ATST Safety Review High-Level Software Overview


ATST Safety Review
High-Level Software

26 January 2011

Work Package Overview
Telescope
Software
Control Systems
(MCS, M1CS,
TEOACS, FOCS,
ACS, WCCS,
PACCS, ECS)
Observatory
Software
Control Systems
(OCS, DHS, TCS,
ICS)
Instrument
Software
Control Systems

Work Package Overview

WBS Area(s):
1.0
 Telescope,
2.0
 WFC,
3.0
 Instruments,
4.0
 Software,

5.0
Enclosure
Responsible Engineer: Berst (
3.6
), Cowan (
4.3
), Goodrich (
1.0, 4.4
),

Hubbard
(
4.1
), Johanssen (
3.1 - 3.5
), Wampler (
4.2
)
Group Manager: Bret Goodrich
Contractor(s):
TCS
 (4.4)
,
 Observatory Control Ltd, Cambridge, UK;

MCS (1.1)
, IMT/MT
 Mechatronics, Rockford, IL/Mainz, Germany;

ECS (5.6)
; AEC/Idom, Minneapolis, MN/Bilbao, Spain;

M1CS (1.2), TEOACS (1.3)
:
TBD
Partners(s):

VBI (3.2), WCCS (2.3), PACCS (3.1.1)
, ATST, Sunspot;

ViSP (3.3)
, High Altitude Observatory, Boulder;

NIRSP (3.4)
, Institute for Astronomy, Manoa;

VTF (3.5)
, Kiepenheuer-Institut für Sonnenphysik, Freiburg,

Germany

Work Package Overview

Telescope Software (Goodrich)
1.1: TMA, Mount Control System
operation of the altitude, azimuth, rotator mechanical systems
slew and track across the entire ranges of motion
1.2: M1 Assembly, M1 Control System
operation of the 120 axial and 24 lateral mirror actuators
support and figure control of the M1 mirror
1.3: Top-end Optical Assembly, TEOA Control System
operation of the hexapod, fast tip-tilt
position and correction of the M2 mirror

Work Package Overview

Telescope Software (Goodrich)
1.5: Feed Optics, Feed Optics Control System
operation of the M3 and M6 tip-tilt
1.8: Acquisition Control System
operation of the acquisition camera
2.3: Wavefront Correction Control System (Sunspot)
operation of the high-order and low-order wavefront correction
3.1.1: Polarization Analysis and Calibration (Sunspot)
operation of the calibration optics at the Gregorian Optical Station
5.6: Enclosure, Enclosure Control System
operation of the carousel, shutter, entrance aperture
slew and track across entire range of motion

Work Package Overview

Instrument Software
3.1.4: Instrument Control System (Johanssen)
operation and coordination of the instruments
3.6.2: Camera Software System (Berst)
operation of instrument cameras
3.2: Visible Broadband Imager
3.3: Visible Infrared Spectropolarimeter
3.4: Near-Infrared Spectropolarimeter
3.5: Visible Tunable Filter
each operates the mechanisms of the instrument

Work Package Overview

Observatory Software
4.1: Common Services Framework (Hubbard)
infrastructure for all software systems
4.2: Observatory Control System (Wampler)
execution of observing programs
4.3: Data Handling System (Cowan)
data transfer, processing, storage, and archiving
4.4: Telescope Control System (OSL)
coordination of telescope systems

Schedule Overview

Telescope Control System:
FDR Feb 2011; Beta Release Feb 2012; Delivered Feb 2013
Observatory Control System:
Beta Release June 2012; Delivered June 2014
Data Handling System:
Beta Release July 2012; Delivered Dec 2015
Instrument Control System:
Beta Release August 2012; Delivered Nov 2015
Camera Software System:
FDR Jun 2011; Beta Release 2014; Delivered Dec 2015

Reference Design
Preliminary Hazard Analysis

Software is not a safety system
All safety mechanisms (GIS) are wired in parallel with the
control systems
Software may detect, report, and correct errors
These errors may or may not affect safety
Safety mechanisms must detect the safety-related errors
Software has an independent interlock network
That takes GIS interlocks and broadcasts them to the
relevant software systems

Reference Design
Preliminary Hazard Analysis

Personnel
 Safety Hazards (unanticipated motion):
Movement on boot-up or start-up
Control system energizes motors and begins indexing operation
Prevention:
Manual lock-out mechanism
All software systems use a lifecycle mechanism.
Init state does not allow connection of software to hardware
Requirement to have a default, unpowered state and use it
“The default state of any equipment shall be an inert, non-moving,
non-powered condition. Equipment shall take this state on an
interlock condition, initialization, shutdown, or when commanded
through the software interface.”
Tested on acceptance
ATST standard motion controller enforces behavior
Three-step process: power-up, index, move

Motion Control States
Operational
Off
Lost

idle

home
Idling

[fail]

park

[done]

home
Manual
Halted
Following

follow

idle

idle

park

move or
offset

idle or
[done]

manual

park

manual

shutdown

startup
Jogging

jog

idle

Reference Design
Preliminary Hazard Analysis

Personnel
 Safety Hazards (unanticipated motion):
Movement after interlock release
Control system was moving when interlock occurred
Control system now receives interlock release and resumes
moving
Prevention:
Manual lockout mechanism
Interlocks force software systems to cancel all actions
Interlocks force software systems into default, unpowered state
Resumption now follows boot-up/start-up process

Software Interlocks
Controller
event=atst.gis
attr=ecs
GIS
OCS
Operator
Display

status
Controller

raiseInterlock()
reject commands
cancel actions
doRaiseInterlock
()
local operations
lowerInterlock()
accept commands
doLowerInterlock()
local operations

interlock:event(string)
 interlock:attribute(string[])
Controller
event=atst.gis
attr=tma
Controller
event=atst.gis
attr=m1
GIS sends regular status
information
Operator can monitor the
current GIS status
A controller registers for a
specific interlock event

interlock event

register
An interlock will cause an
interlock event to be sent
The registered
interlock event name
The registered
interlock signal

Software Interlocks
EMCS
ecs.az
ecs.alt
ecs
GIS
OCS
Enc hand
paddle
Mnt Az
mcs.az
mcs.alt
mcs
GIS
OCS
Mnt hand
paddle
Mnt Alt
Interlock of top-level software system on hand paddle enable

Enclosure

Mount
Cancel all actions
Cancel all actions

Software Interlocks
EMCS
ecs.az
ecs.alt
ecs
GIS
OCS
Mnt Az
mcs.az
mcs.alt
mcs
GIS
OCS
Mnt Alt
Interlock of low-level software system on hardware fault
az fault
az fault

Enclosure

Mount
Cancel all actions
Power off motors
Cancel all actions
Power off motors
