al. ACL 09 Evolving Web-scale datasets Billions of entities and hundreds of thousands of concepts Difficult to create a complete ontology Hierarchical classification of entities into incomplete ontologies is needed
Contributions Hierarchical Exploratory EM Adds new instances to the existing classes Discovers new classes and adds them at appropriate places in the ontology Class constraints: Inclusion: Every entity that is Mammal is also an Animal Mutual Exclusion: If an entity is Electronic Device then its not Mammal
Problem Definition Input Large set of data-points : ?1 ?? Some known classes : ?1 ?? Class constraints ?? between ? classes Small number of seeds per known class: |seeds| n Output Labels for all data-points ?? Discover new classes from data: ??+? ??+? k +? ? Updated class constraints: Zk ??+?
Review: Exploratory EM [Dalvi et al. ECML 2013] Initialize model with few seeds per class Iterate till convergence (Data likelihood and # classes) E step: Predict labels for unlabeled points If P(Cj | Xi) is nearly-uniform for a data-point Xi, j=1 to k Create a new class Ck+1, assign Xi to it Classification/clustering KMeans, NBayes, VMF Max/Min ratio JS Divergence M step: Recompute model parameters using seeds + predicted labels for unlabeled points Number of classes might increase in each iteration Check if model selection criterion is satisfied If not, revert to model in Iteration `t-1 AIC, BIC, AICc
Hierarchical Exploratory EM Initialize model with few seeds per class Iterate till convergence (Data likelihood and # classes) E step: Predict labels for unlabeled points Assign a consistent bit vector of labels for each unlabeled datapoint If ? ????????????) is nearly-uniform for a data-point ?? Create a new class ????, assign ?? to it Update class constraints accordingly M step: Recompute model parameters using seeds + predicted labels for unlabeled points Number of classes might increase in each iteration Since the E step follows class constraints this step need not be modified Check if model selection criterion is satisfied If not, revert to model in Iteration `t-1
Divide-And-Conquer Exploratory EM Level 1 Assumptions: Classes are arranged in a tree- structured hierarchy. Classes at any level of the hierarchy are mutually exclusive. Root Level 2 Location Food Inclusion Level 3 Condiment Vegetable Country State E.g. Spinach, Potato, Pepper Mutual ExcIusion
Divide-And-Conquer Exploratory EM California 1.0 Root Location Food Condiment Vegetable Country State
Divide-And-Conquer Exploratory EM California 1.0 Root 0.9 Location 0.1 Food Condiment Vegetable Country State
Divide-And-Conquer Exploratory EM California 1.0 Root 0.9 Location 0.1 Food Condiment Vegetable Country State 0.8 0.2 1 0 0 1 1 0 0
Divide-And-Conquer Exploratory EM Coke 1.0 Root Location Food Condiment Vegetable Country State
Divide-And-Conquer Exploratory EM Coke 1.0 Root Location Food 0.1 0.9 Condiment Vegetable Country State
Divide-And-Conquer Exploratory EM Coke 1.0 Root Location Food 0.1 0.9 Condiment Vegetable Country State 0.55 0.45
Divide-And-Conquer Exploratory EM Coke 1.0 Root Location Food 0.1 0.9 C8 Condiment Vegetable Country State Coke 0.55 0.45 1 1 0 0 0 0 0 1
Divide-And-Conquer Exploratory EM Coke 1.0 Root Adds to class constraints ?8 ???? ?8 ????????? = ? Location Food 0.1 0.9 ?? Condiment Vegetable Country State Coke 0.55 0.45 1 1 1 0 0 0 0 0
Divide-And-Conquer Exploratory EM Adds to class constraints ?9 ???? ?9 ???? = ? Cat 1.0 Root C9 Location 0.45 0.55 Food Cat C8 Condiment Country Vegetable State 0 0 0 1 0 0 0 0 1
What are we trying to optimize? Objective Function : Maximize { Log Data Likelihood Model Penalty } m: #clusters, Params{C1 Cm} subject to Class constraints: Zm
Datasets Ontology 2 Ontology 1 Clueweb09 Corpus + Subsets of NELL Dataset #Classes #Levels #NELL entities #Contexts DS-1 11 3 2.5K 3.4M DS-2 39 4 12.9K 6.7M
Results Dataset #Train /Test Points DS-1 335/ 2.2K DS-2 1.5K/ 11.4K
Results Dataset #Train Level #Seed/ #Ideal Classes /Test Points DS-1 335/ 2.2K 2 2/3 3 4/7 DS-2 1.5K/ 11.4K 2 3.9/4 3 9.4/24 4 2.4/10
Results Dataset #Train Level #Seed/ #Ideal Classes Macro-averaged Seed Class F1 /Test Points FLAT SemisupEM ExploratoryEM DS-1 335/ 2.2K 2 2/3 43.2 78.7 * 3 4/7 34.4 42.6 * DS-2 1.5K/ 11.4K 2 3.9/4 64.3 53.40 3 9.4/24 31.3 33.7 * 4 2.4/10 27.5 38.9 *
Results Dataset #Train Level #Seed/ #Ideal Classes Macro-averaged Seed Class F1 /Test Points FLAT DAC SemisupEM ExploratoryEM SemisupEM ExploratoryEM DS-1 335/ 2.2K 2 2/3 43.2 78.7 * 69.5 77.2 * 3 4/7 34.4 42.6 * 31.3 44.4 * DS-2 1.5K/ 11.4K 2 3.9/4 64.3 53.40 65.4 68.9 * 3 9.4/24 31.3 33.7 * 34.9 41.7 * 4 2.4/10 27.5 38.9 * 43.2 42.40
Conclusions Hierarchical Exploratory EM works with incomplete class hierarchy and few seed instances to extend the existing knowledge base. Encouraging preliminary results Hierarchical classification Flat classification Exploratory Learning Semi-supervised Learning Future work: Incorporate arbitrary class constraints Evaluate the newly added clusters
Thank You Questions?
Class Creation Criterion Given ? ?? ??) , ? = 1 ? & ????????= [1 ? 1 ?] MinMax ratio: ???(? ????))/ ???(? ?? ??) < 2 Jensen-Shannon divergence: JS- Div(? ?? ??),????????) <1 ?
Model Selection Extended Akaike Information Criterion AICc(g) = -2*L(g) + 2*v + 2*v*(v+1)/(n v -1) Here g: model being evaluated, L(g): log-likelihood of data given g, v: number of free parameters of the model, n: number of data-points.
